Eizo eClient SC1 User Manual

Eizo eClient SC1 User Manual

Stand type windows-based terminal
Hide thumbs Also See for eClient SC1:
Table of Contents

Advertisement

Quick Links

Download this manual
Please confirm the version of the software built in eClient, and refer to
the suited User's Manual (Refer to the User's Manual Version List on
next page).
This is the manual for the following software version.
* Microsoft Windows CE: 4.20 Rev. 3.0.2 or later
* Microsoft Terminal Server Client: Ver. 8.0.1 or later
* Ctrix ICA Client Software: Ver. 7.23 or later
- For Administrator -
For Microsoft Windows CE.NET
Version A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eClient SC1 and is the answer not in the manual?

Questions and answers

Related Manuals for Eizo eClient SC1

Summary of Contents for Eizo eClient SC1

  • Page 1 Please confirm the version of the software built in eClient, and refer to the suited User's Manual (Refer to the User's Manual Version List on next page). This is the manual for the following software version. * Microsoft Windows CE: 4.20 Rev. 3.0.2 or later * Microsoft Terminal Server Client: Ver.
  • Page 2 User’s Manual Version List A handling description changes with versions of the software built in eClient. Please refer to below. NOTE • The version of software built in eClient can be checked with a [System]-[ICA] tab of [Terminal Properties]. Microsoft Windows CE .NET Software Manual (This manual)

  • Page 3: Safety Symbols

    Indicates a prohibited action. Indicates to ground for safety. Copyright© 2004 EIZO NANAO CORPORATION. All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.

  • Page 4: Table Of Contents

    1-2. Features ...5 1-3. Package Contents...6 1-4. Controllers & Connectors ...7 2. CONNECTING the eClient SC1 ... 9 2-1. Setting up the eClient SC1 ...9 3. SETTING UP the eClient SC1... 15 4. ADDING & CHANGING A CONNETION NAME... 25 4-1.

  • Page 5: Introduction

    1. INTRODUCTION Thank you very much for purchasing the EIZO eClient SC1. 1-1. General Description The SC1 is used as a thin client, which connects to the terminal service installed Windows Terminal Server (Hereafter defined WTS) as listed below and accesses applications or data provided from the WTS.

  • Page 6: Package Contents

    NOTE • A keyboard is not included. It must be purchased separately. • Please use the enclosed mouse. EIZO NANAO CORPORATION will no be held responsible for accident or damage caused by the use of a mouse manufactured by other companies.

  • Page 7: Controllers & Connectors

    1-4. Controllers & Connectors Controllers Left View Power Button Power Indicator Power Indicator Blue [Procedure to return to the operation mode] - Operate the mouse or keyboard. The monitor is in the power save mode when the power save function of the monitor is set.
  • Page 8 Connectors (1) Power Supply Control Switch (POWER SYNC)…Same with (5) on P.7 (2) Power Connector(AC output) (3) Power Connector(AC input) (4) Ethernet Connector (10 Base-T, 100 Base-TX) (5) Parallel Connector (6) Headphone Connector Microphone Connector (7) PC Card Slot (8) USB Port (Downstream) x 2 (9) DVI-I Output Connector (10) Serial Port (RS-232C) (11) Mouse Connector...

  • Page 9: Connecting The Eclient Sc1

    2. CONNECTING the eClient This chapter explains how to connect the eClient SC1 to a WTS. 2-1. Setting up the eClient SC1 Please observe the following cautions when connecting the SC1. WARNING Place the eClient SC1 on a strong, stable surface.
  • Page 10 Mounting EIZO monitor to the SC1 When using other monitors than EIZO, proceed to step 3. The Monitor Attachment Unit of SC1 supports the EIZO L767, L567, L557, and L367, so EIZO monitor mounted SC1 is available. NOTE • Prepare the following, when mounting a monitor to the SC1.
  • Page 11 (2) Grip both side of the monitor firmly with both hands and adjust the monitor angle as desired. 100 mm x 100 mm For L567, L557, L767 75 mm x 75 mm For L367 Knob position Middle position 2. CONNECTING the eClient SC1 Highest position Lowest position...
  • Page 12 When the power button of SC1 is turned on or off… Power Supply Control Switch (POWER SYNC) OFF (default) 2. CONNECTING the eClient SC1 Power supply for the monitor The monitor’s power supply is linked, and it turns on or off simultaneously.
  • Page 13 • Please remove the lid on the side of the SC1 before connecting a LAN card or a modem card. Plug a keyboard and a mouse into the SC1. When using other devices, connect them to the appropriate connectors. 2. CONNECTING the eClient SC1...
  • Page 14 Analog Output 640 x 480 @60 Hz 800 x 600 @60 Hz 1024 x 768 @60 Hz 1280 x 1024 @60 Hz 2. CONNECTING the eClient SC1 Digital Output 8 bbp 640 x 480 @60 Hz 16 bbp 32 bbp...

  • Page 15: Setting Up The Eclient Sc1

    3. SETTING UP the eClient SC1 This chapter presents how to prepare for a connection with a WTS when the eClient SC1 starts up for the first time. Turn on the eClient SC1. The power indicator turns green and a picture appears on the screen.
  • Page 16 End User License Agreement page is displayed. Read the content and click [Accept] to continue. 3. SETTING UP the eClient SC1...
  • Page 17 In case of the dial-in connection (ICA protocol only) to log on to WTS NOTE [Dial-Up Connection] Telephone Lines eClient RAS Server FTP Server eClient 3. SETTING UP the eClient SC1 Reference page p.18 p.18 p.19 p.20 Go to step 5 * Skip the [Network Properties] settings [Dial-In Connection]...
  • Page 18 (1) Double-click [NE 20001] icon. [IP Address] ...Type the IP address of the unit. [Name Servers]...Type the IP address of each server when DNS or 3. SETTING UP the eClient SC1 Example; In case of connecting with a NE2000 compatible LAN card WINS is used.
  • Page 19 ...Set the connection setting with a wireless LAN card. NOTE • In case of selecting [Obtain an IP address via DHCP], deactivate the built-in LAN by the procedure below. (1) Richt-click [Built-in LAN] icon (2) Select [Disable] in the displayed dialog. 3. SETTING UP the eClient SC1...
  • Page 20 A small window will be displayed on the right bottom of the screen. Clicking an active button of the small window starts the connection listed in the [Current Connections]. To set an automatically start connection when the eClient SC1 boots up, select the [Connect automatically on boot up] check box. Click [Next].
  • Page 21 16 bbp 32 bbp 800 x 600 @60 Hz 8 bbp 16 bbp 32 bbp 1024 x 768 @60 Hz 8 bbp 16 bbp 1280 x 1024 @60 Hz 8 bbp 16 bbp 32 bbp 3. SETTING UP the eClient SC1...
  • Page 22 (1) Select [Internet Options] icon and click [Open]. [General]...Set up the browser. [Connection] ...Set up the connection method to the browser. [Security]...Set up the security for the connection to the browser. [Advanced]...Set up the display method of the browser. 3. SETTING UP the eClient SC1...
  • Page 23 Setup if you are connecting to WTS/Web server by dial-up connection. (1) Select [Dialing] icon and click [Open] icon. [Location name]...Choose the sender’s location (click [New] to add a [Local Settings are:] ...Setup the local settings. new sender’s location). 3. SETTING UP the eClient SC1...
  • Page 24 The “Terminal Connection Manager” dialog box will be displayed after restarting. NOTE • Click [No] to finish the “eClient Setup Wizard” and display “Terminal Connection Manager” on the screen. The setting is not activated until the SC1 is restarted. 3. SETTING UP the eClient SC1...

  • Page 25: Adding & Changing Aconnetion Name

    4. ADDING & CHANGING A CONNETION NAME This chapter shows how to add, delete, and modify connection names to a WTS. All the settings are managed in the “Terminal Connection Manager”. 4-1. Adding a Connection Name These are settings for the server connection. Each protocol has different settings.
  • Page 26 Protocol selection dialog box is displayed. Select the “Microsoft Remote Desktop Client” (RDP). “WTS Connection Wizard” is displayed. (Setup as following the wizard.) (1) Type the connection name and the name of the Server. (2) Setup to enable an Automatic Logon to the WTS after connecting if you want. (3) Select whether to display the Windows desktop screen or start up an application.
  • Page 27 In Use of the ICA protocol Display [Terminal Connection Manager]. Click the [Configure] tab and [Add...] to set the connection information of the WTS. “New Connection” dialog box is displayed on the screen. Select the “Citrix ICA Client” (ICA). “Specify Connection Type” is displayed. (Setup as following the wizard.) (1) Choose a connection type (Network Connection / Dial-In) for the remote application.

  • Page 28: Setting An Autostart Connection

    • Please repeat the step 2 to 3 when you adding another connection name. 4-2. Setting an Autostart Connection This function configures a connection to start automatically each time the eClient SC1 is turned on. (This function is available for a LAN connection.) Select the desired connection name for Autostart Connection and click [Startup...].

  • Page 29: How To Control

    5. How to control This chapter shows how to log on to and log off from a WTS. 5-1. Logging on or off the WTS Logging on to the WTS Turn on the SC1. The “Terminal Connection Manager” dialog box will be displayed. Please follow the instruction depending on the network environment of the SC1.
  • Page 30 The SC1 connects to the WTS and the “Log On to Windows” dialog box is displayed. Enter your [User name] and [Password], and then click [OK] to log on to the WTS. After logging on, the SC1 allows you to use the Microsoft Windows applications running on the WTS.
  • Page 31 Logging off the WTS If your SC1 starts its operation with a desktop: Log off the WTS. (1) Close all the applications. (2) Select [Start] on the taskbar. (3) Select [Shut Down...] and select [Logoff] of the [Shut Down Windows] dialog box.
  • Page 32 If your SC1 starts its operation with an application: Log off the WTS. Close the applications to log off from the WTS. The “Terminal Connection Manager” dialog box will be displayed. If it’s connected through a dial-up, click the active button on the right bottom of the screen.
  • Page 33 Opening/Closing the Local Web Browser Opening the Local Web Browser Turn on the SC1. The “Terminal Connection Manager” dialog box will be displayed. Please follow the instruction depending on the network environment of the SC1. (Contact your system administrator for the connection environment.) (7) If the web server is on the same network (Intranet): Go to step 3.
  • Page 34 Closing the Local Web Browser (SC1) Close the local web browser. Select [Close] on the [File] and close the local web browser. The “Terminal Connection Manager” dialog box will be displayed. If a dial-up connection is made, click the active button on the right bottom of the screen.

  • Page 35: Using The Terminal Properties

    6. USING THE TERMINAL PROPERTIES This chapter presents how to modify all settings of the eClient SC1 using the “Terminal Properties”. To display the “Terminal Properties” during logging on, press F2 in the “Terminal Connection Manager” dialog box. Settings and adjustments of “Terminal Properties”...

  • Page 36: General

    System Software Hardware Network Applicable only for ICA 6-1. General Product Information [General] tab shows the product name, Product ID, Windows CE Revision, version, and Terminal name. Resetting to Default (1) Select the [Reset the terminal to factory-default property settings] check box. (2) The “System Settings Change”...

  • Page 37: Display

    6-2. Display Resolutions / Desktop Colors [Desktop Area, Refresh Frequency and Colors] ...Set the resolution, refresh frequency and colors. The [Test...] ...A test pattern is displayed. NOTE • [High Color] setting after WTS connection can be available only when connecting with WTS, which version is 5.1 or later. •...

  • Page 38: Screen Saver

    Screen Saver [Enable Screen Saver] ...Set the screen saver. Select the check box, and set an [Turn off monitor] ...Set the “Turn off monitor”. Select the check box, and NOTE • Power saving system of the monitor After the “Turn off monitor” idle period passed, the connected monitor shift to the power save mode when the monitor’s power save function is set.
  • Page 39 Dialing [Location name]...Choose the sender’s location (click [New] to add a new sender’s location). [Local Settings are:] ...Setup the local settings. Keyboard [Input Locale] ...Selects a keyboard language. [NumLock Key] ...Enables/cancels NumLock function on start-up. [Check Input Devices]...Enables/cancels checking the connection state of a keyboard and a mouse on start-up.

  • Page 40: Volume And Sounds

    Password [Password] ...This enables password settings on FTP service (p.47) Mouse [Buttons] ...Assigns the primary mouse button and the secondary [Motion] ...Adjusts the speed at which the pointer moves on your Volume & Sounds [Volume] ...Select the check boxes to enable sounds for events, [Sounds] ...Select sounds for each case.
  • Page 41 Date / Time NOTE • Date and time will return to the default settings if the power cord is unplugged. [Date/Time] ...Set date, current time, or time zone. [NTP Server] ...Synchronize time with the NTP Server. Select when to synchronize time with the NTP server (on every boot up or every time clicking the [Synchronize] button.) NOTE...

  • Page 42: Dhcp Settings

    Certificates Lists the certificates stored in the SC1. A certificate can be registered, if an external disk is connected to this product, a certificate file can be imported. NOTE • When using the Secure Gateway, select its certificate and click [Add]. By clicking the button, the certificate can be used.

  • Page 43: Internet Options

    Add-on Add-on lists all application software installed in eClient. To remove software, select it and click [Remove]. NOTE • Neither Microsoft Terminal Server Client nor Citrix ICA Client Software is removed. Internet Options [General]...Setup the browser. [Connection] ...Setup the connection method to the browser. [Security]...Setup the security for the connection to the browser.
  • Page 44 Printers NOTE • The eClient SC1 supports an LPTx port and a COM1 port. • Use a RDP protocol to set the printer’s adjustment. • If you are using the ICA protocol, please refer to the instruction manual of the Citrix MetaFrame.

  • Page 45: Network And Dial-Up Connections

    Network and Dial-up Connections Set up connection information according to the connection method to WTS/Web server (See page 18 for the details). 6. USING THE TERMINAL PROPERTIES...

  • Page 46: Ica Settings (Ica Protocol Only)

    6-6. ICA Settings (ICA Protocol only) NOTE • The settings will affect all the settings with ICA protocol. ICA Client information [ICA Client Software] ...Version of the Citrix ICA Client ICA Client Configurations [ICA Client Configurations] ...You can set the configuration for the ICA Connection. ICA Client Feature Settings [Configure ICA Client Feature Settings] ...You can configure ICA Client Feature Settings.

  • Page 47: Server

    6-7. Server FTP Service NOTE • Before setting the FTP service, specify the [Password] in the [Control Panel] tab surely. [FTP Service]...If using this eClient as a FTP server, select the FTP Server ON/OFF check box and set the user name, which is used for accessing the product from the other eClient, in the user list.

  • Page 48: Security

    6-8. Security Security Settings [Terminal Security Enable] ...This enables settings on network information of the • Security items Dialog box Terminal Connection Manager Terminal Properties Canceling Settings (1) Display “Terminal Connection Manager”. (2) Press [Shift] and [F2] keys at the same time. (3) “Enter Security Password”...

  • Page 49: Administration Console

    [Single Button Connect Enable] ...(Select the [Terminal Security Enable] check box to Canceling Settings (1) Display the “Single Button Connect” dialog box. (2) Press [Alt] and [F4] keys at the same time. (3) “Enter Security Password” dialog box is displayed. Enter the password set in the [Password] of the [Control Panel].

  • Page 50: System

    6-9. System Product Information [Software] ...Microsoft Windows CE Version, Revision [Hardware] ...Serial Number of the unit [Network] ...Network information 6. USING THE TERMINAL PROPERTIES Window Terminal Server Client Revision (Please refer to the page 51 on [Update...].)

  • Page 51: Software Updating/Installation

    7. SOFTWARE UPDATING/INSTALLATION You can update the built-in/add-on software and install new add-on software. Updating/Installation is performed in the “Terminal Properties”. (Built-in Software) OS: Microsoft Windows CE.NET Applications: Microsoft Terminal Server Client (Microsoft RDP Client) / Citrix ICA Client NOTE •...
  • Page 52 “Software Update” dialog box is displayed. [Server:] ...Type IP address or full domain name of the FTP [User Name:]/[Password:] ...Type the user name and password to connect the FTP. [File Name:] ...Type the folder and copied file name located in the NOTE •...
  • Page 53 • In case of updating the built-in software The following message is displayed when you successfully download the software. Click [OK] and restart the eClient SC1. • In case of installing or updating the Add-on software The eClient restarts automatically when you successfully download the software.
  • Page 54 Using the SC1 as a FTP server The firmware file can be updated by the SC1 set as a FTP server when two or more SC1 exists on the same network NOTE • This updating is available for OS file (NK.bin) only. ( as a FTP Server ) Update a SC1 firmware.

  • Page 55: Practical Setup

    • Administration Console Setting NOTE • For DHCP Option settings, confirm the following: - The eClient SC1 is connected to the WTS/Web server through built-in LAN or connection with a LAN card - A DHCP Server is used for obtaining the IP address.
  • Page 56 NOTE • Making a Registry File to Connect to a WTS/Web Server. • Please refer to the example below, make a registry file, and save it in Unicode format. Please change the italic bold phrases as necessary. - ConnectionName: Type the connection name in the “Terminal Connection Manager”.
  • Page 57 : Selecting [Enable DHCP Options] and typing each option number settings. NOTE • If the DHCP Option is used to setup the eClient SC1 for the first time, “Terminal Connection Manager” will appear because the unit automatically receives information from the DHCP Server. (“eClient Setup Wizard will not be displayed.)

  • Page 58: Short Cut Command By Keyboard

    8-2. Short cut command by keyboard Function Display “Terminal Connection Manager” dialog box (after WTS / Web connection) Display “Terminal Properties” dialog box Canceling the security settings Switching the Active Session of the WTS for the multi session 8. PRACTICAL SETUP Short cut command Press [Ctrl] + [Alt] + [End] Press [F2] in the “Terminal Connection...

  • Page 59: Troubleshooting

    9. TROUBLESHOOTING This page presents problem that can be corrected by the user. If a problem persists even after applying the suggested remedies, contact an EIZO dealer. Problems 1. No picture is displayed on the screen. 2. The following messages appear on...

  • Page 60: Cleaning

    10. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE • Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet.

  • Page 61: Specifications

    11. SPECIFICATIONS CPU and Memory Memory Display Color Supported Resolution Complying Protocol Software Complying Software for Windows Terminal Server Mouse Power Supply Power Consumption (without AC outlet connection) Interface Connector Keyboard, Mouse USB Port Parallel Serial Port PC Card Slot Line Output Monaural Microphone...
  • Page 62 Dimensions (eClient only) Dimensions (EIZO monitor attached) Monitor Mount Position Model L367 L557/L567 L767 * The figure is the size in case the monitor is installed perpendicularly. L367 11. SPECIFICATIONS 200(7.9) Highest Middle 326 x 383 x 216 326 x 355 x 232...
  • Page 63 L557/L567 L767 11. SPECIFICATIONS...
