Modulift CMOD 6 User Instructions

User Instructions
CMOD 6: 6-Point Frame
The CMOD 6-Point Spreader Frame is modular in span and every frame consists of 4 Corner Units and
2 T-pieces, with intermediate Struts that can be bolted into the assembly to achieve different spans.
CMOD 6: 6-Point Frame has an assembled span up to 118" x102".
= Base to
α
sling angle
(BSA)
T-piece Strut
CMOD 6: 6-Point Frame Specification
Rated at a maximum of 8 tonnes WLL.
● ●
Please see Table 2 for WLL at specific spans.
'Base to sling' angle,
● ●
Corner Units and T-Pieces rated at 2 tonnes
● ●
WLL each (8 tonnes combined capacity).
Bolt tightening torque: 44 Pound Foot.
● ●
Spanner size required: 17mm.
Recommended additional equipment: Torque
● ●
Wrench, Podger Spanner and Ring Spanner.
Modulift UK Ltd tel: +44(0)1202 621511 email: sales@modulift.com www.modulift.com
Assembled Frame
Fig. 1 – Typical CMOD 6-Point
Spreader Frame Assembly
α
P1
Span
Corner
, 45 degrees or more.
α
P2
P3–P7
Table 1 – Component List
Part Ref.
Unit
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P10 P9
Description
Corner Unit
(
length 9" each)
T-Piece
(
length 12" x 9" each)
40" Strut
24" Strut
12" Strut
8" Strut
4" Strut
8.5t Shackle
6.5t Shackle
M10 x 30, Grade 8.8, HT Bolts, Nuts & Washers
P8
Weight/item
34lbs
33lbs
18 lbs
12 lbs
8 lbs
6 lbs
5 lbs
5.7 lbs
3.9 lbs
