UNILITE ATEX-H2 Quick Start Manual

FEATURES
• Powerful 225 Lumen white Cree LED, 6500k
• Intrinsically safe for use in hazardous locations
• Durable rubber coated construction
• 90° Rotating angling head
• Silicone lined non-slip headband included
• Easy press rubberised micro switch
• Polycarbonate lens and smooth reflector
• Safety release valve to allow hydrogen gases to escape
• Secure screw fastening battery compartment
• Chemical and corrosion resistant
• IP67 dust & water proof (1m submersible)
BATTERIES - 3 x AAA Alkaline batteries (not included)
WEIGHT - 130g without batteries
DIMENSIONS - 80 x 50 x 45mm
CERTIFICATIONS
Class I Div 1 Grp ABCD / Class II Div 1 Grp EFG
Class III / Temperature Code T4 IP67
File number: E324236
II 1G Ex ia IIC T4 Ga IP67
DEMKO 14 ATEX 1354X
Ex ia IIC T4 Ga
IECEx UL 14.0059X
Approved - 0518
Approved
Approved
Address: No. 1, Alley 2, Lane 110, Sec. 4, Hsi-Men Road, North District, Tainan City, 704 Taiwan
STANDARDS
UL 913, 7th Edition
CAN/CSA C22.2 No.157-92, Reaffirmed 2014
EN 60079-0:2009
EN 60079-11:2012
EN 60079-26:2007
IEC 60079-0:2007-10, 5th Edition
IEC 60079-11:2011, 6th Edition
IEC 60079-26:2006, 2nd Edition
www.unilite.co.uk
ANSI FL1 Standard
HIGH
LOW
OPERATION
Press top switch to operate.
Switch Sequence:
HIGH > LOW > OFF
ACCESSORIES
- Silicone Lined Adjustable Headband (included)
- Hex Key (included)
BATTERY INSTALLATION
To replace the batteries, use the hex-key provided to unlock the battery
compartment on the back of the headtorch. Ensure that only batteries
of the types specified below are used. Replace batteries taking note
of the polarity markings. Then ensure that the battery compartment is
closed securely.
SAFETY WARNING - Do not attempt to open in hazardous locations.
Unilite cannot be held responsible for the use of mixed or incorrect
batteries in our ATEX products.
Battery Replacement:
Use only battery types below:
AAA Alkaline type
Energizer E92
Duracell MN2400
Panasonic AAA LR03(T)
ADVICE & IMPORTANT INFORMATION!
DO NOT OPEN THIS DEVICE IN HAZARDOUS LOCATIONS.
Only use the battery brands mentioned in these instructions.
This headtorch has not been tested with rechargeable batteries, therefore we do not advise using
rechargeable batteries as it may not be safe.
Always use high-quality Alkaline 1.5v AAA batteries.
Disposable battery life is affected by different battery brands, different ambient temperatures and
different lighting modes. To reduce the RISK OF EXPLOSION do not mix new batteries with used
batteries, or mix different battery brands.
If not using the torch for 3 weeks or more, be sure to remove the disposable batteries to avoid
battery leakage. Battery leaks are not covered under warranty.
Protect batteries from heat, intense sunlight, fire, water and moisture. If a battery is damaged, fluids
can leak out. AVOID contact as this can lead to skin irritation and/or burns. If skin contact occurs,
rinse thoroughly with water. If irritation persists, seek medical advice.
Do not look directly at the LED or shine directly in other peoples eyes.
The LED will become warm when switched on; do not touch and do not place face down on any
surface – risk of fire!
Do not use the device if there is any visible damage to the housing, lens or switch. Check for any
damage before each use.
This product is water proof to IPX7 – 1m SUBMERSIBLE for 30 mins. If the product has been affected
by excessive damp or moisture, remove the batteries and leave the unit open and allow to dry out
completely before using.
If the batteries are installed and the device does not work, try checking for the following: (1) Press
the switch button several times. (2) Check that the batteries are inserted the correct way around
according to polarity markings. (3) Check there is no debris on the contacts that might affect the
battery connection. (4) Check there is no water or dampness in the unit, if so, allow it to fully dry
out and try again.
If the product has been subjected to water deeper than 1m for longer than 30 minutes the warranty
may be void.
This product has a 1 year standard warranty (or extended 2 years once registered online at WWW.
UNILITE.CO.UK/WARRANTY) against manufacturing faults and defects. It does not cover normal
wear and tear, modifications, accidental damage or poor maintenance. Unilite warranties do not
cover battery leaks.
Take care not to let the lens come into contact with hard/sharp objects, damage to the lens will
affect light output.
Children under 12 years of age should only use the product with adult supervision.
Do not disassemble or attempt to modify the product, this will void the warranty and can impair the
intrinsic safety and can be dangerous. Improper use or modification is not covered under warranty.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised
disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
ATEX-H2
225
115M
Lumens
110
79M 12H
Lumens
ATEX-H2
5H
