User Manual
Portable Air Conditioner
Before using your AC Pro Portable Air Conditioner
please read this user manual in its entirety.
MO DEL NUMBERS
APC05AK-A3NNA1C
APC06AK-A3NNA1C
5,000 BTU (DOE rating)
6,000 BTU (DOE rating)
8,000 BTU (ASHRAE rating)
9,999 BTU (ASHRAE rating)
