9. TECHNICAL SPECIFICATIONS

9.1 Technical Characteristics of Triride Models

MAXIMUM USER WEIGHT
MAXIMUM TOWABLE WEIGHT
(INCLUDING USER, ACCESSORIES
WHEELCHAIR AND TRIRIDE)
MAXIMUM GRADIENT
APPROACHABLE
DIMENSIONS
WEIGHT
CONDITIONS FOR
WHEELCHAIR
INSTALLATION
MAX SPEED
STEERING SYSTEM
TYPE OF DRIVING WHEEL
WHEEL DIAMETER
TIRE TYPE
TIRE PRESSURE
TREAD WIDTH
DISK BRAKE
BATTERY
BATTERY VOLTAGE
BATTERY WEIGHT
POWER SUPPLY
ELECTRIC MOTOR POWER
DISTANCE BEFORE CHARGE
SURMONTABLE OBSTACLES
MINIMUM BRAKING
DISTANCE AT HIGH SPEED
(1) The maximum load of the wheelchair indicated by the manufacturer must always be observed.
(2) The maximum speed permitted on pedestrian walkways is 6 km/h and on cycle paths is 12 km/h. On private streets and areas not open to the public,
the speed limit may also be above 12 km/h.
(3) Value refers to charged 10.2 Ah battery, with flat terrain and user weight of around 75 kg. On uphill or slopes the autonomy of the battery can be
inferior.
(4) The indications for the wheelchair provided by the manufacturer must always be observed.
(5) The tread width refers to the standard tire and can therefore vary depending on the type of tire fitted.
ManUso_TRIRIDE_eng_r06
TRIRIDE BASE
80 kg
(1)
120 kg
Up to 10%
(4)
Max height: 950 mm
Max width: 460 mm
Max depth: 420 mm
9,4 kg
From wheelchair width of 320 mm
Up to 6 km/h
(2)
Built-in bearings
Reinforced aluminium wheel
12" o 14"
City or Cross
from 3,00 to 3,50 kPa
57 mm
(5)
Diameter 160 mm
Lithium ion
36V 7Ah or 36V 9Ah
1,4 kg / 1,9 Kg
100-240 Vac 50/60Hz 90 w
Max 720 w
Up to 30/35 km
(3)
(full charge)
30 - 50 mm (12" - 14" wheel)
1000 mm at 6 Km/h
1500 mm at 12 Km/h
20/07/2020
USER MANUAL AND MAINTENANCE
TRIRIDE PIEGHEVOLE
80 kg
(1)
120 kg
Up to 10 %
Max height: 900 mm
Max width: 400 mm
Max depth: 400 mm
9,2 kg
From wheelchair width of 320 mm
Up to 6 km/h
Built-in bearings
Reinforced aluminium wheel
12"
City or Cross
from 3,00 to 3,50 kPa
57 mm
Diameter 160 mm
Lithium ion
36V 7Ah
1,4 kg
100-240 Vac 50/60Hz 90 w
Max 720 w
Up to 30/35 km
(full charge)
30 mm
1000 mm at 6 Km/h
1500 mm at 12 Km/h
(4)
(2)
(5)
(3)
