- Page 1 User Manual SUH2E-H2 HDMI 2.0 1x2 Splitter with 4K to 1080p Down-scaling All Rights Reserved Version: SUH2E-H2_2019V1.6...
-
Page 2: Safety Precaution
Statement Thanks for purchasing this product, please read this user manual carefully before using this product. In the constant effort to improve our product, we reserve the right to make functions or parameters changes without notice or obligation. Safety Precaution Do not dismantle the housing or modify the module to avoid electrical shock or burn. -
Page 3: Product Introduction
Product Introduction Thanks for choosing the HDMI 2.0 1x2 Splitter, which can distribute one HDMI input to two outputs. The splitter supports HDMI video resolution up to 4K@60Hz 4:4:4, 1080p 3D, and multichannel audio formats. Besides passing EDID information from the display, there are multiple built-in EDID settings can be selected by the 4-pin DIP switch on the front panel. -
Page 4: Rear Panel
④ EDID: 4-pin DIP switch for EDID setting and HDCP mode selection. Please refer to the EDID Management for more details. ⑤ FW: Micro-USB port for firmware upgrade. Rear Panel DC 5V ① INPUT: Type-A female HDMI input port to connect a HDMI source. ②... - Page 5 setting are shown at the back of the product. EDID Setting Default Priority OUT 1 > 2 4K/30Hz LPCM Priority OUT 2 > 1 4K/30Hz DTS/Dolby 1080p LPCM 4K/60Hz LPCM 1080p DTS/Dolby 4K/60Hz DTS/Dolby Switch Status Video Resolution Audio Format Obtains EDID from the first detected display starting at HDMI output 1>2.
-
Page 6: Firmware Upgrade
Video Resolution Down-scaling The product supports video resolution down-scaling, the 4K input can be automatically degraded to 1080p output for compatibility with 1080p display, shown in the below chart. Input Output Color Resolution Refresh Downscale 1080p Specs Space 3840x2160 4:4:4 Support 1080p@60Hz 4:4:4 3840x2160... -
Page 7: Technical Specification
Technical Specification Video Input Input (1) HDMI Input Connector (1) Type-A female HDMI HDMI Input Resolution Up to 4Kx2K@60Hz 4:4:4 8bit HDMI Standard HDCP Version 2.3, 1.4 compliant Supported Video Output Output (2) HDMI Output Connector (2) Type-A female HDMI HDMI Output Resolution Up to 4Kx2K@60Hz 4:4:4 8bit HDMI Standard... -
Page 8: System Connection
System Connection The following diagram illustrates the typical input and output connection of the splitter: 4K/60 Display 4K/60 Blu-ray 1080p Display 4K@60 4:4:4 HDR Down Scaling...
