Page 1
INSTALL GUIDE 660 Series Advanced 2-Way Remote Vehicle Security System WWW.ULTRASTARTERS.COM Technical Support- 866.698.5872 FCC/ID Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 2
INSTALL GUIDE SECURITY SYSTEM PAGE 2 Table of Contents Table of Contents Page 2 Components Wiring Diagram Page 3 Installation Tips Page 4 Pre-Installation Suggestions Installation Suggestions Page 4 Mounting The Module Installing The Program Button Connecting The Starter Disable Connecting The Dome Light Supervision Under Hood Connections Mounting The Siren...
Page 3
INSTALL GUIDE SECURITY SYSTEM PAGE 3 Wiring Diagram Built-in Starter Disable Relay (Normally Connected 87a & 30) 3amp (+) Siren Siren Output (+) Brown 500ma Channel 4 Pink Programmable 500ma Horn/ Channel 5 Wht/Blue Programmable Main Power Constant Power (+) Input Chassis Ground (-) Input Ground...
Page 4
INSTALL GUIDE SECURITY SYSTEM PAGE 4 Recommended Pre-Installation Procedures BEFORE STARTING INSTALLATION: - Discuss the optional system features with the customer. - Take a few minutes to review the installation and owners manuals. - Do a walk around the vehicle and check for any damage. - If installing a LED discuss the placement with customer before installing.
Page 5
INSTALL GUIDE SECURITY SYSTEM PAGE 5 2 Pin Connector (Brown wire with female connectors) Starter Disable harness. See page 4 for installation instructions 14 Pin Connector Brown (+) Siren Output Positive output for siren* Pink Channel 4 Output Programmable - See menu 2** Wht/Blue Channel 5 Output Programmable - See menu 2***...
Page 6
INSTALL GUIDE SECURITY SYSTEM PAGE 6 Quick Start Install Step 1 - Connect All Of the Following Wires 14 Pin Power Connector Black Ground Input System ground input. Yellow Ignition Input Input from vehicles ignition wire. Main Power Input Constant power input. White (+) Park lights Programmable - menu 2, setting 3.
Page 7
INSTALL GUIDE SECURITY SYSTEM PAGE 7 Programming Overview Program mode allows you to adjust the settings and options of your system. Your system has been intelligently designed by installers with years of experience. The system’s default settings do not require any program changes in most cases. However, this system does incorporate a highly advanced programming system that includes 2 menus with numerous options and settings that can be easily adjusted for custom installations and applications.
Page 8
INSTALL GUIDE SECURITY SYSTEM PAGE 8 Menu 1 - User Settings Setting 1- Ignition Auto Lock 1 Ignition Lock & Unlock Enabled 1 Light Flash Doors Lock/Unlock when the key is turned On/Off 2 Ignition Lock Only 2 Light Flashes Doors Lock when ignition key is turned ON only *3 Ignition Auto Lock Disabled 3 Light Flashes Doors do not Lock or Unlock with Ignition key Press the Program Switch 1 time to select setting 1 (This will be confirmed by 1 LED flashes)
Page 9
INSTALL GUIDE SECURITY SYSTEM PAGE 9 Menu 2- Alarm Settings Setting 1 - Car Finder/ 5th Channel 1 Car Finder OFF 1 Light Flash Car Finder Mode Disabled *2 Car Finder ON 2 Light Flashes Car Finder Mode activated when # button is held. **To operate the 5th channel on button #4, setting 7 must be programmed for 5th channel output.
Page 10
INSTALL GUIDE SECURITY SYSTEM PAGE 10 First Car Operation Press Once to Lock the doors and arm the alarm. Hold for Panic Mode. Press a second time and hold for Constant Lock Output. Press once to unlock the doors and disarm the alarm Press and hold for the Trunk / Aux Output Press this button to activate the 4th channel output.
Page 11
INSTALL GUIDE SECURITY SYSTEM PAGE 11 System Service Mode ACTIVATING SERVICE MODE 1. While the ignition is “ON” press and hold the Program Button for five seconds. The park lights will flash and the siren will chirp five times to confirm that the system is in Service Mode. 2.
Page 12
INSTALL GUIDE SECURITY SYSTEM PAGE 12 Diagnostics Alarm Diagnostics If the alarm system is triggered while armed, the system will retain in memory the cause of the trigger. The diagnostics can then be used to determine what the cause of the trigger was. When disarming the alarm, the siren/horn will chirp 3 times instead of the usual 2 times to indicate the alarm had been triggered.
