TOOLS REQUIRED
3 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7515EK
Summary of Contents for Furniture of America CM7515EK
- Page 1 MODEL # CM7515EK Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PT) TOOLS REQUIRED 3 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 Furniture America FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 9...
- Page 5 EASTERN KING BED CM7515EK #5 1pc #6 2pcs #2 1pc #3 1pc #4 1pc Top Front Headboard panel #7 2pcs #8 2pcs Footboard Footboard Side Rail Side Rail Right Leg Left Leg Right Bed Slat - Bed Slat Bed Center Slat...
- Page 6 ASSEMBLY INSTRUCTIONS Align Headboard Leg(#4) to the Top front Headboard(#1), then secure by using pan head screw(#F) Part #1 x1pc Sticker L Part #6 x2pcs Left Hardware #F x6pcs Sticker R Right Back View NAIL LEG Hardware #H x12pcs Turn-over the fixed part (#1) &...
- Page 7 ASSEMBLY INSTRUCTIONS Part #2 x1pc Part #3 x1pc Back View Part #4 x1pc Align the Front Headboard Panel (#2,#3 & #4) on the fixed dowel(#H) as shown. Lift Headbord with Secure Headboard Leg Upside down (L&R)(#6)and Front Headboard position as shown Panel (#2,#3 &...
- Page 8 ASSEMBLY INSTRUCTIONS Insert Dowel (#G) to the Footboard Panel (#5) and attach Footboard Leg(L&R) (#10) & (#11) accordingly secure with JCBC (#B), Spring washer (#C) and Bend-Washer (K) . Tighten with Allen Key (#I) as shown. Part #5 x1pc Part #10 x1pc Part #11 x1pc...
- Page 9 ASSEMBLY INSTRUCTIONS Align the Side Rail (#8) and (#9) to Headboard & Footboard then secure by tightening bolts. Part #13 x12pcs Part #14 x8pcs Part #15 x4pcs leveler Hardware #B x8pcs Hardware #E x24pcs Align the Bed Slat Support Leg (#14), to Bed Slat (#13) and Center slat (#15) secure with JCBC...
