Summary of Contents for Magellan N630

  • Page 1 N630 User Manual...
  • Page 2 Revision: R00 (October 2019) Trademark All brand and product names are trademarks or registered trademarks of their respective companies. Disclaimer Specifications and documents are subject to change without notice. Note Not all models are available in all regions. Not all features are available on all models. Depending on the specific model purchased, the colour and look of your device and accessories may not exactly match the graphics shown in this document.

  • Page 3: Table Of Contents

    Table of Contents Device Basics ........................4 Getting to Know Your Device ................4 Installing and Charging the Battery Pack .............. 4 Using a Micro-SIM Card ..................6 Using a Memory Card.................... 6 Turning the Device On and Off ................7 Turning On ....................

  • Page 4: Device Basics

    Device Basics Getting to Know Your Device Barcode reader Battery cover ❶ ❿ Accessory screw hole Microphone ❷ ⓫ Rear camera lens and flash LED Charge indicator ❸ ⓬ USB Type A port Front camera lens ❹ ⓭ USB Type C connector Power button* ❺...
  • Page 5 ❶ ❷ ❶ Install the connector side of the battery pack into the battery compartment first (❸), and then place the other side of the battery pack into the compartment (❹). ❹ ❸ ❹ Align the triangular mark on the battery cover with the triangular mark on the device (❺), and then close the battery cover properly (❻).

  • Page 6: Using A Micro-Sim Card

    Using a Micro-SIM Card Depending on the model, your device may use a Micro-SIM card. Remove the battery cover. (Follow the steps in the “Installing and Charging the Battery Pack” section.) Remove the battery pack out of the battery compartment. Locate the Micro-SIM card slot (as shown in the illustration).

  • Page 7: Turning The Device On And Off

    To remove the card, first unmount it from the device: Slide up from the bottom of the Home screen and tap Settings. Tap Storage  Then gently push the top edge of the card inwards to release it, and pull it out of the slot. Replace the battery pack and the battery cover.

  • Page 8: Aeroplane Mode

    To resume the screen, press the Power button briefly and then unlock the device by dragging the Lock icon ( ) upwards. Aeroplane Mode When you are in an aeroplane or in the area where data transferring is not allowed, enable Aeroplane mode.

  • Page 9: Getting Started

    Getting Started Using the Touch Screen To operate your device, touch the screen with your finger. You can perform the following actions: Tap: Touch the screen once with your finger to open items or select on-screen buttons or options.  Tap and hold: Tap and hold on the desired item to open the pop-up menu that contains the available ...

  • Page 10: Home Screen

    Home Screen The Home screen is your starting place for tasks, providing quick access to frequently used applications and settings. To display the app list, swipe up from the bottom of the screen with one finger. To display the Home screen, tap at any time.

  • Page 11: Customising Your Device

    Customising Your Device You can easily customise the device for personal settings through the Settings menu, such as personalising the Home screen, changing the display and sound settings, configuration the connection settings, and more. To access the Settings menu, slide up from the bottom of the Home screen and tap Settings. Cellular Data Connection ...

  • Page 12: Removing A Remembered Network

     Turn off the WIFI function when not in use to save battery power. Removing a Remembered Network Slide up from the bottom of the Home screen and tap Settings. Tap Network & internet  WIFI. Tap and hold the network to remove on the list, and select FORGET. Bluetooth Bluetooth is a short-range wireless communications technology that allows Bluetooth-enabled devices to exchange information over a distance of about 30 feet (10 metres) without requiring a physical connection.

  • Page 13: Reference

    Regulatory Information For regulatory identification purposes, the series is assigned a model number of N630. Marking labels located on the exterior of your device indicate the regulations that your model complies with. Please check the marking labels on your device and refer to the corresponding statements in this chapter.

  • Page 14: Fcc

    Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 15 The device could automatically discontinue transmission in case of absence of information to transmit, or operational failure. Note that this is not intended to prohibit transmission of control or signaling information or the use of repetitive codes where required by the technology. The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems.

  • Page 16: Rf Exposure Information (Sar)

     The DoC letter will be added to the end of the manual. RF Exposure Information (SAR) This device has been tested and meets applicable limits for Radio Frequency (RF) exposure. Specific Absorption Rate (SAR) refers to the rate at which the body absorbs RF energy. SAR limits are 1.6 Watts per kilogram (over a volume containing a mass of 1 gram of tissue) in countries that follow the United States FCC limit and 2.0 W/kg (averaged over 10 grams of tissue) in countries that follow the Council of the European Union limit.

  • Page 17: About The Charger

    Replace only with the same or equivalent type recommended by the manufacturer.  The battery must be recycled or disposed of properly.  Use the battery only in the specified equipment.  USA Contact Information Magellan 279 E Arrow Highway San Dimas, CA 91773 USA +1 909-394-5000 http://www.magellangps.com...
