- Page 1 User Guide Frequency Standard QFS-106 Model QFS-106 P/N 0150060XX Revision D October 2017 Brandywine Communications 1153 Warner Ave (714) 755 1050 (714) 755 0175 http://www.brandywinecomm.com MANUAL P/N 900000034 REV D...
- Page 2 FCC PART 15, CLASS A VERIFICATION INFORMATION TO THE USER FOR CLASS A DIGITAL DEVICE WARNING: This equipment has been tested and found to comply with the limits for Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 3 Revision History REVISION DATE COMMENTS 10-26-04 Original release of QFS-106 user guide. 12-14-04 Revision of the rear panel and mechanical outline drawings. 08-03-05 Revision of Section 3.1. 02-14-11 Illustrations of fuse installation 10-24-17 Corrected Fuse Ratings MANUAL P/N 900000034 REV D...
-
Page 4: Table Of Contents
3.1 Unpacking ....................8 3.2 Installation ....................8 3.3 Connections ....................8 Operation ..........................10 4.1 Powering the QFS-106 ................10 4.2 Loss of Input Signal ................10 4.3 Loss of Output Signal ................10 Calibration ..........................11 Diagrams ..........................12... -
Page 5: Overview
Controlled Crystal Oscillator (OCXO) or a free running Rubidium Oscillator. Also, the QFS-106 has various power supply options. The QFS-106 may use either AC or DC input power supplies. The QFS-106 provides six output channels of a single reference frequency, typically 10 MHz. The QFS-106 has six individually buffered low phase noise outputs. -
Page 6: Specifications
Specifications I/O and Environmental (Rear Panel) SPECIFICATION DESCRIPTION Internal Reference OCXO Stability 1 x 10 at -30° to -60°C Oscillator OCXO Aging 5 x 10 per year Rubidium Stability ±1 x 10 at 0 to 50°C Rubidium Aging 5 x 10 per month Reference Input Label... -
Page 7: Switch And Indicator (Front Panel)
2.2 Switch and Indicator (Front Panel) SWITCH/INDICATOR COLOR DESCRIPTION POWER SWITCH –– Used to switch the unit on and off POWER LED GREEN Indicates that the unit has primary power OUTPUT MONITOR 1 LED GREEN Indicates that Output 1 is present OUTPUT MONITOR 2 LED GREEN Indicates that Output 2 is present... -
Page 8: Unpacking And Installation
• 1 power cord • 1 power mating connector (DC voltage only) Note the power connection on the rear of the QFS-106 chassis. Please take note of the voltage displayed near this power connection. If the AC or DC voltage setting is incorrect, use a small screw driver to remove the fuse holder. - Page 9 Units Figure 1 Daisy-Chain Interconnection When daisy-chaining multiple QFS-106 units, these units should be connected as shown in Figure 1. This configuration ensures that all outputs are accurately locked to a common reference with minimal injection of the phase lock loop noise.
-
Page 10: Operation
Operation Powering the QFS-106 Once all the connections to the QFS-106 have been made, apply power to the unit by switching the power switch to the on position. The power switch is located on the rear panel of the unit. The Power LED and Output Monitor LEDs (1 –... -
Page 11: Calibration
Calibration The QFS-106 is a free running standard that requires periodic recalibration. The unit must be calibrated against a frequency standard that is at least ten times more accurate than the oscillator fitted in the QFS-106 unit. Therefore OCXO oscillator units must be calibrated against a rubidium reference. Rubidium oscillator units must be calibrated against a cesium frequency standard or GPS disciplined rubidium. -
Page 12: Diagrams
Diagrams FIGURE DESCRIPTION 1-Page 13 QFS-106 Front Panel (AC and DC Models) 2-Page 14 QFS-106 Rear Panel (AC Model) 3-Page 15 QFS-106 Rear Panel (DC Model) 4-Page 16 QFS-106 Mechanical Outline (AC Model) 5-Page 17 QFS-106 Mechanical Outline (DC Model)
