  • Page 1 NA346 Series Network Appliance User’s Manual...
  • Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd.
  • Page 3 Safety Approvals CE Marking  FCC Class B  FCC Compliance  This equipment has been tested and complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 When handling boards and components, wear a wrist-grounding strap, available  from most electronic component stores. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. ® Windows is a trademark of Microsoft Corporation. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.

  • Page 5: Table Of Contents

    Table of Contents Section 1 Introduction ............1 1.1 General Description ....................1 1.2 Features ........................... 1 1.3 Specifications ........................ 2 1.3.1 Block Diagram ....................2 1.3.2 Specifications ....................3 1.4 Dimensions and Outlines ..................5 1.5 I/O Outlets ........................6 Section 2 Hardware and Installation ........
  • Page 6 3.7 Boot Menu........................40 3.8 Save & Exit Menu ....................... 44 Appendix A LAN Bypass Configuration ....... 53 About LAN Bypass ......................53 Appendix B WDT Timer for System Reset ......55 WDT (Watchdog Timer) ....................55 Appendix C Warning.............. 57...

  • Page 7: Introduction

    NA346 User’s Manual Section 1 Introduction This chapter contains general information and detailed specifications of the NA346 Series Network Appliance Server. It contains the following sections: General Description  Features  Specifications  Dimensions and Outlines  I/O Outlets ...

  • Page 8: Specifications

    NA346 User’s Manual Specifications 1.3.1 Block Diagram Introduction...

  • Page 9: 1.3.2 Specifications

    NA346 User’s Manual 1.3.2 Specifications Model NA346 SBCs SBC8A346 Form Factor Desktop Chassis Steel Material Chipset Processor/Cac Intel® Celeron® N3350 1.1GHz/2C/2M/6W BIOS AMI 128Mbits PnP Flash BIOS with function of BIOS redirected to COM port System 1 x DDR3L SO-DIMM socket, up to 8GB none-buffer none-ECC / ECC, Memory up to1866MHz Super I/O...
  • Page 10 NA346 User’s Manual Linux kernel (Ubuntu 15.10/Fedora 23/Yocto 64 bit/Centos6.9&7.3/FreeBSD or latest version) Environmenta Operating temperature: 0°C ~ 60°C Storage temperature: -20°C ~ 70°C 10% ~ 90% non-condensing NOTE: All specifications and images are subject to change without notice. Introduction...

  • Page 11: Dimensions And Outlines

    NA346 User’s Manual Dimensions and Outlines The following diagram shows you dimensions and outlines of the NA346 Series. Unit: mm Introduction...

  • Page 12: I/O Outlets

    NA346 User’s Manual I/O Outlets Locate front and rear panel I/O outlets on the NA346 Series server to connect serial and Ethernet interface devices. LAN ports HDMI USB 3.0 GPO LED LAN Bypass Power LED HDD LED Reset Button Console...
  • Page 13 NA346 User’s Manual LAN Bypass LED  While running the LAN Bypass function, the LED always lights up. Reset  It is for reset the system to reboot your computer instead of turning off the power switch. It is a better way to reboot your system for a longer life of the system’s power supply. Tact Switch (GPI) ...
  • Page 14 NA346 User’s Manual This page is intentionally left blank Introduction...

  • Page 15: Hardware And Installation

     4 x Plastic stand for stack-up  If you cannot find this package or any items are missing, please contact Axiomtek distributors immediately. If you order any optional components, the package might contain those additional hardware or documents accordingly.

  • Page 16: Memory Module (So-Dimm)

    NA346 User’s Manual Memory Module (SO-DIMM) The main board supports one DDR3L-1866 SO-DIMM slot with maximum of up to 8GB non-ECC memory. The following steps show you how to install the memory modules: Push down each side of the SO-DIMM slot. Align the memory module with the slot that the notches of memory module must match the slot keys for a correct installation.

  • Page 17: Board Layout

    NA346 User’s Manual Board Layout zJP1 JP11 COM1 BAT1 COM2 SDIMM1 SATA1 JP10 LAN4 LAN3 LAN2 LAN1 LED1 Hardware and Installation...
  • Page 18 NA346 User’s Manual BOTTOM Hardware and Installation...

  • Page 19: Jumper Settings

    And remove jumper clip from 2 jumper pins to open. Below illustration shows how to set up jumper. This section provides the information about jumpers and connectors of NA346 Series. Properly configure jumper settings on the main board in this appliance to meet your application purpose.

  • Page 20: Rtc/Cmos Clear Jumper (Jp1 & Jp2)

    NA346 User’s Manual 2.4.1 RTC/CMOS Clear Jumper (JP1 & JP2) Use this jumper to erase and restore CMOS memory and BIOS setting. Put jumper clip to pin 2-3 for a few seconds then move it back to pin 1-2. By doing this procedure CMOS data resets to its safe default settings.

  • Page 21: Tact Sw1 Function Selection Jumper (Jp9)

    NA346 User’s Manual Note: If the jumper setting is “Low Level GPO”, LAN Bypass function will still be started even when power supply is normally input. The default setting is “High Level GPO” that LAN Bypass function is not working when power supply is normally input. 2.4.3 TACT SW1 Function Selection Jumper (JP9) Description...

  • Page 22: Connectors

    NA346 User’s Manual Connectors Signals go to other parts of the system through connectors. Loose or improper connection might cause problems, please make sure all connectors are properly and firmly connected. Here is a summary table which shows all connectors on the hardware. Connectors Label DC Jack for 12VDC Power Input...

  • Page 23: Mini Pcie Full & Half Connector (Cn4/Cn5)

    NA346 User’s Manual 2.5.1 Mini PCIe full & half connector (CN4/CN5) The CN4 is mini PCIe half, it supports SATA/USB2.0 single. The CN5 is mini PCIe full, it supports SATA/USB2.0 single and PCIe for optional, with SIM slot CN6 Signal Signal PCIE_WAKE0_N +3.3VSB...

  • Page 24: Lan Port (Lan1~Lan4)

    NA346 User’s Manual 2.5.2 LAN Port (LAN1~LAN4) Signal Signal MDI0+ MDI2+ MDI0- MDI2- MDI1+ MDI3+ MDI1- MDI3- 100 LAN LED (Green)/ 1000 LAN LED (Amber) Active LED (Orange) 2.5.3 USB3.0 Port0 ~ Port1 Connector (CN9) Signal Signal USB_POWER USBP0N USBP0P Ground (GND) SSRX0N SSRX0P...

  • Page 25: Hdmi (Cn8)

    NA346 User’s Manual 2.5.5 HDMI (CN8) Signal Signal HDMI_DATA2+ HDMI_DATA2- HDMI_DATA1+ HDMI_DATA1- HDMI_DATA0+ HDMI_DATA0- HDMI_CLK+ HDMI_CLK - HDMI_SCL HDMI_SDA HDMI_HTPLG 2.5.6 Serial Port1 (For Console) (COM1) Signal Signal RTS1 DTR1 TXD1 RXD1 DSR1 CTS1 2.5.7 Serial Port2 (COM2 for Optional) RS-232 RS-422 RS-485...
  • Page 26 NA346 User’s Manual This page is intentionally left blank Hardware and Installation...

  • Page 27: Ami Bios Setup Utility

    NA346 User’s Manual Section 3 AMI BIOS Setup Utility The AMI BIOS provides users with a built-in setup program to modify basic system configuration. All configured parameters are stored in a battery-backed-up RAM (CMOS RAM) to save the setup information whenever the power is turned off. This chapter provides users with detailed description about how to set up basic system configuration through the AMI BIOS setup utility.

  • Page 28: Main Menu

    NA346 User’s Manual Main Menu When you first enter the setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options. They are described in this section. The Main BIOS Setup screen is shown below. System Language ...
  • Page 29 NA346 User’s Manual System Date/Time  Use this option to change the system time and date. Highlight System Time or System Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time is entered in HH:MM:SS format.

  • Page 30: Advanced Menu

    NA346 User’s Manual Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: Trusted Computing ...
  • Page 31 NA346 User’s Manual Trusted Computing  This screen provides the function for specifying the TPM settings. Configuration Use this item to enable or disable control TPM function. AMI BIOS Setup Utility...
  • Page 32 NA346 User’s Manual NCT6102D Super IO Configuration  You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 33 NA346 User’s Manual Serial Port 1 Configuration This option specifies the base I/O port address and Interrupt Request address of serial port 1. The Optimal setting is 240h/IRQ4. AMI BIOS Setup Utility...
  • Page 34 NA346 User’s Manual Serial Port 2 Configuration This option specifies the base I/O port address and Interrupt Request address of serial port 2. The Optimal setting is 248h/IRQ10 AMI BIOS Setup Utility...
  • Page 35 NA346 User’s Manual NCT6102D HW Monitor  This screen monitors hardware health status. AMI BIOS Setup Utility...
  • Page 36 NA346 User’s Manual Serial Port Console Redirection  AMI BIOS Setup Utility...
  • Page 37 NA346 User’s Manual Console Redirection Settings Terminal Type This item allows you to select the target terminal type. Configuration options: ANSI, VT100 and VT-UTF8. Bits per second This item allows you to setup the data transfer rate for the console port. The default value is 115200.
  • Page 38 NA346 User’s Manual Stop Bits This item allows you to select the data bits. The configuration options: 1 and 2. Flow Control This item allows you to select flow control for console redirection. The configuration options: None, Hardware and Software. VT-UTF8 Combo Key Support Use this item to “Enabled”...
  • Page 39 NA346 User’s Manual CPU Configuration  This screen shows the CPU Configuration, and you can change the value of the selected option. Socket 0 CPU Information AMI BIOS Setup Utility...
  • Page 40 NA346 User’s Manual CSM Configuration  This screen shows the CSM Configuration, and you can enable/disable option ROM execution settings. WDTO Trigger BIOS AMI BIOS Setup Utility...
  • Page 41 NA346 User’s Manual Network AMI BIOS Setup Utility...
  • Page 42 NA346 User’s Manual USB Configuration  Use this item for further setting USB port configuration. Legacy USB Support Due to the limited space of the BIOS ROM, the support for legacy USB keyboard (in DOS mode) is by default set to Disabled. With more BIOS ROM space available, it will be able to support more advanced features as well as provide compatibility to a wide variety of peripheral devices.

  • Page 43: Chipset Menu

    NA346 User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus： North Bridge  South Cluster Configuration ...
  • Page 44 NA346 User’s Manual South Cluster Configuration  AMI BIOS Setup Utility...

  • Page 45: Security Menu

    NA346 User’s Manual Security Menu The Security menu allows users to change the security settings for the system. Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled). User Password This item indicates whether a user password has been set (installed or uninstalled). AMI BIOS Setup Utility...

  • Page 46: Boot Menu

    NA346 User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. You can select any of the items in the left frame of the screen to go to the sub menus： Boot Configuration  Boot Option Priorities ...
  • Page 47 NA346 User’s Manual Boot Option Priorities  You could set the system boot order of the legacy devices in this group. You could set the system boot order in option #1 UEFI or Disabled. AMI BIOS Setup Utility...
  • Page 48 NA346 User’s Manual Hard Drive BBS Priorities  AMI BIOS Setup Utility...
  • Page 49 NA346 User’s Manual Boot Option Priorities  AMI BIOS Setup Utility...

  • Page 50: Save & Exit Menu

    NA346 User’s Manual Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values.  Save Options  Default Options  Boot Override Save Options Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and return to Main Menu.
  • Page 51 NA346 User’s Manual Discard Changes and Exit Select this option to quit Setup without making any permanent changes to the system configuration and return to Main Menu. Select Discard Changes and Exit from the Save & Exit menu and press <Enter>. Select Yes to discard changes and exit. Save Changes and Reset When you have completed the system configuration changes, select this option to save changes.
  • Page 52 NA346 User’s Manual Discard Changes and Reset Select this option to quit Setup without making any permanent changes to the system configuration. Select Discard Changes from the Save & Exit menu and press <Enter>. Select <Yes> to discard changes and reset system. Save Changes When you have completed the system configuration changes, select this option to save changes.
  • Page 53 NA346 User’s Manual Discard Changes Select this option to quit Setup without making any permanent changes to the system configuration. Select Discard Changes from the Save & Exit menu and press <Enter>. Select <Yes> to discard changes and reset system. AMI BIOS Setup Utility...
  • Page 54 NA346 User’s Manual Default Options Restore Defaults It automatically sets all Setup options to a complete set of default settings when you select this option. The Optimal settings are designed for maximum system performance, but may not work best for all computer applications. In particular, do not use the Optimal Setup options if your computer is experiencing system configuration problems.
  • Page 55 NA346 User’s Manual Restore User Defaults It automatically sets all Setup options to a complete set of User Defaults when you select this option. Select Restore User Defaults from the Save & Exit menu and press <Enter>. AMI BIOS Setup Utility...
  • Page 56 NA346 User’s Manual Boot Override UEFI : Built-in EFI Shell AMI BIOS Setup Utility...
  • Page 57 NA346 User’s Manual P1: AXIOMTWK Corp. AMI BIOS Setup Utility...
  • Page 58 NA346 User’s Manual This page is intentionally left blank. AMI BIOS Setup Utility...

  • Page 59: Appendix Alan Bypass Configuration

    LAN Bypass Configuration About LAN Bypass What is the LAN by-pass meant for NA346 Series It doesn’t have any down time in network connections for two other network segments (LAN1 and LAN2) when any fetal errors occur to this device.
  • Page 60 NA346 User’s Manual This page is intentionally left blank. LAN Bypass Configuration...

  • Page 61: Appendix Bwdt Timer For System Reset

    NA346 User’s Manual Appendix B WDT Timer for System Reset WDT (Watchdog Timer) The hardware supports the WDT (Watchdog Timer) function. While time-out happens after a defaulted period, the WDT will reset the system. Note: Please refer to BIOS “WDT function selection”. Note: If you need sample codes, please contact our FAE directly.
  • Page 62 NA346 User’s Manual This page is intentionally left blank. WDT Timer for System Reset...

  • Page 63: Appendix C Warning

    NA346 User’s Manual Appendix C Warning This is a class A Product. In a domestic Environment this Product may cause radio  interference in which case the user may be required to take adequate measures. It will be danger if battery is incorrectly replaced. Replacing only with the same or ...
