- Page 1 IF101 2Q/4Q IF101 2Q/4Q Construction Guide Revision 1.02 June 27 , 2018 ELBY Designs - Laurie Biddulph 9 Follan Close, Kariong, NSW 2250, Australia elby-designs@bigpond.com http://www.elby-designs.com 1 of 3...
- Page 2 4. Solder the jack sub-assembly in to place 5. Install the Column 1 board 6. Fit the short IDC cable between the modules ELBY Designs - Laurie Biddulph 9 Follan Close, Kariong, NSW 2250, Australia elby-designs@bigpond.com http://www.elby-designs.com...
- Page 3 6. Turn the [Y LEVEL] knob full clockwise. 7. Connect a 200Hz 10VAC triangle wave to [X IN] 8. Connect 5VDC to [Y IN] 9. Adjust P204 for an output of 10VAC. ELBY Designs - Laurie Biddulph 9 Follan Close, Kariong, NSW 2250, Australia elby-designs@bigpond.com http://www.elby-designs.com...
