- Page 1 ™ HoundHunter SD-3200 Operating Guide Please read this entire guide before beginning...
-
Page 2: Table Of Contents
Thank you for choosing SportDOG Brand™. Used properly, this product will help you train your dog effi ciently and safely. To ensure your satisfaction, please review this owner’s manual thoroughly. If you have questions regarding this product’s operation, please see this manual’s Frequently Asked Questions or Troubleshooting section, contact our Customer Care Center at 1-800-732-0144, or visit our website at www.sportdogbrand.com. -
Page 3: Components
Collar Receiver to deliver a harmless stimulation. With proper training, a dog will learn to associate this signal with a command. Like all SportDOG products, this model features adjustable stimulation levels so you can tailor the stimulation level to your dog’s temperament, eliminating the risk of over-correction. -
Page 4: Key Defi Nitions
Key Defi nitions Remote Transmitter: Transmits the radio signal to the Collar Receiver. It is waterproof and can be submerged in water. Intensity Dial: Provides multiple levels of stimulation so you can match the correction to your dog’s temperament. Transmitter Indicator Light: Indicates that a button is pressed and also serves as a low battery indicator. Toggle Switch: This switch is factory-set so that the Remote Transmitter can control up to four Collar Receivers. -
Page 5: Prepare The Remote Transmitter
Step Prepare the Remote Transmitter Inserting 9-Volt Battery 1. Remove the panel from the side opposite of the knob and toggle switch. Note: The screws have been “captured” to allow them to stay in the panel once they have been loosened. 2. -
Page 6: Prepare The Collar Receiver
Step Prepare the Collar Receiver Charger connector placed Charge the Collar Receiver in Collar Receiver Charging Jack 1. Lift the rubber cover protecting the Collar Receiver Charging Jack. 2. Connect the charger connector to the Collar Receiver Charging Jack. 3. Plug the charger into a standard 120-volt AC wall outlet. - Page 7 Receiver Indicator Light Function Indicator Light Response Collar Receiver on – good battery Flashes once per second Collar Receiver on - low battery Flashes once every 4 seconds Continuous Stimulation button pressed Solid in color Momentary (Nick) Stimulation button pressed Single fl...
-
Page 8: Fit The Collar Receiver
Step Fit the Collar Receiver Important: The proper fi t and placement of the Collar Receiver is important for effective training. The Contact Points must have direct contact with your dog’s skin. To ensure a proper fi t, follow these steps: 1. - Page 9 Finding Your Dog’s Recognition Level: Note: Every dog is different and you cannot predict where your dog’s Recognition Level will be. Watch closely for any slight change in behavior that tells you your dog is feeling the stimulation. 1. With the Collar Receiver turned on and properly fi tted to your dog, set the Remote Transmitter’s Intensity Dial at Level 1 and press the Continuous Stimulation Button for 1 to 2 seconds.
-
Page 10: Program The Remote Transmitter
Step Program the Remote Transmitter Note: The Transmitter is factory set to Mode 1. The Mode of the Remote Transmitter can be changed to fi t your type or style of training. To change the mode: 1. Referring to the table below, adjust the Intensity Dial to the Mode you want to use. -
Page 11: Reset The Collar Receiver
Program the Collar Receiver for Step Two-Dog Operation (Mode 2) SportDOG Collar Receivers can be set to respond to either the left or right toggle switch position. A SportDOG Add-A-Dog™ receiver must be purchased to train a second dog in two-dog mode. -
Page 12: Program The Collar Receiver For Up To Four-Dog Operation (Mode 1)
Program the Collar Receiver for Up to Four-Dog Operation (Mode 1) SportDOG Add-A-Dog™ Receivers must be purchased to train additional dogs. 1. Program the Remote Transmitter to Mode 1 (see page 10). 2. Flip the toggle switch to the left position. -
Page 13: Frequently Asked Questions
Can I use the HoundHunter Yes, SportDOG Add-A-Dog™ Collar Receivers must 3200 with more than one dog? be purchased. For 3 or 4-dog operation, the Remote Transmitter must be programmed to Mode 1. -
Page 14: Troubleshooting
Troubleshooting The answers to these questions should help you solve any problem you have with this system. If they do not, please contact the Customer Care Center at 1-800-732-0144 or visit our website at www.sportdogbrand.com. My dog is not responding when •... -
Page 15: Test Light Instructions
Test Light Instructions 1. Hold the Test Light Contacts to the Contact Points. 2. Press a Stimulation Button on the Remote Transmitter. 3. The Test Light will fl ash. Note: At higher Intensity Levels the Test Light will fl ash brighter. Save the Test Light for future testing. -
Page 16: Sportdog Add-A-Dog™ Receivers
Radio Systems Corporation are in violation of FCC regulations and could void the user’s authority to operate the equipment and void the warranty. ™ SportDOG Add-A-Dog Receivers Note: The HoundHunter Transmitter can be used with any SportDOG Add-A-Dog Receiver. ™ ™ Description Part Number...
