UNILITE ATEX-RA2 Quick Start Manual

RIGHT ANGLE TORCH FOR USE IN HAZARDOUS LOCATIONS
ENGLISH
Description:
ATEX-RA2 (SF-14) is a portable, hand-held intrinsically safe right angle
flashlight for use in hazardous locations and can be powered with four AA
size alkaline batteries. It has high and low mode operating functions that
allows users to operate for high brightness or long duration lighting.
Features:
» Uses high power CREE LED
» Intrinsically safe for use in
hazardous locations
» High and Low mode functions
» Chemical and corrosion
resistant
Certifications:
Class I Div 1&2 Grp ABCD / Class II Div 1&2 Grp EFG
Class III / Temperature Code T4 IP67
File number: 261379
Gas: II 1G Ex ia IIC T4 Ga
Mine: I M1 Ex ia I Ma
Sira 15ATEX2166X
Gas: Ex ia IIC T4 Ga
Mine: Ex ia I Ma
IECEx SIR 15.0062X
Approved - 0518
Approved
Approved
Standards:
1. UL 913, 2011
2. UL783, 2011
3. CSA C22.2 No.157, Reaffirmed 2012
4. EN 60079-0 : 2012/A11:2013
5. EN 60079-11 : 2012
Warning: Do not open in hazardous locations.
Warning: To reduce the risk of explosion do not mix new batteries
with used batteries, or mix batteries from different
manufacturers or from different types.
Warning: Remove the batteries when unused for a period of time to
prevent battery leakage in the device.
SÉCURITÉ INTRINSÉQUE :
1. AVERTISSEMENT : LA SUBSTITUTION DE C OMPOSANTS.
PEUT C OMPROMETTRE LA SÉCURITÉ INTRINSÉQU E
2. AVERTISSEMENT : AFIN DE PRÉVENIR L'INFLAMMA TION
3. D'ATMOSPHÉRES D ANGEREUSES, NE CHANGER LE S
4. B ATTERIES QUE D ANS DES EMPLA CEMENTS DÉSIGNÉS
NON DANGEREUX.
Unilite International Ltd - The LAB, Winyates Way, Moons Moat North Ind. Est., Redditch, Worcestershire, B98 9FG - UK
Unit 6, Colemeadow Road, North Moons Moat, Redditch, Worcestershire, UK, B98 9PB
T 00[44] 1527 584 344 F 00[44] 1527 584 345
T F
00[44] 1527 584 344 00[44] 1527 584 345
» Industrial strength
polycarbonate housing
» High efficient heatsink
» Screw fastener for safety
precautions
» Built-in gas release vent
» Angled head for use on chest
6. EN60079-26 : 2015
7. IEC 60079-0 : 2011
8. IEC 60079-11 : 2011
9. IEC 6007 9-26 : 2014
10. Directive 2014/34/EU
E sales@unilite.co.uk
E
sales@unilite.co.uk
Operation:
Push front button to operate. Sequence is high then lo w mode.
Installation :
Battery Replacement:
Use only battery types below:
Alkaline type
Energizer E91
Duracell MN1500
Rayovac AL-AA
Varta 4906
Warranty :
1 years Limited W arrant y
Safety Warnings:
1. The screws shall be secured tightly after opening and closing of
the battery compartment.
2. Substitution of components may impair intrinsic safety.
3. Clean the flashlight only with damp cloth to avoid static
electricity.
4. Do not flash the light beam directly into eyes.
5. Always use the device following the regulations of each country
with used batteries or mixed batteries.
Where a static-generating mechanism is identified, such as
repeated brushing against clothing, suitable precautions shall be
taken, eg. the use of anti-static footwear.
W www.unilite.co.uk
W
www.unilite.co.uk
ATEX-RA2
S I S U E D 2 : 0 1 5 0 . 6 0 .
BUTTON
(battery leaks not covered)
1 V1.0
