INSTALLATION INSTRUCTIONS
FRONT WINCH MOUNTING KIT
Application: 2012 Can Am Renegade 800R
G E N E R A L S A F E T Y P R E C A U T I O N S
W A R N I N G
Impact and Moving Parts Entanglement Hazard
FAILURE TO OBSERVE THESE INSTRUCTIONS COULD LEAD TO SEVERE INJURY OR DEATH
Read installation and operating instructions thoroughly.
Part Number: 89535
1
CAUTION
89548A0

Advertisement

loading

Summary of Contents for Warn 89535

  • Page 1 This information alerts you to potential hazards that could hurt you or others. It is not possible to warn you about all potential hazards associated with this product, you must use your own good judgment.
  • Page 2: Table Of Contents

    Equipment Damage • Always refer to the Installation and Specification Guide, supplied in the winch kit, for all wiring schematics and specific details on how to wire this WARN product to your vehicle. Read installation and operating instructions thoroughly. N O T E S...
  • Page 3: Parts List

    5/16 17 lb. ft. (23.0 N-m) 10mm 30 lb. ft. (40.7 N-m) 7/16 11mm 50 lb. ft. (67.8 N-m) 13mm 75 lb. ft. (101.7 N-m) 89548A0 ©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc.
  • Page 4 Remove the plastic skid plate by removing the outside bottom and inside top bolts. Uninstall the upper bracket by removing the three long bolts and short bolt shown. 89548A0 ©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc.
  • Page 5 Mount the winch using four M8 x 1.25 x 25mm bolts (A7) supplied in this kit and lock washers supplied in winch kit. Pull the winch rope through the front window of the winch mount. (A7) Winch Rope 89548A0 ©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc.
  • Page 6 (A3) on the bottom. After all bolts are in place, tighten all hardware to specifications on page 3. NOTE: Review exploded view on page 3 for gusset orientation. Position winch mount assembly on vehicle. 89548A0 ©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc.
  • Page 7: Installation

    11. Re-attach the front of the plastic skid plate to aluminum bumper the front two bolts only at this time, allowing the bottom of the skid plate to remain loose. 12. Slide the bumper over the front fairlead tabs. 89548A0 ©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc.
  • Page 8 14. Loosely install the lower factory bumper mounting bolts with nuts. 15. Tightenall bumper hardware now. 16. Install the bottom skid plate bolts to finish mounting the plastic skid plate. 89548A0 ©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc.
  • Page 9 17. Loosen the top roller of the fairlead to allow the wire/synthetic rope through. 18. Tighten the top roller down after the loop is through. 19. Mount the fairlead to the front tabs using the fairlead hardware given. 89548A0 ©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc.
  • Page 10 Mount the contactor to the contactor plate (B1) and attach the plate mounting location using the two M8 bolts (A8) provided. Attach the red and black wires to the coordinating color marked contactor terminal, using hardware with contactor. Contactor Contactor plate mounting Contactor plate location 89548A0 ©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc.
  • Page 11: Maintenance/Care

    CARELESS INSTALLATION AND OPERATION CAN RESULT IN SERIOUS INJURY OR EQUIPMENT DAMAGE. READ AND UNDERSTAND ALL SAFETY PRECAUTIONS AND OPERATING INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS PRODUCT. 89548A0 ©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc.
