Summary of Contents for Triride BASE
- Page 2 “Triride” is registered in the Medical Devices Register of the Health Ministry with the following codes: MODEL MEDICAL DEVICE CODE NO. BASE/PIEGHEVOLE/KIDS 922795 SPECIAL LIGHT 1560509 SPECIAL COMPACT 1560515 SPECIAL L14 1560510 SPECIAL HP16 1560514 PIEGHEVOLE 1560507 T-ROCKS 1776589 TRIBIKE 1776590 MANUFACTURER: TRIRIDE S.R.L.
-
Page 3: Table Of Contents
10. TRIRIDE BATTERY ..........................22 10.1 “Special Models” Battery (from 2019) .................. 22 10.2 Cylindrical Battery for “Base”, “Pieghevole”, “Tribike E” Models.......... 22 10.3 EVO Battery for “Base” Model ....................23 10.4 “Special Models” Battery (old version) ................23 10.5 Battery for “MadMax”... - Page 4 13.4 Storing the Battery ........................ 37 13.5 Further Safety Information ....................38 13.6 Supplementary Information on Battery Use ................. 38 13.7 Transporting Triride ....................... 39 14. MAINTENANCE ..........................40 14.1 Maintenance, Inspection and Checks ................... 40 14.2 Authorised Technical Support ....................41 14.3 Checking Tire Pressure and Changing the Tire ..............
-
Page 5: Introduction
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 1. INTRODUCTION Dear User, Thank you for choosing Triride, a Made in Italy product, following a strong tradition of prestigious products. All TRIRIDE S.R.L. products are compliant with European Council Directive 93/42/CEE concerning medical devices and subsequent updates. -
Page 6: Symbols
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 2. SYMBOLS Graphic symbols are used in the manual and on the device with the meanings indicated in the table below. SYMBOL MEANING NOTES Mark of compliance with Present on the device European legislati on... -
Page 7: Warnings And Safety Precautions
• Do not operate in case of suspected fault or broken casing on the batt ery or control unit; • If you suspect that the appliance is faulty and/or damaged, it must be checked by TRIRIDE S.R.L. specialist staff or personnel authorised by TRIRIDE S.R.L.;... - Page 8 • Do not use the device with uncharged batteries, it can turn off and block. • Triride srl does not assume any responsibility for damage, accident or injury caused by a failure to observe the requirements and safety indications/directives provided in this Manual.
-
Page 9: Precautions Before Using Triride
• check that the ti re pressure of the Triride is suitable and compliant with what is indicated on the ti res and in the “technical specifi cati ons” table in this manual;... -
Page 10: Precautions To Follow During Use Of Triride
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE Triride may only be used by users trained to use the device, and it is essenti al to carefully consider the following warnings/contraindicati ons. The device must be switched on and used only by users trained to use it. - Page 11 • When braking at high speed, it is advisable to try to brake progressively, in order to avoid losing control of the “Triride” and determine a risk of overturning or collision. The IBS - Intelligent Braking System (opti onal) eliminates this risk by automati cally modulati ng braking.
-
Page 12: Further General Recommendations
Only use accessories approved by TRIRIDE S.R.L. Avoid proximity of Triride with fires and open flames. If Triride is exposed to direct sunlight or high (> 41°C) or low (< 0°C) temperatures for extended periods, its components may overheat or become excessively cold. -
Page 13: Purpose
Triride. To connect Triride to a manual wheelchair, the caster wheels are lift ed and a single driving wheel is used instead. This is directly connected to the Triride motor, ensuring constant and effi cient power transmission whilst maintaining all of the other characteristi cs of the manual wheelchair. -
Page 14: Product Description
The Triride att achments vary in diameter from 19 mm to 40 mm. There are also specifi c clamps for wheelchairs with special frames or with free tube forms so that they can be perfectly fi tt ed to most wheelchairs models available. -
Page 15: Triride Label
4. Year of Production 9. RAEE Directive Symbol 5. Model name The label is always placed under the steering fork of Triride. TRX... When requesting spare parts or reporting defects, please provide the details on the label, in particular the device serial number. -
Page 16: Technical Specifications
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 9. TECHNICAL SPECIFICATIONS 9.1 Technical Characteristics of Triride Models TRIRIDE BASE TRIRIDE PIEGHEVOLE MAXIMUM USER WEIGHT 80 kg 80 kg MAXIMUM TOWABLE WEIGHT 120 kg 120 kg (INCLUDING USER, ACCESSORIES WHEELCHAIR AND TRIRIDE) MAXIMUM GRADIENT... - Page 17 TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE MANUFACTURER: TRIRIDE S.R.L. Registered Office: Via Milano, 18 - 63827 Porto San Giorgio (FM) Operating Headquarters: Via Massimo D’Antona, 8 - 63812 Montegranaro (FM) TRIRIDE SPECIAL LIGHT TRIRIDE SPECIAL COMPACT MAXIMUM USER WEIGHT 100 kg...
- Page 18 TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE TRIRIDE SPECIAL L14 TRIRIDE SPECIAL HP L16 MAXIMUM USER WEIGHT 120 kg (36V) / 140 Kg (48V) 140 kg MAXIMUM TOWABLE WEIGHT 140 kg (36V) / 160 Kg (48V) 160 kg (INCLUDING USER, ACCESSORIES...
- Page 19 TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE TRIRIDE MAD MAX TRIRIDE T-ROCKS MAXIMUM USER WEIGHT 140 kg 140 kg MAXIMUM TOWABLE WEIGHT Max. 160 kg Max. 160 kg (INCLUDING USER, ACCESSORIES WHEELCHAIR AND TRIRIDE) MAXIMUM GRADIENT Up to 15 % Up to 15 %...
-
Page 20: Overall Dimensions And Maneuverability
(corridor useful for the change of directi on) The dimensions and measurements shown in the diagrams are indicati ve, calculated with a Triride Base model mounted on a standard wheelchair (Length 950 mm, Width 600 mm, Height 820 mm). These measurements may diff er depending on the Triride model purchased and depending on the size of the user’s wheelchair. -
Page 21: Main Parts Of Triride
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 9.4 Main Parts of Triride Display Display Handlebar Handlebar Control Unit Control Unit Tilti ng Frame Tilti ng Frame Batt ery Batt ery Batt ery Support Batt ery Support Headlight Headlight Wheel Wheel Brake Disk... -
Page 22: Console With Main Controls
DOWN arrow button Electronic brake / IBS* Power button Press for 2/3 seconds until the display turns on. The Triride is ready to use. ON/OFF Press for changing the speed gear on the display from 1 to 5. UP arrow button Zero (0) for neutral gear. -
Page 23: Description Of The Main Features Of "Triride
Triride has been att ached. Depending on the Triride model, the user’s weight and other factors such as the road surface etc. ManUso_TRIRIDE_eng_r06 20/07/2020 Pag. -
Page 24: Ibs - Intelligent Braking System (Optional)
USER MANUAL AND MAINTENANCE 9.7 IBS - Intelligent Braking System (Optional) Triride offers, as an option, an exclusive braking system that increases safety and saves on brake consumption. This system called IBS - Intelligent Braking System, programmable and customizable based on the user’s needs. -
Page 25: Acc - Adaptive Cruise Control (Optional)
USER MANUAL AND MAINTENANCE 9.8 ACC - Adaptive Cruise Control (Optional) Triride’s standard cruise control can be implemented with the ACC system (optional) that allows to keep the speed set on each type of route, even downhill! The advanced electronics automatically maintain the desired and set speed along the routes, in total safety and efficiency. -
Page 26: Triride Battery
2. Battery charger socket 3. ON/OFF switch 4. Charge level indicator 5. Connectors for battery 10.2 Cylindrical Battery for “Base”, “Pieghevole”, “Tribike E” Models. 1. Battery charger socket 2. ON/OFF switch 3. Charge level indicator (push button for activate) 4. Connectors for battery... -
Page 27: Evo Battery For "Base" Model
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 10.3 EVO Battery for “Base” Model 1. Battery charger socket 2. Charge level indicator (push button for activate) 3. ON/OFF switch 4. Connectors for battery 10.4 “Special Models” Battery (old version) 1. Charge level indicator 2. -
Page 28: Battery For "Madmax" Models
Each battery model has a charge status indicator. In general, this indicator is composed of LED lights of different colors. Battery life and the corresponding indication value vary depending on the way the Triride is used, the user’s weight and the type of road course. - Page 29 TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE Below is a diagram of indicator with the corresponding charge residue for each LED lit: 100% Cylindrical Batt ery Cylindrical Batt ery “Special” Batt ery (20/19) Evo Batt ery 100% 100% “Special” Batt ery (old) “MadMax”...
-
Page 30: Battery Connection
By turning the key and removing it, the batery will be locked to the device. To release the battery, turn the key and unlock the battery performing the reverse procedure. WARNING - Always lock the battery before turn on the Triride! ManUso_TRIRIDE_eng_r06 20/07/2020 Pag. - Page 31 TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE Inserti ng the Cylindrical batt ery Inserti ng the EVO batt ery Insert the batt ery in the special housing, paying Insert the batt ery in the special housing from att enti on to the contacts. Secure the batt ery above unti l you hear the locking snap.
-
Page 32: Correct Battery Use
Below, are the main components of Triride and instructions for connecting a manual wheelchair. 11.1 Delivery Triride is supplied completely packaged in a sealed cardboard box to protect it from impact and dust. To avoid breakage during transport, components, such as the battery charger, which may be installed later are packaged separately in the cardboard box. -
Page 33: Contents Of Package
11.3 Contents of package Triride is delivered unassembled with the following components, as illustrated below. 1. Triride (frame complete with wheel, motor, control unit, steering fork and handlebars with electric controls). 2. Tilti ng frame with spring cott er pin, locking clamps and brackets. -
Page 34: Triride Assembly
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 11.4 Triride Assembly Assemble Triride exclusively in a fl at area with wheelchair brake engaged. The positi oning sequence of your Triride is illustrated below. IMAGE STEP/DESCRIPTION Triride clamps installati on on the wheelchair Install the dedicated clamps on the wheelchair following the instructi ons for a correct mounti ng provided by Triride. - Page 35 Watch the video for a correct installati on of the Triride on our website htt p://www.trirideitalia.com/en/faq/ *Step 1 and step 2 must be performed only by qualifi ed staff or authorized by Triride. The other steps can be performed by the user only aft er being instructed by qualifi ed personnel appointed by Triride srl.
- Page 36 3. Switch on the display using the ON/OFF butt on. 4. Acti vate the assisted lift ing system (STEP 7) bringing the Triride into the locking positi on. 5. Lock the ti lti ng frame by inserti ng the pin into one of the three holes, rotati ng the lever sideways and ti ghtening the front screw handle (STEP 8).
-
Page 37: Using Triride
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 12. USING TRIRIDE 12.1 Adjusti ng Handlebars and Frame Tilt IMAGE STEP/DESCRIPTION Adjusti ng handlebars To adjust the height and angle of the handlebar piece, loosen the screws indicated with a 5 mm Allen key. -
Page 38: Switching On And Operating Triride
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 12.2 Switching On and Operating Triride IMMAGE STEP/DESCRIPTION Switching on the battery After inserting the battery into the housing, turn it on using the ON / OFF button. Refer to section 10 for the different battery models. -
Page 39: Charging The Battery
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 12.3 Charging the Battery inizio IMAGE STEP/DESCRIPTION Turn OFF the battery Use the switch to turn the battery OFF. Refer to section 10 for the different battery models. Unlocking and removing the battery Turn the key anticlockwise (if present). Remove the battery from the support as indicated on section 10.6. -
Page 40: Guidelines For Using Lithium Batteries
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 13. GUIDELINES FOR USING LITHIUM BATTERIES • Always charge your batt ery, even when you only travel a few kilometres. There are several reasons for this: 1. You will always have maximum available distance;... -
Page 41: Battery Features
13.3 Battery Charging The Triride battery is charged via a socket on the side of the battery. Only charge the battery using the original charger supplied with Triride. The battery charging time (if used correctly) averages around 4-5 hours. -
Page 42: Further Safety Information
USER MANUAL AND MAINTENANCE 13.5 Further Safety Information The lithium batteries used on the Triride may represent a danger, as they have sufficient potential energy to cause a serious accident in cases of improper use or negligence. TRIRIDE S.R.L. only uses lithium batteries which are considered stable and equipped with safety systems, including an intelligent management system which controls the battery at all times. -
Page 43: Transporting Triride
TRIRIDE S.R.L. guarantees the batt ery for one year, as it is a consumable material. In the case of replacement of the batt ery under guarantee, the new batt ery will have a guarantee equivalent to the guarantee period remaining on the original batt ery. -
Page 44: Maintenance
Regular maintenance signifi cantly reduces the possibility of problems and extends the useful life of the product. To minimise the risk of accidents or damage to Triride, it is very important to always use the Authorised Technical Service for all repairs. -
Page 45: Authorised Technical Support
USER MANUAL AND MAINTENANCE 14.2 Authorised Technical Support Ensure that your Triride is always kept in good conditi on, with the necessary care and maintenance carried out by trained and qualifi ed personnel of the Authorised Technical Service. For all problems, contact the Authorised Technical Service directly, indicati ng the serial number that uniquely identi fi es each appliance, found on the label on the Triride frame. -
Page 46: Cleaning
USER MANUAL AND MAINTENANCE 14.6 Cleaning To clean Triride, only ever use a damp soft cloth, to avoid introducing water into the appliance. Clean the components of the frame with hot water and soap or a neutral, non-abrasive detergent. Dry carefully to remove any excess water. -
Page 47: Troubleshooting
For problems that can be managed under the guarantee, TRIRIDE S.R.L. recommends contacting the reseller/distributor that sold and delivered Triride. TRIRIDE S.R.L. will not be held responsible if Triride malfunctions due to inadequate warehouse storage or improper use. ManUso_TRIRIDE_eng_r06 20/07/2020 Pag. -
Page 48: Activation Of Guarantee
(1) year from the date of first receipt of Triride. In event of faults or defects, TRIRIDE S.R.L. reserves the right to request that the Triride be sent to them along with all components at the customer’s expense to evaluate replacement or repair. -
Page 49: Emc Tables
17. EMC TABLES Guide and manufacturer’s declaration – electromagnetic emissions TRIRIDE is designed to function in the electromagnetic environment indicated below. The customer or user of the appliance must guarantee that it is used in such an environment Emissions test... - Page 50 Field strengths for fixed transmitters, such as base stations for radio telephones (cordless phones) and land mobile radios, amateur radio equipment, AM FM radio transmitters and TV transmitters can not be predicted theoretically with precision.
- Page 51 The customer or the user of TRIRIDE can help prevent electromagnetic interference by ensuring a minimum distance between mobile and portable RF communications devices (transmitters) and TRIRIDE, as recommended below, in relation to the maximum output power of the radiocommunication equipment.
-
Page 52: Accessories
TRIRIDE s.r.l. USER MANUAL AND MAINTENANCE 18. ACCESSORIES The standard equipment of the Triride can be enriched by several opti ons and many accessories, in order to enjoy bett er the new life with Triride. DISCOVER ALL THE ACCESSORIES ON WWW.TRIRIDEITALIA.COM... -
Page 53: Attachments - " Acceptance And Personal Warranty
"Acceptance and approval declarati on". This form must be completed in full and delivered by mail or email to Triride srl for the acti vati on of the warranty. - Page 54 NOTES...
- Page 55 NOTES...
- Page 56 Dealer stamp © TRIRIDE srl. - Via Massimo D’Antona 8 - 63812 - Montegranaro (FM) - ITALY Tel: +39 0733 801405 - Tel/Fax: +39 0733 896964 Mob. +39 327 6266267 - Email: info@trirideitalia.it WWW.TRIRIDEITALIA.COM Triride...
