Summary of Contents for Dual Electronics Corporation DM70MIR
- Page 1 DM70MIR INSTALLATION/OWNER’S MANUAL Media Receiver with USB Mirror featuring a 7" Digital TFT Display...
-
Page 2: Fcc Compliance
DM70MIR FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Safety Notice
The SAFETY NOTICE is reminder to drive responsibly and safely while using your mobile phone device, or any APP’s that are compatible with this unit. it is highly recommended that your Dual DM70MIR is installed by a professional installer or an authorized dealer. - Page 4 DM70MIR Preparation Please read and understand entire manual before installation. Consult a qualified technician for detailed instructions or installation assistance. Before You Start • Disconnect negative battery terminal. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
-
Page 5: Wiring Diagram
DM70MIR Wiring Diagram External Microphone (included) Tips When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause damage. The unit uses (1) 10 amp ATC blade-type fuse located on the back of the unit. - Page 6 DM70MIR Main Control Locations Microphone microSD Card Slot Mode / Voice Assistant Reset Tune/Track Up Auxiliary Input Volume / Power / Mute USB Slot Tune/Track Down...
- Page 7 DM70MIR Source Menu Operation Radio Press to access Radio. USB Mirroring Press to initiate USB mirroring. Bluetooth Phone Press to access Bluetooth phone. Settings Press to display and adjust system settings. Camera Press to display the rear and front cameras.
-
Page 8: On Screen Controls
DM70MIR On Screen Controls Screen Brightness Press up to two times to dim the screen. Press a third time to put the unit in standby mode (screen will go black). Press anywhere on the screen to return to normal screen operation. -
Page 9: Audio Settings
DM70MIR Audio Settings Select any of the preset EQ settings (Flat, Classic, Rock, Pop, Jazz, Beat or User) or use the touch screen to manually adjust EQ settings. Select any of the preset Surround settings: Concert, Church, Passive, Wide, Live or None. -
Page 10: Settings Menu
DM70MIR Settings Menu From the Main Menu, press the gear icon to access the Setup menu and adjust the following: General, Audio, Display and Bluetooth. General: • OSD Language - Select English. • Wallpaper - Select from three different wallpaper options. -
Page 11: Tuner Operation
DM70MIR Tuner Operation Select the Radio icon from the Main Menu screen. Radio Operation Press to return to Main Menu screen. Main Menu Displays the current mode of operation. Mode Indicator Press to tune to a lower frequency one step at a Tune Down time. - Page 12 DM70MIR USB/microSD Operation To play MP3 files from a USB device or microSD card, USB/microSD insert a USB device or microSD card, and playback Operation will begin automatically. To return to USB or microSD playback from another mode of operation, select the corresponding icon from the Main Menu.
-
Page 13: Media Compatibility
DM70MIR Media Compatibility File Type FAT 12 File System FAT 16/FAT 32 .mp3/.MP3/.Mp3/.mP3 File Extension .rmp/.m4a MPEG 1 MPEG MPEG 2 Format MPEG 2.5 MPEG 1 32/44.1/48kHz Sampling MPEG 2 12/16/22.05/24kHz Frequency MPEG 2.5 8/11.025/12kHz... -
Page 14: Bluetooth Operation
Bluetooth device. Refer to the owner’s manual for your device for more details. The device name is “DM70MIR”. The unit can be in any mode of operation when pairing is performed. On certain phones, pairing may need to be done more than once. -
Page 15: App Operation
DM70MIR Bluetooth Operation Paired Device List Press to display a list of paired devices, and select desired device to connect. Talk Press to connect a call to the number entered. Press to end a call. End Call Previous Track Press to go back to the previous track. - Page 16 DM70MIR USB Mirroring To set up USB Mirroring capabilities, select USB Mirroring from the main menu and follow the on-screen directions for connecting your Android phone or Apple iPhone. Once completed, the unit will mirror the phone display onto the receiver’s display.
-
Page 17: Rear Camera
DM70MIR Rear Camera Connect an optional rear camera to the Rear Camera inputs (Yellow RCA connector for video; there is no audio connection for a front camera). Refer to the wiring diagram for details. Manual selection - Touch the REAR CAMERA icon from the Main Menu or from any operational mode (when enabled) to select camera mode. -
Page 18: Steering Wheel Controls
DM70MIR Steering Wheel Controls A third-party adapter must be used in order for the DM70MIR to be compatible with any OEM steering wheel controls. The DM70MIR has a built-in 3.5mm SWC interface that compatible with many popular 3rd party SWC control modules, such as PAC, METRA, and others. -
Page 19: Limited One-Year Warranty
DM70MIR Limited One-Year Warranty What to do? This warranty gives you specific legal rights. 1. Before you call for service, check the You may also have other rights which vary from state to state. troubleshooting guide in your owner’s manual. A slight adjustment of any custom Dual Electronics Corp. -
Page 20: Troubleshooting
DM70MIR Troubleshooting General PROBLEM CAUSE ACTION Red and/or Yellow wire not connected or Check connections for proper voltage incorrect voltage (11~16VDC) Unit will not turn on Black wire not connected Check ground connection (no power) Blown fuse on unit or vehicle... -
Page 21: Specifications
DM70MIR Specifications FM Tuner US Tuning Range: 87.5MHz-107.9MHz EU Tuning Range: 87.50MHz-108.00MHz Usable Sensitivity: 8.5dBf 50dB Quieting Sensitivity: 10dBf Stereo Separation@ 1kHz: 30dB Frequency Response: 30Hz-13kHz AM Tuner Tuning Range: 530kHz-1710kHz Usable Sensitivity: <42dBu Frequency Response: 30Hz-2.2kHz Bluetooth Version: 4.1 + EDR... - Page 22 Dual Electronics Corp. Toll Free: 1-866-382-5476 Monday-Friday, 9AM-5PM EST www.dualav.com ©2021 Dual Electronics Corp. All rights reserved. NSC1121-V01...
