- Page 1 (WK-1800) Fire Fighting UAV | Airborne Fire Hose | Airborne dry powder fire extinguisher | QUICK START GUIDE V1.0 Aug. 18th, 2020 www.walkera.com...
-
Page 3: Table Of Contents
Table of Contents 1.0 Safety Summary 1.1 Environment 1.2 Check before Flying 1.3 Operation 2.0 About the UAV 3.0 About the Remote Control 4.0 Specifications 8-10 5.0 Check Battery Level 6.0 Charge 10-11 6.1 Charge the remote control 6.2 Charge the aircraft lithium battery 6.3 Laser-assisted sight battery charging 7.0 WK-1800 Software Interface Introduction 12-13... -
Page 4: Safety Summary
WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved 1.0 Safety Summary Use of the WK-1800 may pose certain safety risks. It is not suitable for people under the age of 18. The Safety Summary contains only a portion of the flight safety knowledge, so be sure to read the entire Quick Start Guide carefully to avoid property damage or even personal injury due to improper operation. - Page 5 Walkera be liable for any indirect, consequential, punitive, incidental, special or criminal damages, including damages resulting from your purchase of, use of, or inability to use this product (even if Walkera has been advised of the possibility of such damages).
-
Page 6: About The Uav
Caution Walkera always emphasizes flight safety, and to achieve this, Walkera provides various technical means to assist users in using the aircraft safely and in compliance with local laws and regulations. It is strongly recommended that users download and install the latest firmware from Walkera’s official channels to ensure that the aircraft can work properly with the flight restriction features. -
Page 7: About The Remote Control
WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide 1) Propeller (CW) 2) Propeller (CCW) Aircraft battery 4) GPS antenna 5) Head cover 6) Communication antenna 7) Ranging and obstacle avoidance syste... -
Page 8: Specifications
Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved The default control mode of the remote control is an “American Hand Mode” (left hand throttle). The left stick controls the aircraft’s flight altitude and direction, while the right stick controls the forward, backward and left/right flight direction. - Page 9 WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide PTZ Camera System with 3-Axis Gimbal Video Size 136×98×139mm recording 4K 30fps resolution Weight 452g Photograph 3840×2160 Input voltage resolution Stability Focal length 6.7-134.5mm...
-
Page 10: Check Battery Level
WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved 5.0 Check Battery Level ※ Please turn on the remote control and the aircraft battery level detection switch to check the battery level. Be sure to fully charge the battery for the first time of use. -
Page 11: Charge The Aircraft Lithium Battery
WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide 6.2 Charge the aircraft lithium battery Operating steps 1) Power on: Connect the aircraft to AC mains and turn the power switch on. The charger will sound a “Beep”, the fan will rotate once for self-test, and the LCD will show the following screen. -
Page 12: Wk-1800 Software Interface Introduction
WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved 7.0 WK-1800 Software Interface Introduction In this interface, you can preview the live HD video and photos taken by WK-1800, and dynamically set the parameters of the aircraft, remote control, gimbal and battery. -
Page 13: Prepare The Remote Control
WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide 21) Flight status parameters: 22) Map thumbnail: tap the map thumbnail to quickly switch to the map interface (Before flight, please turn off the aircraft, D-Distance: horizontal distance between the aircraft and and tap “Map Thumbnail”... -
Page 14: Prepare The Aircraft
WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved 9.0 Prepare the Aircraft 9.1 Deploy arms, paddles, GPS antennas Turn the arm fasteners and arm latches inwards in turn, and then expand the arm upwards.Then turn the arm lock to the side and snap it into the arm buckle, then press the arm fastener firmly. -
Page 15: Prepare For Flight
WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide 10.0 Prepare for Flight Before fly the aircraft, please cache the map (turn off the aircraft and tap the “Map Thumbnail” as connected to the Internet to cache the map). -
Page 16: Description Of Gps Signal Indications
WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved 10.4 Description of GPS signal indications The status bar of the APP interface shows that the number of satellites is large and the positioning accuracy is high, indicating that the current GPS signal is strong. - Page 17 WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Manual takeoff Operate the sticks as shown in Figure 11.0-1 to start the motor, then push the throttle stick up to allow the aircraft to take off.
- Page 18 WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved GPS Mode Turn the flight mode switch to the “GPS” position and push the throttle stick back to center. Then, the aircraft will enter the GPS mode.
- Page 19 WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Return To Home Press the RTH button to allow the aircraft to automatically return to home. Power Fig.11.0-9 Horizontal distance between aircraft and Home point >30m a.
-
Page 20: Gimbal Control
WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved 12.0 Gimbal Control The 3-axis gimbal can stabilize the camera, to enable the camera to take stable images even when the aircraftis flying at high speed. -
Page 21: Photo & Video
WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide 13.0 Photo & Video Note: The aircraft cannot be operated by the touch screen until the WK-1800 main screen displays a image transmitted from the aircraft. -
Page 22: Installation Of Airborne Dry Powder Fire Extinguishing Components
WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved 15.2 Installation of airborne dry powder fire extinguishing components The nozzle cap Laser-assisted Sight Power plug Power switch Quick release connector... -
Page 23: App Settings
WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide 15.3 APP settings 2.4G 51.98V 2.4G 51.98V 03:58:45 AUTO Mode Connected Connected 03:58:45 AUTO Mode 5.00 m 5.00 m Photo Video... -
Page 24: Additional Instructions
WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved Operations 2.4G 51.98V Connected 03:58:45 AUTO Mode 1） After the plane arrives at the fire, click on the main interface of the APP"... -
Page 25: Compass Calibration
WK-1800 Walkera All Rights Reserved Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Note: The following diagram is an example of setting the safety distance to obstacle at Hover state in automatic mode: obstacle avoidance is possible ahead. -
Page 26: Remote Control Stick Mode Switch And Stick Calibration
WK-1800 Airborne dry powder fire extinguisher , Fire Hose Fire Fighting UAV Quick Start Guide Walkera All Rights Reserved 17.3 Remote control stick mode switch and stick calibration The remote control stick mode and stick calibration have been set at the factory. Please refer to the following method for mode switching and calibration;... -
Page 27: Instructions For Safe Use Of Battery
2)It is strictly forbidden to use a battery that is not officially supplied by Walkera. If you need to replace the battery, please go to the Walkera official website for purchasing information. Walkera assumes no liability for any battery accidents or flight failures caused by using batteries other than those provided by Walkera. - Page 28 Manufacturer: Guangzhou Walkera Technology Co.,Ltd. Add: No.48 Wantai Rd, Taishi Industrial Park, Dongchong Town, Nansha Dist, Guangzhou, China.511453 Hotline: +86 20-84915115 This manual is subject to update without prior written notice. Please refer to Walkera official website for latest version.
