Thank you for purchasing the Panasonic product.
• Please read these instructions before operating this product and retain
them for future reference.
• Be sure to read "Safety Precautions" (page 2 to 4) before use.
• These Operating Instructions are shared by TY-WPS1, TY-WPSC1,
TY-WP2B1, TY-WPB1, TY-WP2BC1, TY-WPBC1 and TY-WPR1.
English
DA0920TS5092 -PB
Wireless Presentation System
TY-WPS1
Model No.
WPS Basic Set
TY-WPSC1
WPS USB-C Basic Set
TY-WPR1
WPS Receiver
Operating Instructions
TY-WP2B1
WPS Transmitter Set
TY-WPB1
WPS Transmitter
* WPS is an abbreviation of "Wireless Presentation System".
Safety Precautions
Accessories
Part Names
Connection
Basic Use
Fixing the Transmitter Connection
Transmitter Extension Method (Pairing) 13
Installing the Receiver
Notes on Using Wireless LAN
Request Regarding Security
Specifications
Basic Guide
For business use
TY-WP2BC1
WPS USB-C Transmitter Set
TY-WPBC1
WPS USB-C Transmitter
2
5
6
8
10
12
15
17
19
21
DPQX1530ZF/X1

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TY-WP2B1

Summary of Contents for Panasonic TY-WP2B1

  • Page 1 WPS Receiver Safety Precautions Accessories Part Names Connection Thank you for purchasing the Panasonic product. Basic Use • Please read these instructions before operating this product and retain Fixing the Transmitter Connection them for future reference. Transmitter Extension Method (Pairing) 13 •...

  • Page 2: Safety Precautions

    Safety Precautions ■ WARNING: About AC adaptor Stop using the product immediately when an Do not use an AC adaptor or AC adaptor cable other abnormality or malfunction occurs. than those supplied with this product. Remove the power plug in the case of an Using an AC adaptor or AC adaptor cable other than abnormality.
  • Page 3 Do not damage the AC adaptor and power plug. * Persons with poor bloodstream (due to vascular by damaging, modifying, forcibly bending, twisting, impairment, poor blood circulation, diabetes or strong pulling or bundling them, bringing them close to heat compression) or poor skin sensitivity (elderly persons) appliances, placing heavy items on them, etc.
  • Page 4 Safety Precautions Continued CAUTION: Do not pull or hang the connection cables. Doing so may cause the product to fall over or drop, Do not block the vent hole of this product. resulting in an injury. Do not push the product into a narrow and poorly •...
  • Page 5 (DPVF3516ZA/X1)...1 (see page 15) ..1 • The part numbers of accessories are subject to change without notice. WPS Transmitter Set TY-WP2B1 (The actual part number may differ from the ones WPS Transmitter Transmitter case USB extension cable shown above.) (TY-WPB1) ...2...

  • Page 6: Part Names

    Part Names ■ Receiver (TY-WPR1) Antenna FUNCTION button / LED Used to save a pairing file to the USB memory. Indicator Displays the power supply status, and connection statuses of LAN and USB. Screw holes for mounting bracket (page 15) Used to attach the receiver to the mounting bracket.
  • Page 7 ■ Transmitter (TY-WPB1) HDMI input terminal Connect to an imaging device equipped with HDMI output. USB terminal (Type-A) Connect to a USB power supply device. Main button / LED Switches between on and off of image display. Sub button / LED Switches to the multi-screen mode.

  • Page 8: Connecting The Receiver

    Connection Connect a display device such as a display Before connection, carefully read the operation manual of the device to be connected to this system. and projector to the receiver with HDMI Turn off the power of each device before connecting cable.

  • Page 9: Connecting The Transmitter

    Press the power button of the receiver. USB terminal When a standby screen is displayed on the TY-WPB1 display device, the receiver has completed preparation. HDMI input terminal TY-WPBC1 For the USB-C transmitter, connect the USB terminal (Type-C) to the image output device. Main LED changes from red blinking (connecting) to white illumination (standby).

  • Page 10: Basic Use

    Basic Use Single connection Multi connection This section describes how to display an image using This section describes how to display images one transmitter. simultaneously using multiple transmitters. Images of up to 4 transmitters can be displayed Press the main button of the transmitter simultaneously.
  • Page 11 For details of usage, read “Operating Instructions - The image is added. Functional Manual”. Download the “Operating Instructions - Functional Manual” from the following URL. https://panasonic.net/cns/prodisplays/wps2/ Full screen display Multi-screen display White Sub LED Green...
  • Page 12 Fixing the Transmitter Connection While multiple transmitters are paired and used, you can Other transmitters connect only one transmitter to the receiver and disable switching to another transmitter. This setting prevents accidental transmitter-switching operation. Setting the fixed mode White illumination Red illumination Press and hold the main button of the (standby)
  • Page 13 Transmitter Extension Method (Pairing) Wait for a while until the LED of the receiver blinks in Pairing settings have been made for transmitter and white. Then, pairing starts automatically. receiver of TY-WPS1 Basic Set / TY-WPSC1 Basic Set. “Pairing…” (pairing in progress) is displayed on the Pairing by connecting the receiver and standby screen.
  • Page 14 Transmitter Extension Method (Pairing) Continued Remove the USB memory. Pairing by saving a file to the USB memory Slide the mode switch to the EXT side. Supported device ● Commercially available USB memory devices are supported. (Those with security functions are not supported.) ●...

  • Page 15: Installing The Receiver

    Installing the Receiver Components for receiver mounting bracket Installing on the ceiling or wall Check the following parts are included. Place the base bracket (A-1) aligning it with Base bracket (A-1) ....1 Sheet A (B-1) ......1 the 4 screw holes on the bottom surface of (DPVF3503ZA/X1) (DPVF3507ZA/X1) the receiver.
  • Page 16 For details of installation method, read “Operating Instructions - Functional Manual”. Download the “Operating Instructions - Functional Manual” from the following URL. https://panasonic.net/cns/prodisplays/wps2/ Other installation method The receiver can be installed on the display or projector. ● Installing on the display...

  • Page 17: Notes On Using Wireless Lan

    Notes on Using Wireless LAN Wireless LAN uses radio waves in the 5 GHz bands. The product may not work properly due to strong radio wave from the broadcast station or the radio. Be sure to read and fully understand the following items ●...
  • Page 18 Notes on Using Wireless LAN Continued Declaration of Conformity (DoC) “Hereby, Panasonic Connect Co., Ltd. declares that this product is in compliance with the essential requirements and other relevant provisions of the Directive 2014/53/ EU.” If you want to get a copy of the original DoC of this product, please visit the following website: http://www.ptc.panasonic.de...

  • Page 19: Request Regarding Security

    Request Regarding Security When using this product, take safety measures • A malicious third-party may access your personal against the following incidents. or corporate network without authorization and ● Personal information being leaked via this product engage in the following types of behaviour. ●...
  • Page 20 LAN by yourself, please contact the Panasonic dealer. ● Panasonic Connect Co., Ltd. asks customers to thoroughly understand the risk of using this product without making security settings, and recommends that the customer make security settings at their own discretion and responsibility.

  • Page 21: Specifications

    Specifications ■ ■ Receiver Transmitter Model No. TY-WPB1 TY-WPBC1 Model No. TY-WPR1 Product name WPS Receiver Product name WPS Transmitter WPS USB-C Transmitter Video output HDMI × 1 (HDCP1.4) USB Type-C × 1 Video input HDMI × 1 (HDCP1.4) 1920 x 1080/60p, (HDCP1.4, DisplayPort Alt Mode) Output resolution 3840 x 2160/30p (max.)

  • Page 22: Software License

    Web setting screen of this product. At least three (3) years from delivery of this product, Panasonic Connect Co., Ltd. will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0, LGPL V2.0, LGPL V2.1 or the other licenses with the obligation to do so, as well as the respective copyright...
  • Page 23 Operation is subject to the following two conditions: (1) power supply cord. Any changes or modifications This device may not cause harmful interference, and not expressly approved by Panasonic Corp. of North (2) this device must accept any interference received, America could void the user’s authority to operate including interference that may cause undesired operation.
  • Page 24 Whenever the date of original purchase cannot be satisfactorily determined, the date of manufacture of the unit will be deemed to be the effective date of the warranty. Panasonic reserves the right to audit and reject English any warranty claim that cannot be substantiated.
  • Page 25 Whenever the date of original purchase cannot be satisfactorily determined, the date of manufacture of the unit will be deemed to be the effective date of the warranty. Panasonic reserves the right to audit and reject any warranty claim that cannot be substantiated.

  • Page 26: Trademark Credits

    • USB Type-C and USB-C are trademarks or registered trademarks of USB Implementers Forum. • PressIT is a trademark of Panasonic Holdings Corporation. Even if no special notation has been made of company or product trademarks, these trademarks have been fully respected.

  • Page 27: Customer's Record

    Warranty Service purposes. Model Number Serial Number Panasonic Connect North America Unit of Panasonic Corporation of North America Executive Office : Two Riverfront Plaza, Newark, New Jersey 07102 Authorized Representative in EU:...
