Sonelco PCP1275 Manual

4FA039401
1- Display. 2- Auxiliary channel input. 3- Infrared receiver, 4- Channel button
5- Volume increase button, 6- Exit button, 7- Accept button, 8- Volume down
button, 9-Mono/stereo switch, 10- Antenna.

DESCRIPTION

Control with 2 stereo channels and FM radio, auxiliary channel, alarm clock, calendar,
auto-off, and IR receiver for remote control (optional).

CONNECTION

Before connecting the device, make sure that the power supply unit of the system is
switched off. Insert the control into the frame and make the connection according to the
following instructions:
TERMINALS:
2 – Input + 16V power supply.
3 – Output + 16V after switch.
4 – Ground.
15 – Channel 1 input – left..
16 – Channel 1 input – right
NOTE: The wiring of the system must be installed separately from the electricity
mains, according to regulations.

OPERATION

When power is supplied to the control, the time, date and following items are displayed:
Alarm activated – Alarm deactivated, icon not visible
Timer off activated – Timer off deactivated, icon not visible
Infrareds activated – Infrareds deactivated, icon not visible
CONTROL OFF:
In this initial state, the volume Up (5) / Down (8) buttons have no function, Channel
button (4) passes from one audio source to another.
Switch audio on by pressing and holding Exit (6) button.
Enter menu by pressing and holding Accept (7) button.
CONTROL ON:
With the volume adjustment Up (5) / Down (8) buttons.
Change station by pressing and releasing Exit (6) and Accept (7) buttons. Switch
audio off by pressing and holding Exit (6) button.
Enter menu by pressing and holding Accept (7) button.
ENTER MENU:
Once inside the menu, we will browse using the Up (5), Down (8), Accept (7)
and Exit (6) buttons.

MENU:

AUDIO
1 On/Off
1.1. From the initial screen with the Exit (6) button.
1.2 AUDIO/CHANNEL Menu.
1.3 With remote control: press button
2 Change audio source
2.1 Menu: AUDIO/CHANNEL
2.2. From the initial screen with the Channel (4) button.
2.2 With remote control: with audio on, press buttons.
to toggle between channels 1-2, button
between radio and channels 1-2, button
source and the auxiliary channel.
DIGITAL CONTROL WITH FM TUNER - 2 CHANNELS PCP1275
25 – Channel 2 input – left..
26 – Channel 2 input – right.
L – Left speaker output.
R – Right speaker output.
- - Speaker ground
to toggle
to toggle between any audio
3 Change volume
3.1 Menu: with audio on, Up/Down buttons.
3.2 With remote control: Press buttons
4 Change bass tones between 0 and 100
4.1 Menu: AUDIO/BASS.
4.2 With remote control: press BASS +/-
5 Change trebles tones between 0 and 100
5.1 Menu: AUDIO/TREBLE.
5.2 With remote control: press TREB +/-
6 Jazz, Classical, Pop, Rock Equalization
6.1 Menu AUDIO/EQUALIZATION.
6.2 With remote control: sequentially press button
7 Superbass activation/deactivation
7.1 Menu: AUDIO/SBASS.
7.2 With remote control: press button.
8 Change balance between LEFT 50-0, CENTRED, RIGHT 0-50
8.1 Menu: AUDIO/BALANCE.
9 Ideal sound – bass, treble, audio volume, call receiving volume, alarm buzzer
volume (factory preset values)
9.1 Menu: AUDIO/IDEAL
9.2 With remote control: press and hold button.
10 Tuning in the next station
10.1 With remote control: press button
11 Tuning in a specific frequency
11.1 With remote control: sequentially press the button, keying in the
frequency without the decimal sign, from 876 to 1080.
12 Tuning in the frequency saved in a specific memory
12.1 Menu: AUDIO/RADIO/MEM X.
12.2 With the remote control and with the audio on radio, press the memory number
using button to
or pressing buttons
13 Storing the current frequency in a specific memory.
13.1 With remote control: sequentially press button
pressing buttons to
14 Storing the current frequency in the next free specific memory
14.1 With remote control: sequentially press buttons and
audio on radio.

STATUS

1 Change alarm state
1.1 STATE/ALARM/INACTIVE to deactivate the alarm
1.2 STATE/ALARM/BUZZER to activate the alarm with
buzzer, the time and minutes will be selected on the following screens, as well as
the alarm buzzer volume and the days of the week when we want it to be active.
1.3 STATE/ALARM/AUDIO to activate the alarm with the
current audio, the time and minutes will be selected on the following screens,
and the days of the week when we want it to be active.
and
with audio on radio.
and the memory number,
with the
