Chapter 1 Product Introduction Congratulations on your purchasing of the PoE Ethernet Switch. Before you install and use this product, please read this manual carefully for full exploiting the functions of this product 1.1 Product Overview The 24FE + 2GE + 2SFP Port PoE Ethernet Switch provides the seamless network connection.
Chapter 2 External Component Description 2.1 Front Panel The front panel of the Switch consists of series of LED indicators, 24 10/100Mbps RJ-45 ports, 2 10/100/1000Mbps RJ-45 ports and 2 SFP ports a shown as below. Figure 1 - Front Panel 10/100Mbps RJ-45 ports (1~24): Designed to connect to the device with a bandwidth of 10Mbps or 100Mbps.
COLOR STATUS STATUS DESCRIPTION Power On Power Green Power off A device is connected to the port LINK/ACT Green A device is disconnected to the port (1~24) Flashing Sending or receiving data A device is connected to the port LINK/ACT 25,26T A device is disconnected to the port Green...
Chapter 3 Installing and Connecting the Switch This part describes how to install your Ethernet Switch and make connections to it. Please read the following topics and perform the procedures in the order being presented. 3.1 Installation Please follow the following instructions in avoid of incorrect installation causing device damage and security threat.
Figure 5 - Rack-mountable Installation use the screws provided with the equipment rack to mount the Switch on the rack and tighten it. 3.1.3 Power on the Switch The Switch is powered on by the AC 100-240V 50/60Hz internal high-performance power supply.
