Thank you for purchasing the Panasonic product.
• Please read these instructions before operating this product and retain
them for future reference.
• Be sure to read "Safety Precautions " (page 2 to 4) before use.
• These Operating Instructions are shared by TY-WPS1, TY-WPSC1,
TY-WP2B1, TY-WPB1, TY-WP2BC1 and TY-WPBC1.
English
DA0920TS3051 -PB
Wireless Presentation System
TY-WPS1
Model No.
WPS Basic Set
TY-WPSC1
WPS USB-C Basic Set
* WPS is an abbreviation of "Wireless
Presentation System".
Operating Instructions
TY-WP2B1
WPS Transmitter Set
TY-WPB1
WPS Transmitter
Safety Precautions
Accessories
Part Names
Connection
Basic Use
Fixing the Transmitter Connection
Transmitter Extension Method (Pairing) 13
Installing the Receiver
Notes on Using Wireless LAN
Request Regarding Security
Specifications
Basic Guide
For business use
TY-WP2BC1
WPS USB-C Transmitter Set
TY-WPBC1
WPS USB-C Transmitter
2
5
6
8
10
12
15
17
19
21
DPQX1530ZD/X1
