Triride BASE User Manual And Maintenance page 17

TRIRIDE s.r.l.
MANUFACTURER: TRIRIDE S.R.L.
Registered Office: Via Milano, 18 - 63827 Porto San Giorgio (FM)
Operating Headquarters: Via Massimo D'Antona, 8 - 63812 Montegranaro (FM)
MAXIMUM USER WEIGHT
MAXIMUM TOWABLE WEIGHT
(INCLUDING USER, ACCESSORIES
WHEELCHAIR AND TRIRIDE)
MAXIMUM GRADIENT
APPROACHABLE
DIMENSIONS
WEIGHT
CONDITIONS FOR
WHEELCHAIR
INSTALLATION
MAX SPEED
STEERING SYSTEM
TYPE OF DRIVING WHEEL
WHEEL DIAMETER
TIRE TYPE
TIRE PRESSURE
TREAD WIDTH
DISK BRAKE
BATTERY
BATTERY VOLTAGE
BATTERY WEIGHT
POWER SUPPLY
ELECTRIC MOTOR POWER
DISTANCE BEFORE CHARGE
SURMONTABLE OBSTACLES
MINIMUM BRAKING
DISTANCE AT HIGH SPEED
(1) The maximum load of the wheelchair indicated by the manufacturer must always be observed.
(2) The maximum speed permitted on pedestrian walkways is 6 km/h and on cycle paths is 12 km/h. On private streets and areas not open to the public,
the speed limit may also be above 12 km/h.
(3) Value refers to charged 10.2 Ah battery, with flat terrain and user weight of around 75 kg. On uphill or slopes the autonomy of the battery can be
inferior.
(4) The indications for the wheelchair provided by the manufacturer must always be observed.
(5) The tread width refers to the standard tire and can therefore vary depending on the type of tire fitted.
ManUso_TRIRIDE_eng_r06
TRIRIDE SPECIAL LIGHT
100 kg
(1)
120 kg
Up to 15 %
(4)
Max height: 950 mm
Max width: 460 mm
Max depth: 420 mm
9 kg
From wheelchair width of 320 mm
Up to 6 km/h
(2)
Built-in bearings
Reinforced aluminium wheel
12" o 14"
City or Cross
from 3,00 to 3,50 kPa
57 mm
(5)
Diameter 160 mm
Lithium ion
36V or 48V
2,6 kg / 3,3 Kg
100-240 Vac 50/60Hz 120 w
Max 1000 w
Up to 50 km
(3)
(full charge)
30 - 50 mm (12" - 14" wheel)
1000 mm at 6 Km/h
1500 mm at 12 Km/h
20/07/2020
USER MANUAL AND MAINTENANCE
TRIRIDE SPECIAL COMPACT
100 kg
(1)
120 kg
Up to 15 %
Max height: 950 mm
Max width: 460 mm
Max depth: 400 mm
10,5 kg
From wheelchair width of 320 mm
Up to 6 km/h
Built-in bearings
Reinforced aluminium wheel
12"
City or Cross
from 3,00 to 3,50 kPa
57 mm
Diameter 160 mm
Lithium ion
36V or 48V
2,6 kg / 3,3 Kg
100-240 Vac 50/60Hz 120 w
Max 1350 w
Up to 50/55 km
(full charge)
30 mm
1000 mm at 6 Km/h
1500 mm at 12 Km/h
(4)
(2)
(5)
(3)
Pag. 13 di 49
