- Page 1 AVB32V03C CM500 series Commercial HIGH RESOLUTION TOUCH SCREEN Digital Thermostat with Humidity Control Up to 3-heat & 2-cool with Wi-Fi Owner’s Manual & Installation Instructions...
- Page 2 Notice: Only peripherals complying with FCC limits may be attached to this equipment. Operation with noncompliant peripherals or peripherals not recommended by ClimateMaster, is likely to result in interference to radio and TV reception. Changes or modifications to the product, not expressly approved by ClimateMaster could void the user’s authority to operate the equipment.
- Page 3 être choisis afin que la puissance isotrope rayonnée équivalente (PIRE) ne est pas plus de ce qui est nécessaire pour une communication réussie. We, ClimateMaster, declare under our sole responsibility that the device to which this declaration relates: Complies with Part 15 of the FCC Rules. Operation is...
- Page 4 Glossary of Terms Auto-Changeover: A mode in which the thermostat will turn on the heating or cooling based on room temperature demand. Cool Setpoint: The warmest temperature that the space should rise to before cooling is turned on (without regard to deadband). Deadband: The number of degrees the thermostat will wait, once a setpoint has been reached, before energizing heating or cooling.
-
Page 5: Table Of Contents
Table of Contents GET TO KNOW YOUR THERMOSTAT Home Screen ..................1 Menu Screens ..................1 Dropdown Dashboard ................2 Care and Use of Your Thermostat ............5 QUICK START Selecting Your Desired Temperature and Mode ........6 Using the Fan Button ................6 Using the Override Button .............. - Page 6 Table of Contents ALERTS ..................... 21 View Current Alerts ..............22 Reset Alerts ................22 Set/Edit Reminders ..............22 Service Information (Who To Call For Service) ......22 DISPLAY .................... 23 Active Brightness ..............24 Idle Brightness ................24 Night Dimmer ................24 Maintenance ................
- Page 7 Table of Contents SETTINGS ...................38 Thermostat Name ................42 Available Modes ................42 SD Card (Import and Export) ............42 GENERAL SETUP ................42 Units (F or C)..................42 Language ..................43 Smart Recovery On/Off..............43 AUTOMATED DEMAND RESPONSE .............44 INSTALLATION SETTINGS ..............58 Heat & Cool Stages................58 Heat &...
- Page 8 Table of Contents WI-FI ....................64 Enabled ...................65 Status ....................65 Setup ....................65 Local API ..................65 Secure API ..................66 SKYPORT .....................69 Account ..................69 EMERGENCY HEAT ................70 INSTALLATION INSTRUCTIONS ............71 Remove & Replace the Old Thermostat ..........71 Wire Connections ................72 The Thermostat Backplate ..............73 Explanation Of the Thermostat Dip Switches........74 Sample Wiring Diagrams ..............75 TROUBLESHOOTING...
-
Page 9: Get To Know Your Thermostat
Get To Know Your Thermostat Home Screen Home Screen Indoor Humidity Reading Outdoor Temperature Backlit ColorTouch Display (If optional accessory is used or connected to Skyport) Drop Down Connectivity Symbol Dashboard Connectivity Symbol Table Button Warmer Not connected Button to Wi-Fi SD Card Connected to local Slot... -
Page 10: Dropdown Dashboard
Get To Know Your Thermostat Dropdown Dashboard (The contents of your Dashboard may vary) The Dropdown Dashboard displays temperature, humidity, and other Wi-Fi Drop Down readings. It will also show the high and low readings of the day. Connection Dashboard Button Icon Wi-Fi Drop Down... - Page 11 Get To Know Your Thermostat Equipment Runtimes This screen allows you to view daily heating and cooling runtimes and can show details about which stages were active. To view one week of runtime data, press menu > information > view runtime graphs Weather This screen only appears when...
- Page 12 Get To Know Your Thermostat Alerts This screen shows some information about any active alerts. More information about alerts as well as resetting active alerts can be founds at menu > alerts. Thermostat Information T8900 Commercial This section contains four different screens that allow easy viewing of the thermostat model number, firmware...
-
Page 13: Care And Use Of Your Thermostat
Get To Know Your Thermostat Care and Use of Your Thermostat Pencils, pens and other sharp objects should never be used on your thermostat; these may damage your touchscreen. Only use your finger tip to press the touchscreen buttons. Use a soft, damp cloth to clean the screen. DO NOT USE ABRASIVE CLEANERS OR CLEANERS THAT CONTAIN SOLVENTS. -
Page 14: Quick Start
Quick Start - Temperature, Modes & Fan Selecting Your Desired Temperature and Mode Press to adjust temperature Cool Setpoint The Heat or Cool Setpoint is the Warmer temperature the room has to Button reach before heating or cooling will turn on. (Without regard Cooler to deadband) -
Page 15: Using The Override Button
Quick Start - Override Using the Override Button OVERRIDE NOTE: Override may only be used when the thermostat is set to Program RUN or Holiday ON modes. Override Unoccupied Operation - During programmed, unoccupied periods, pressing the OVERRIDE button will force the thermostat into Occupied 1 settings. When the OVERRIDE button is pressed, a timer screen will appear and allow the user to choose from 30 minutes to up to 4 hours of override time. - Page 16 Quick Start - Set Time & Date NOTE: When the thermostat is connected to a Skyport account, the Time & Date are automatically synchronized to the Skyport Cloud, including automatic Daylight Savings adjustments. Set Time & Date Your time zone is selected in the Skyport web application. Set Current Time Use AM/PM - ON Set Current Date...
-
Page 17: Setting The Time
Quick Start - Set Time & Date Setting the Time Press then to scroll down. MENU Press Set Time & Date Press Set Current Time (12:00 AM) min + hr + Press to set the current time. hr - min - Press when finished. -
Page 18: Setting The Date
Quick Start - Set Time & Date Setting the Date Press Set Current Date 6/1/2013 Press to set the current month and year. Press the day on the calendar Press BACK when finished. Daylight Savings Setup Turn Daylight Savings Daylight Savings Time - OFF Time on or off. -
Page 19: Connecting To Wi-Fi
Quick Start - Connect to Wi-Fi Connect to Wi-Fi (from initial start up) When power is connected to the thermostat and it has not been configured to connect to a Wi-Fi Access point, the following message appears: Wi-Fi Set Up No Wi-Fi access points are configured for your thermostat. - Page 20 Quick Start - (from menus) Connect to Wi-Fi MENU Press MENU Press DOWN Press Wi-Fi • Wi Fi Setup Press Wi-Fi Setup Select the access point from the list that you want to connect to. Enter the password for the Wi-Fi Access Point and press NEXT. Select automatic setup and press NEXT.
- Page 21 Quick Start - (from menus) Connect to Wi-Fi Although there is more than one way to create a Skyport account, the steps below illustrate creation from a browser. If the thermostat is connected to the local Wi-Fi Access Point, but not yet joined to a Skyport account, you may join the thermostat to an account by doing the following: Select MENU from the thermostat’s home screen.
-
Page 22: Schedule
Main Menu Buttons - Schedule Schedule View My Schedule Edit My Schedule Unoccupied Settings Mode (Auto) Auto Heat Cool Heat Setpoint (55˚ ) Cool Setpoint (85˚ ) Allow Setpoint Changes (No) -
Page 23: View My Schedule
Main Menu Buttons - Schedule This thermostat features up to 3 Occupied time periods per 24 hour day. Schedule View My Schedule Press a day of the week to view its settings. This may be repeated for each day. Edit My Schedule Press and select day(s) to program Select individual day(s) Select groups of day(s) -
Page 24: Unoccupied Settings
Main Menu Buttons - Schedule Edit My Schedule (Continued) Adjust Mode, Start Time, Stop Time, and Heat and Cool Setpoints to desired settings. The Time Period May also be Enabled or Disabled. Un-check the enabled box for Time Periods you don’t want to use. Press DONE when finished. -
Page 25: Fan Settings
Main Menu Buttons - Fan Settings Fan Settings Fan - Auto Who To Call For Service Occupied Fan State (Auto) Auto Fan Purge - OFF View Runtime Graphs Preoccupancy Purge Time (15 mins) -
Page 26: Fan On/Off Auto
Main Menu Buttons - Fan Settings The fan may be set to run continuously during Heat, Cool, Auto, and Occupied modes. A Preoccupancy Fan Purge Fan Settings schedule may also be set. Press to turn fan On to run continuously or Auto for fan to run only with heating or cooling. -
Page 27: Screensaver
Main Menu Buttons - Screensaver Screensaver Screensaver - OFF Who To Call For Service Screensaver Setup View Runtime Graphs Screensaver Turn On Delay Screensaver Type Slideshow Digital Clock Analog Clock Change Image After... Use Theme Images - Off Randomize Slideshow - Off Show Clock - OFF Home Screen Info - OFF Screensaver Preview... -
Page 28: Screensaver Preview
Main Menu Buttons - Screensaver The Screensaver allows you to create custom slideshows. Screensaver Screensaver - OFF Screensaver - ON Screensaver Setup Screensaver Turn On Delay (5m) How long after a button press for the Screensaver to appear. 1, 3, 5, or 30 minutes Screensaver Type (Slideshow) Slideshow, Digital Clock, Analog Clock... -
Page 29: Alerts
Main Menu Buttons - Alerts Alerts View Current Alerts Reset Alerts Reset Air Filter Alert Reset UV Lamp Alert Reset Hum. Pad Alert Set/Edit Reminders Service Call Reminder - OFF Days Until Service Call (0 days) Air Filter Reminder - OFF Set Max Filter Runtime (300 hrs) Set Max Filter Days... - Page 30 Main Menu Buttons - Alerts The alerts let you know when your system needs service. Alerts View Current Alerts View and reset current Alerts will appear service alerts here. on the bottom bar of the Home Screen. Press to view and reset current alerts.
-
Page 31: Display
Main Menu Buttons - Display Display Active Brightness Idle Brightness Night Dimmer Auto Night Dimmer - OFF Set Idle Brightness (20%) Set Dimmer Schedule Maintenance Screen Cleaning Touch Calibration... -
Page 32: Active Brightness
Main Menu Buttons - Display The display brightness options may be adjusted in this menu. Display Active Brightness (80%) You may select how bright the backlight is while the thermostat is active. The display is active for 3 minutes after last touch, it then goes Idle. Idle Brightness (30%) You may select how bright the backlight is while the thermostat is idle. -
Page 33: Maintenance
Main Menu Buttons - Display Maintenance Maintenance allows you to clean and calibrate the touch screen. Screen Cleaning Screen Cleaning Mode disables the touch feature for 15 seconds so the screen may be cleaned without altering any settings. Use a soft cloth without solvents or abrasive cleaners Touch Calibration Under normal circumstances, the touchscreen should not need to be calibrated. -
Page 34: Preferences
Main Menu Buttons - Preferences Preferences User Interface Themes Custom Wallpaper Heat/Cool Indicator Heat/Cool Indicator OFF Taskbar red/white OFF Room Temp red/blue OFF Mode Status red/blue OFF Sound Options Beep - OFF Beep Sound... -
Page 35: User Interface Themes
Main Menu Buttons - Preferences You may set the type of background that appears on the thermostat Preferences Home Screen. User Interface Themes (ocean) This thermostat has several high quality background themes to choose from. NOTE: At 7pm, the background will change to an evening scene. At 7am it will return to a daytime scene. -
Page 36: Humidity
Main Menu Buttons - Humidity Humidity Humidification Settings Humidify setpoint (0%) Humidify with heat - OFF Run fan w/humidity demand - OFF Dehumidification Settings Dehumidify setpoint (99%) Run A/C to dehumidify - OFF Maximum Overcool (2°) Reheat - OFF Dehumidify only when cooling - ON... - Page 37 Main Menu Buttons - Humidity The Humidity feature allows the thermostat to control a humidifier or use your air conditioner to dehumidify the space. Humidity IMPORTANT: D/H Output Usage must be set for Hum or Dehum for these settings to take effect. See: D/H Output Settings on page 61.
-
Page 38: Holidays
Main Menu Buttons - Holidays Holidays Holiday Schedule - OFF Edit Holidays Preset Holidays... -
Page 39: Holiday Schedule On/Off
Main Menu Buttons - Holidays The Holiday Schedule allows the Color Touch Screen to follow a fully customizable preset, weekly, monthly, and yearly holiday program. The thermostat will Holidays stay in Unoccupied settings while Holiday is active. Holiday Schedule - OFF Press to turn Holiday Schedule On or Off. - Page 40 Main Menu Buttons - Holidays Edit Holidays (Continued) Deselecting Holidays You may deselect a holiday simply by pressing on it. Press BACK to save your changes and return to the Holiday menu. If you choose to deselect a holiday that is part of a Custom Repeating Program, the screen below will appear.
-
Page 41: Preset Holidays
Main Menu Buttons - Holidays Edit Holidays (Continued) Editing Repeating Holidays (continued) You may now delete all repeating custom holidays in this group by pressing the ON box to uncheck your selection. Press SAVE to return to Holiday editing screens. Preset Holidays You may choose from several standard preset holidays to observe. -
Page 42: Security
Main Menu Buttons - Security Security Auto Screenlock Auto Screenlock - OFF Set Passcode (1m) Lock After... Allow fan/mode changes - NO Allow setpoint changes - NO Allow override - NO Setpoint Limits Setpoint Limits - OFF Minimum Cool Setpoint Maximum Heat Setpoint... -
Page 43: Auto Screenlock
Main Menu Buttons - Security Security settings may be set to limit or prevent changes to your thermostat. Security Auto Screenlock Auto Screenlock - OFF NOTE: Auto Screenlock - ON Code must be set before Auto Screenlock Set Passcode can be turned on. (code not set ) Use keypad to enter and confirm passcode. -
Page 44: Information
Main Menu Buttons - Information Information View Runtime Graphs Last 7 Days - Cooling Last 7 Days - Heating Last 7 Days - Override Delete Runtime Data Who To Call For Service... -
Page 45: View Runtime Graphs
Main Menu Buttons - Information This button contains valuable service and system runtime information. Information View Runtime Graphs Track your system’s runtime/energy usage. Last 7 Days - Cooling Press the information icon to learn more about each graph *NOTE: The runtime graphs are updated Last 7 Days - Heating at 12:00 AM each day. -
Page 46: Settings
Main Menu Buttons - Settings Settings Thermostat Name Available Modes All Modes Including Auto Heat and Cool Heat Only Cool Only SD Card Import Settings from SD Card Export Settings to SD Card General Setup Units Fahrenheit Celsius Language English Spanish/Espanol French/Francais Smart Recovery - ON/OFF... - Page 47 Main Menu Buttons - Settings Settings (Continued) Installation Settings Timers & Deadbands Min Heat/Cool Difference 1st Stage Deadband 2nd Stage Deadband 2nd Stage Deadband 2nd Stage Timer 2nd Stage Turnoff Point Deadband Setpoint Continued...
- Page 48 Main Menu Buttons - Settings Settings Installation Settings D/H Output settings Fan Off Delay Sensor Settings Control Source Thermostat sensor only Wired sensor only Average all wireless sensors Average wired/thermostat Average wireless/thermostat Average all available sensors Wireless Sensors Add New Sensor Remove sensor Aux in Use Use as outdoor sensor...
- Page 49 Main Menu Buttons - Settings Settings Installation Settings (Continued) Test Outputs Dealer Information Dealer Name Contact Name Dealer Phone Dealer Email Dealer Website Upgrade Firmware Delete Custom Images Factory Defaults Restart Thermostat...
- Page 50 Main Menu Buttons - Settings Thermostat heating and cooling options are found in this menu Settings Thermostat Name Use keypad to name your thermostat. The name is displayed on the Home Screen. (Up to 14 characters) Name appears here Available Modes (all) Choose the desired modes the thermostat will use: Heat, Cool, Heat &...
-
Page 51: Installation Settings
Main Menu Buttons - Settings General Setup (Continued) Language (en) English Spanish/Español French/Français Smart Recovery - OFF Smart Recovery - ON Smart Recovery turns on the heat or cool before the Occupied start time to bring the room temperature to the Occupied setpoint at the start of the Occupied time period. - Page 52 Main Menu Buttons - Settings Overview Automated Demand Response Touch Screen thermostats support the handling of specific signals from the utility provider. The utility generated signals carry pricing information and/or setback actions that alter the comfort settings of the thermostat in order to reduce energy usage on demand.
- Page 53 Main Menu Buttons - Settings The Demand Response configuration page, shown below, is where the thermostat is configured to respond to the energy provider’s signals. It also sets operational parameters for the thermostat. The left column of the ADR configuration page allows or prevents access by the utility.
- Page 54 Main Menu Buttons - Settings The right column of the ADR configuration page is where the occupant adjusts the operational parameters for ADR. The utility may send up to 3 types of ADR signals to Skyport. These are: 1) Pricing for the cost of energy, 2) An Offset to the occupants’ comfort setpoints, and 3) a signal to enforce discrete or Static setpoints.
- Page 55 Main Menu Buttons - Settings Selecting the Overview tab of the ADR page will cause a summary of ADR events to be displayed. Office - Configuration...
- Page 56 Main Menu Buttons - Settings Automated Demand Response Utility and Program setup must be done at the Skyport Cloud Services account. From the thermostat Home Screen, press the ‘Menu’ button, then select ‘Settings” . From the above screen the ‘Automated Demand Response’ button is pressed.
- Page 57 Main Menu Buttons - Settings Selecting the ‘Price Dependent Action’ button allows the user to determine what action is taken when the price rises above the set threshold. In the above example; if the price threshold is exceeded, the thermostat will invoke the ‘Offset Setpoints’ configured for an ADR event until the event is over.
- Page 58 Main Menu Buttons - Settings The user may limit the maximum Cooling Setpoint.
- Page 59 Main Menu Buttons - Settings The user may limit the minimum Heating Setpoint.
- Page 60 Main Menu Buttons - Settings The user may adjust the ADR Cooling ‘static’ Setpoint.
- Page 61 Main Menu Buttons - Settings The user may adjust the ADR Heating ‘static’ Setpoint.
- Page 62 Main Menu Buttons - Settings The user may adjust the ADR Cool offset. During an ADR event the cooling setpoint will be adjusted by the amount of degrees configured in this step.
- Page 63 Main Menu Buttons - Settings The user may adjust the ADR Heat offset. During an ADR event the heating setpoint will be adjusted by the amount of degrees configured in this step.
- Page 64 Main Menu Buttons - Settings When an ADR event is pending, and hasn’t started yet, there will be a yellow leaf on the top bar. This will be accompanied by associated text as shown below. During an ADR event there will be a green leaf on the top bar. This will be accompanied by associated text as shown below.
- Page 65 Main Menu Buttons - Settings If a Warmer or Cooler button is pressed during an active ADR event, then the user is presented with this opt-out screen. If a pricing triggered ADR event is enabled, there will be a green leaf on the top bar along with the actual cost of energy.
-
Page 66: Heat & Cool Stages
Main Menu Buttons - Settings Installation Settings Heat & Cool Stages (1h1c) Heat & Cool Stages (1h1c) Up to 2 Stages Cooling and 4 stages Heating. Compressor Stages (1h1c) Only available when Up to 2 compressors. dip switch is set for Heat Pump operation. - Page 67 Main Menu Buttons - Settings Installation Settings (Continued) Timers & Deadbands (Continued) The Deadband is the number of degrees or minutes that the thermostat waits before it initiates the stages of heating or cooling. 1st Stage Deadband Specifies the minimum temperature difference between the room temperature and the desired setpoint before the first stage of heating or cooling is allowed to turn on.
-
Page 68: D/H Output Settings
Main Menu Buttons - Settings (Continued) Installation Settings D/H Output Settings Allows the D/H output to be used for Humidification or Dehumidification. D/H output usage (dehum) IMPORTANT: D/H Output Usage must be set for Hum or Dehum before any settings will take effect in the Humidity Main Menu. -
Page 69: Fan Off Delay
Main Menu Buttons - Settings (Continued) Installation Settings Fan Off Delay (0s) Runs the fan for a short time after Cooling or electric strip heat turns off to increase system efficiency. (0 - 120 Secs.) Sensor Settings Control Source (thermostat ) The thermostat allows multiple wired or wireless sensor accessories to be connected/paired to the thermostat. -
Page 70: Wired Sensor
SENSOR terminals to detect a Condensate overflow switch or a fault/alarm signal. Note that on ClimateMaster equipment, the condensate overflow sensor is connected to the control board such that an actual condensate overflow event causes... -
Page 71: Dealer Information
Main Menu Buttons - Settings Dealer Information A Dealer may enter their company contact information for the customer to use when they need service. This will appear when the “Who To Call For Service” button is pressed in the Information Menu. Use the keyboard to enter your information. -
Page 72: Wi-Fi
Main Menu Buttons - Wi-Fi Wi-Fi Enabled Wi-Fi Status Wi-Fi Setup Choose Network Password Entry Local API Option Local API - OFF API Protocol HTTP HTTPS... - Page 73 Main Menu Buttons - Wi-Fi Wi-Fi Wi-Fi Enabled Press to enable/disable Wi-Fi connectivity Wi-Fi Status It is here that you will find helpful information regarding the connectivity myoffice status of your thermostat, including the thermostat’s ID. Wi-Fi Setup Choose your network from the list and enter Network Name 1 the network password.
-
Page 74: Local Api
Main Menu Buttons - Wi-Fi This is the default with the local API OFF . • Local API - OFF • API Protocol (http) To turn on the HTTP Local API select Local API • Local API - ON • API Protocol (http) Press BACK to return to previous screen. - Page 75 Main Menu Buttons - Wi-Fi Upon pressing BACK, the screen will look like this. • Local API - OFF • API Protocol API Protocol (https) (http) • Basic Auth User PRESS • Basic Auth Password API Protocol (http) • Basic Auth User Select Basic Auth User, and enter (64 remaining) the appropriate information...
- Page 76 Main Menu Buttons - Wi-Fi • Basic Auth Password Select Basic Auth Password and (64 remaining) enter the appropriate information on the screen below and press DONE to save. Shift 123!? SPACE BACK Basic Auth Password DONE The last step is to turn the Local API on as shown below. •...
-
Page 77: Skyport
Main Menu Buttons - Skyport Skyport Skyport Services - ON Weather Updates - ON Skyport Account Skyport Account Pressing this button will let you know if you are paired with a Skyport account. If not, then you may follow prompt and instructions to create an account and add the thermostat to the account. -
Page 78: Emergency Heat
Main Menu Buttons - Emergency Heat The Emergency Heat function is only available if your thermostat is set to control a Heat Pump. Emergency Heat To initiate the Emergency Heat feature, Press the Emergency Heat button. During Emergency Heat operation the thermostat will turn on the fan and auxiliary stages of heat when there is a demand for heat. -
Page 79: Installation Instructions
Installation Instructions Remove and Replace the old thermostat To install the thermostat properly, please follow these step by step instructions. If you are unsure about any of these steps, call a qualified technician for assistance. • Assemble tools: Flat blade screwdriver, wire cutters and wire strippers. -
Page 80: Wire Connections
Installation Instructions Wire Connections If the terminal designations on your old thermostat do not match those refer to the chart below or the wiring on the new thermostat, diagrams that follow. Install on the new Wire from the old thermostat Function Function thermostat terminal... -
Page 81: The Thermostat Backplate
Installation Instructions The TouchScreen thermostat backplate NOTE: The backplate does not fully cover a full size vertical junction box. The ACC-WPLWH ClimateMaster Wallplate or a single-gang, horizontally mounted junction box would SENSOR be needed for that type of installation To remove the thermostat backplate:... -
Page 82: Explanation Of The Thermostat Dip Switches
Installation Instructions Explanation of Thermostat Dip Switches Dip switches are located on the back of the thermostat GAS/EL ELEC SENSOR This dip switch configures the thermostat to control a conventional gas/electric system or a heat pump. If your GAS/EL GAS/EL system is anything other than a heat pump, leave this switch set for GAS/EL.* *For some commercial heat pumps, this switch may need... -
Page 83: Sample Wiring Diagrams
Installation Instructions - Sample Wiring Diagrams Single Stage Heat Pump with AUX Heat Dip Switch Settings GAS/EL ELEC SENSOR Note: Do not clip jumper JW1 on CXM board... - Page 84 Installation Instructions - Sample Wiring Diagrams Dual Stage Heat Pump with AUX Heat and ClimaDry Dip Switch Settings GAS/EL ELEC SENSOR Note 1: Make sure to select 2 compressor stages via MENU > Settings > Installation Settings > Heat & Cool Stages > Compressor Stages Note 2: If using the integral con- O/W2...
- Page 85 Installation Instructions - Sample Wiring Diagrams 1 Stage Heat, 1 Stage Cool (with wired remote sensor) Dip Switch Settings GAS/EL ELEC SENSOR 10K NTC Thermistor ACC-TSEN or ACC-DSEN HVAC Equipment Notes: 1) Connect the two wires from the sensor to the two SENSOR terminals. To enable the function, set MENU >...
- Page 86 Installation Instructions - Sample Wiring Diagrams 2 Stage Heat, 2 Stage Cool (with condensate overflow) Dip Switch Settings GAS/EL ELEC SENSOR Condensate Switch (optional) open = normal closed = condensate pan full Notes: HVAC 1) Make sure to select 2 heat and 2 cool stages via Menu > Equipment Settings >...
-
Page 87: Troubleshooting
Troubleshooting • SYMPTOM: The thermostat touchscreen buttons are not responsive. CAUSE: The touchscreen is out of calibration. REMEDY: Remove the thermostat from the backplate. Push the thermostat back onto the backplate, while keeping your finger pressed firmly against the center of the touchscreen, until the Calibration screen appears. -
Page 88: Warranty
Warranty One-Year Warranty - This Product is warranted to be free from defects in material and workmanship. If it appears within one year from the date of original installation, whether or not actual use begins on that date, that the product does not meet this warranty, a new or remanufactured part, at the manufacturer’s sole option to replace any defective part, will be provided without charge for the part itself provided the defective part is returned to the distributor through a qualified servicing dealer. - Page 89 Patents Issued & Pending P/N 88-1359 Rev. 01 03/30/20...
