Summary of Contents for Walkera VOYAGER 4

  • Page 1 DEVO F8W Remote Controller QUICK START GUIDE V1.2 Oct. 18th, 2018 www.walkera.com...
  • Page 2: Table Of Contents

    6.0 Charge the Batteries 7.0 Downloading and Installing APP 8.0 APP Interface Instructions 9.0 Prepare for Remote Controller 10.0 Prepare the VOYAGER 4 11.0 Ready for Flight 11.1 Starting the aircraft / Get binding 11.2 Connect the APP 11.3 GPS Indicator Lights 11.4 Motor Unlock / Lock...
  • Page 3: Get To Know Your Aircraft

    * 1) To avoid property loss and personal injury caused by wrong operation, please read the manual carefully, upgrade the firmware and calibrate the related items by watching the tutorial video at www.walkera.com before using VOYAGER 4. 2) The Maximum flight time of 20 minutes was obtained under test environment.
  • Page 4: Get To Know Your Remote Controller

    Quick Start Guide 2.0 Get to know your Remote Controller DEVO-F8W remote controller built-in 5.8 G WiFi high resolution integration module, with complete function keys, the operation and setting of the aircraft and camera can be completed within the maximum 1.5km communication distance.
  • Page 5: Specifications

    3250g(Battery included) Remote Controller DEVO F8W Main Controller FCS-V4 Receiver DEVO-RX718 Brushless Motor WK-WS-42-002A Brushless ESC Voyager 4 (R/B) Battery 22.2V 4500mAh 10C(6S) LiPo Flight Time About 20mins Working Temperature -10℃~ +40℃ Gimbal Control accuracy Static: ±0.008°; Motion: ±0.08°; Shake-proof: ±0.008°...
  • Page 6: Attention Before Flight

    6.0 Charge the Batteries 1) Connect the charger to the AC power (100 ~ 240v 50/60hz). 2) Only use the walkera charger for your Intelligent Flight Battery and remote controller. Please turn off the intelligent flight battery and remote controller before charging.
  • Page 7: Downloading And Installing App

    APP software supports Android 5.1 and above systems iOS 9.0 and above, Android system please download at Walkera official website (www.walkera.com) or go to Google play to search for Walker Drone or scan the QR code to download and install;...
  • Page 8: Prepare For Remote Controller

    Quick Start Guide 13. The camera zoom control: divided into wide Angle (W) and telescopic (T). 14. Camera Settings : Touch icons it has preview settings, recording settings and so on. Under identical Video Size, the larger the stream Rate, the better the picture quality, anyway, the video transmission distance is shortened accordingly.
  • Page 9: Prepare The Voyager

    Quick Start Guide 10.0 Prepare the VOYAGER 4 The factory default of the aircraft is Travel Mode. Before flying, connect to power, transform the aircraft to Landing Mode, please don't use the outside force. 1. Insert the battery. 2. Power on the remote controller and the aircraft.
  • Page 10: Ready For Flight

    Quick Start Guide 11.0 Ready for Flight Before you plan to fly, please download the map in the APP (turn off the aircraft power, and connect internet, click the "A thumbnail map icon" to download the map.). Place the aircraft in an open outdoor area, with its tail facing the operator. 11.1 Starting the aircraft / Get binding 1.
  • Page 11: Gps Indicator Lights

    Quick Start Guide 11.3 GPS Indicator Lights When the blue LED light (GPS) begin to flash, you can work GPS function. 11.4 Motor Unlock / Lock Motor Unlock After successful code-matching, move the left & right sticks down and toggle them outward, and hold for more than 2 seconds.
  • Page 12: Flight Control

    Quick Start Guide 12.0 Flight Control 1) Make sure that the GPS signal is received (the blue LED light blinks). 2) Only when “Connected” displays on the upper bar of the main interface of the APP, you can perform APP operation. 3) Please unlock motors before takeoff.
  • Page 13 Quick Start Guide Motion mode (Remote Controller Operation) Attention: Manual Manual 1) In the Motion mode, there are Altitude hold, fixed point, brake function, the flight speed is faster (≤8m/s). Motion Motion 2) If the GPS signal is poor or no signal, can only be Altitude hold, Circle Circle but not fixed point.
  • Page 14 Quick Start Guide RETURN TO HOME (Remote Controller or APP Operation) Long press this key(3-5 seconds) Click this key in the APP on the remote controller and the interface and the aircraft aircraft will return automatically will return automatically Horizontal distance between aircraft & Home point>30m a.
  • Page 15 Quick Start Guide Waypoint Flight (APP Operation) Waypoints Flight (APP Operation) Click icon on APP map interface, Click icon on APP map interface, Click icon to enter the waypoint flight interface. Click icon to enter the waypoints flight interface. 1. Click this icon to add waypoint 1.
  • Page 16 Quick Start Guide Control the gimbal (remote controller or APP operation) Three-axis stabilization gimbal makes the camera steady so that it can shoot stable photos even fly with hight altitude. And you can control pitch and horizontal angle of the gimbal by Gimbal stick on Remote Controller or APP Software.
  • Page 17: End Flight

    2. Micro SD card slot: Place the Micro SD card position 3. UART Port: not used 4. USB port: used for upgrading 5. Connection port: used to connect flexible flat cable port Upgrading www.walkera.com Please upgrade online via USB Cable Walkera official website...
  • Page 18: Stick Mode Switch, Stick Calibration And Customize Fixed Id

    Quick Start Guide 14.3 Stick Mode Switch, Stick Calibration and Customize Fixed ID Factory setting of DEVO F8W stick mode & stick calibration has been determined; please refer to the following operation method for switching and calibration. Be sure to switch off the aircraft power or lock motor before operation. Stick Mode Switch 1.
  • Page 19: Intelligent Flight Battery Safety Guidelines

    2) Never use non-walkera batteries. Go to www. walkera.com to purchase new batteries. Walkera takes no responsibility for any damage caused by non-walkera batteries.
  • Page 20 Manufacturer: Guangzhou Walkera Technology Co.,Ltd. Add: No.48 Wantai Rd, Taishi Industrial Park, Dongchong Town, Nansha Dist, Guangzhou, China.511453 Hotline:+86 20-84915115 This manual is subject to update without prior written notice. Please refer to Walkera official website for latest version.
