OWNER'S MANUAL
MANUEL D'UTILISATION
GEBRAUCHSANLEITUNG
MANUALE SUPPLEMENTARE PER IL PROPRIETARIO
MANUAL DEL PROPIETARIO
MANUAL DO UTILIZADOR
OWNER'S MANUAL
This owner's manual contains the
instruction items necessary for correct
and safe use. Before operating this
engine be sure to read this owner's man-
ual to understand how to correctly oper-
ate the engine. (Incorrect operation could
result in accidents and injury.)
Also be sure to read the owner's manu-
als of equipment used with this engine
before operating this engine.
Store this owner's manual with care so
that it can be referred to at any time.
MANUALE SUPPLEMENTARE PER IL PROPRIETARIO
Il presente Manuale del Proprietario con-
tiene le istruzioni necessarie per un utiliz-
zo corretto e sicuro. Prima di avviare il
motore leggere attentamente il presente
Manuale per comprendere correttamente
il funzionamento del motore. (Un funzion-
amento scorretto potrebbe causare inci-
denti e ferite).
Prima di avviare il motore, leggere accu-
ratamente i Manuali del Proprietario rela-
tivi alle attrezzature utilizzate con il
motore prima di iniziare il funzionamento.
Conservare con cura il presente Manuale
del Proprietario in modo da poterlo con-
sultare in qualunque momento.
MANUEL DE L'UTILISATEUR
Ce manuel de l'utilisateur décrit les
précautions à prendre pour une utilisation
correcte et sûre du moteur. Lisez ce manuel
avec attention et assurezvous de bien le
comprendre afin d'utiliser le moteur dans les
meilleures conditions possibles. (une utilisa-
tion incorrecte du moteur peut entraîner un
accident ou des blessures.)
Veuillez lire aussi le manuel de l'utilisateur
de l'appareil sur lequel est monté ce moteur
avant de l'utiliser.
Conservez avec soin ce manuel de l'utili-
sateur afin de pouvoir le consulter au besoin.
MANUAL DEL PROPIETARIO
Este manual de instrucciones contiene
ítems de instrucciones necesarios para
un uso correcto y seguro. Antes de hacer
funcionar este motor, asegúrese de leer
el manual de instrucciones para enten-
der como utilizar correctamente el
motor. (Un funcionamiento incorrecto
puede provocar un accidente y heridas.)
Además, asegúrese de leer los manuales
de instrucciones del equipo utilizado con
este motor antes de hacerlo funcionar.
Guarde el manual de instrucciones con
cuidado para que pueda consultarlo en
cualquier momento.
GB
F
D
I
E
P
GEBRAUCHSANLEITUNG
Diese Bedienungsanleitung enthält die
Punkte, die für eine richtige und sichere
Benutzung erforderlich sind. Vor der
Benutzung des Motors bitte sicherstellen, daß
Sie die Bedienungsanleitung gelesen haben
und verstehen, wie dieser Motor richtig bedi-
ent wird. (Falsche Bedienung könnte Unfälle
und Verletzungen zur Folge haben.)
Stellen Sie sicher, die Bedienungsanleitungen
der Geräte gelesen zu haben, die mit diesem
Motor benutzt werden sollen, bevor der
Motor betrieben wird.
Bewahren Sie die Bedienungsanleitung gut
auf, um bei späterer Gelegenheit jederzeit auf
sie zugreifen zu können.
MANUAL DO UTILIZADOR
Este manual do proprietário contém as
instruções necessárias para uma utilização
correcta e segura. Antes de fazer funcionar
este motor, leia este manual e ass
g e
u
e r
e s -
de que compreende como operar correcta-
mente o motor. (Uma operação incorrecta
poderá resultar em acidentes e ferimentos.)
Leia também o manual do proprietário do
equipamento utilizado com este motor antes
de o fazer funcionar.
Guarde cuidadosamente este manual do
proprietário de forma a poder consultálo
no futuro.
GB30G
GB40G
KN52060AA
19/10
