- Page 1 SW-UNM-16FE2GC-16POE 16 Fast Ethernet Ports PoE + 2 Giga Combo User Manual Ver 1.0...
-
Page 2: Table Of Contents
CONTENTS Chapter 1 Product Introduction ....................2 1.1 Product Overview ......................2 1.2 Features ..........................2 1.3 Package Contents ......................2 Chapter 2 External Component Description ................. 3 2.1 Front Panel ........................3 2.2 Rear Panel ........................4 Chapter 3 Installing and Connecting the Switch ..............5 3.1 Installation ......................... -
Page 3: Chapter 1 Product Introduction
Chapter 1 Product Introduction Congratulations on your purchasing of the PoE Ethernet Switch. Before you install and use this product, please read this manual carefully for full exploiting the functions of this product 1.1 Product Overview The 16-Port Fast Ethernet + 2G Combo PoE Ethernet Switch provides the seamless network connection. -
Page 4: Chapter 2 External Component Description
Chapter 2 External Component Description 2.1 Front Panel The front panel of the Switch consists of series of LED indicators, 16 Fast Ethernet RJ-45 ports, 2 Giga Combo RJ-45 ports and 2 SFP ports a shown as below. Figure 1 - Front Panel Fast Ethernet RJ-45 ports (1~16): Designed to connect to the device with a bandwidth of 10Mbps or 100Mbps. -
Page 5: Rear Panel
COLOR STATUS STATUS DESCRIPTION Power on Power Green Power off A device is connected to the port Link/Act Green A device is disconnected to the port (1~16) Flashing Sending or receiving data A device is connected to the port Link/Act Green A device is disconnected to the port (17, 18T/S) -
Page 6: Chapter 3 Installing And Connecting The Switch
Chapter 3 Installing and Connecting the Switch This part describes how to install your PoE Ethernet Switch and make connections to it. Please read the following topics and perform the procedures in the order being presented. 3.1 Installation Please follow the following instructions in avoid of incorrect installation causing device damage and security threat. -
Page 7: Power On The Switch
Attach the mounting brackets on the Switch’s side panels (one on each side) and secure them with the screws provided. Figure 5 - Bracket Installation Use the screws provided with the equipment rack to mount the Switch on the rack and tighten it. -
Page 8: Connect Sfp Module To The Switch
3.3 Connect SFP module to the Switch Connect the SFP port to a SFP module. For the Switch, if an SFP transceiver (purchased separately) is installed in a slot and has a valid link on the port, the associated RJ45 port will disabled and cannot be used. -
Page 9: Appendix: Technical Specifications
Appendix: Technical Specifications General IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, Standards IEEE802.3az, IEEE802.3at, IEEE802.3af 10BASE-T: UTP category 5 cable (maximum 100m) 100BASE-TX: UTP category 5,5e cable Network Media (Cable) (maximum 100m) 1000Base-T: UTP category 5, 5e,6 cable (maximum 100m) 16 Fast Ethernet Auto-Negotiation ports, 2G Number of Ports Combo Link/Act... - Page 10 www.morrelltelecom.com sales@morrelltelecom.com morrelltelecom...
