Sonelco PCP1276 Quick Start Manual

VOLUME CONTROLLER / BLUETOOTH RECEIVER / STEREO FM TUNER /
DESCRIPTION
Volume controller with touch screen and 3 sound
sources: Aux stereo channel, stereo FM tuner and
BLUETOOTH receiver. It allows memorizing up to
30 stations.
DIRECT ACCESS FUNCTIONS
OF THE PCP1276 CONTROLLER
ON/OFF
The controller PCP1276 is switched on by pressing for a few moments on
the touch screen.
The default screen is that of the FM Radio channel.
The control unit can be switched off in several ways:
1. By pressing the "MENU" key for several seconds
2. By selecting "OFF", on the second screen of the "MENU", and then
"YES"
SOUND SOURCE SELECTION
The PCP1276 remote control has 3 music sources:
• FM Radio
• Bluetooth
• Auxiliary
While on the screen of any of the sources, to select another of the
channels, just press on the text visible at that moment "FM Radio",
"Bluetooth" or "Auxiliary" and the submenu of channels will appear.
When you are on the screen of any of the sources, to select another of
the sources, simply press on the text visible at that time "FM Radio",
"Bluetooth" or "Auxiliary" and the sources sub-menu will appear. Once in
that sub-menu, select the desired source.
VOLUME CONTROL
Within the display of any of the channels, the volume is increased by
pressing the upper arrow and decreased by pressing the lower arrow.
MENU
Pressing the "MENU" key a screen with various adjustable parameters
is displayed. To move between the two available screens, use the upper
and lower arrows.
AUDIO ADJUSTMENTS
Pressing on "Audio" you access a submenu that allows the adjustment of
the following parameters:
• Bass
Regulation between -20 and +20
• Treble
Regulation between -20 and +20
• SuperBASS
Bass boost selection. Its activation is shown with a tick.
• Equalize
Audio format selection with predefi ned equalization.
o Pop
o Rock
o Jazz
o Classic
The selection is shown by a tick
• Mode
Allows audio selection between
o Stereo
o Mono.
When the volume controller is connected to a single speaker or
multiple speakers with a mono amplifi er, the correct setting is "Mono"
To listen to the music in stereo, select "Stereo", although it is
necessary to have 2 speakers, or a multiple of 2, and in this case
with separate amplifi cation for each channel (left and right)
TOUCH SCREEN – PCP1276
• Ideal
Selection of factory default parameters.
FM RADIO SETTINGS
Storing and selecting stations
- Store stations:
Stations can be stored in different ways:
• One by one memorization
• Automatic memorization with AutoSCAN
- Memorization one by one:
• Select "MENU", then "FM Radio", and then "Direct"
• Press the "BACK" key twice to go to the musical channel that is
selected last. If it is not "FM Radio", select that channel as indicated in
the source selection section.
• Once on the "FM Radio" channel use the lower double arrows to
search for the station you want to record. After tuning in to the station
you want to record, press on it for a few seconds. Then, click on "YES".
It will be saved in the memory indicated below, which is the fi rst there
is free. So on you can record the stations one by one in any order you
want.
- Memorization with AutoSCAN
• This function is used to automatically and consecutively search the
stations detected by the tuner. They will be stored in memory.
• Select "MENU", then "FM Radio", then "AutoSCAN"
• The stations will be stored consecutively from 1 to 30.
• To move between the memorized stations, use the lower double
arrows.
• If you want to erase any of the recorded memories, press on the
frequency number and then "YES".
- Station selection
Once the desired radio stations have been recorded, confi gure the FM
Radio by pressing the "Memories" option.
Note: This setting is carried out by the control automatically if the
memories have been saved with "AutoSCAN".
Pressing on "FM Radio", within the "MENU" screen, a new screen is
displayed with the following sections:
- FM Radio
• Memories
Select "Memories" so that, in the sound sources submenu, when
selecting FM Radio, pressing the lower double arrows will change the
stations between those already memorized. This is the usual way of
operation.
• Direct
If you select "Direct", once you return to the sound sources menu and
then to "FM Radio", by pressing the lower double arrows, the change of
stations will be carried out continuously throughout the entire frequency
band, between the stations that go detecting the tuner. This option is
normally only used to search for stations directly and then record them.
BLUETOOTH CONNECTION (WITHOUT APP)
Bluetooth connection for the first time:
The PCP1276 control has a Bluetooth receiver that is visible by
external Bluetooth devices for 1 minute, from the moment it is powered
up.
If you try to connect a device for the first time and this visibility time has
been exceeded, please proceed as follows:
Press the "MENU" key, then press the "Bluetooth" key and then press
"Restart". You will hear a short beep to indicate that the Bluetooth is
visible again for 1 minute.
You will have this time to connect.
On the device you wish to pair with the PCP1276, open the Bluetooth
settings screen. Update the devices and select the SonelcoXXXX.
Once connected, you can send the music from your device.
