WK160
Touch Screen Keyprox
Table of Contents
1. INTRODUCTION ............................................................................................................. 2
2. INSTALLATION ............................................................................................................... 3
2.1 Inserting Battery ..................................................................................................... 3
2.2 Closing Battery Compartment Cover ..................................................................... 3
2.3 Wall Mounting Options ........................................................................................... 4
2.4 Enrolling the WK160 .............................................................................................. 6
2.5 Configuring the WK160 Parameters ...................................................................... 6
2.6 Enrolling Proximity Tags ........................................................................................ 8
3. USING THE TOUCH SCREEN KEYPROX ..................................................................... 9
3.1 Arming and Disarming the System ........................................................................ 9
3.2 Initiating Alarms ................................................................................................... 10
3.3 System Status and Indications ............................................................................. 10
3.4 Bypassing Zones ................................................................................................. 14
3.5 Controlling Home Automation Devices ................................................................ 14
3.6 Other Functions ................................................................................................... 15
APPENDIX A: SPECIFICATIONS ..................................................................................... 15
APPENDIX B: COMPLIANCE WITH STANDARDS .......................................................... 15
D-306042 WK160 User's Guide
User's Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tyco DSC WK160
Summary of Contents for Tyco DSC WK160
-
Page 1: Table Of Contents
WK160 Touch Screen Keyprox User’s Guide Table of Contents 1. INTRODUCTION ......................2 2. INSTALLATION ....................... 3 2.1 Inserting Battery ..................... 3 2.2 Closing Battery Compartment Cover ..............3 2.3 Wall Mounting Options ................... 4 2.4 Enrolling the WK160 ....................6 2.5 Configuring the WK160 Parameters .............. -
Page 2: Introduction
1. INTRODUCTION WK160 is a 2-way wireless PowerG touch screen keyprox for the WP8010/30 family control panels. The WK160 enables most common everyday user functions: Arm and Disarm the alarm system. Initiate Emergency, Fire and Panic alarms. Control home automation devices. ... -
Page 3: Installation
2. INSTALLATION 2.1 Inserting Battery CAUTION! Risk of explosion if battery is replaced by an incorrect type. Dispose of used battery according to manufacturer's instructions. Figure 1 – Battery Insertion Insert two 1.5V batteries in each slot while ensuring battery polarity. 2.2 Closing Battery Compartment Cover Portable Installation (Using Battery Cover without Tamper Hole) Figure 2 - Battery Cover Mounting (part a) -
Page 4: Wall Mounting Options
Wall-mounted Installation (Using Battery Cover without Tamper Hole – see "A") Figure 3 - Battery Cover Mounting (part b) A. Tamper B. DC Power Connection 2.3 Wall Mounting Options The WK160 unit mounting options are illustrated in the following drawings. Wall Mounting Figure 4a –... - Page 5 Wall Mounting with External Electrical Connector Figure 4b – Wall Mounting with External Electrical Connector 1. Secure bracket with 2 screws as shown in the two drawings above. 2. Attach the unit to the bracket. 3. Secure the unit with the screw D-306042 WK160 User’s Guide...
-
Page 6: Enrolling The Wk160
2.4 Enrolling the WK160 Refer to the WP8010/30 panel's Installer Guide and follow the procedure under the "02:ZONES/DEVICES" option of the Installer Menu. A flowchart of the procedure is provided below. Step Action LCD Display Enter the Installer menu and select ... - Page 7 Notes: 1. Every 5 minutes the keyprox performs a communication test session with the control panel (i.e. "Supervision signal) to check the integrity and quality of the Radio link. If the keyprox does not report a supervision signal at least once within a predefined time, a “MISSING”...
-
Page 8: Enrolling Proximity Tags
as keyproxs, sirens etc.) will stop beeping during the exit delay. Skip exit delay: Stop the exit delay immediately. X-10 (PGM : Activate the appliance controlled by the chosen X-10 unit(s) or the device wired to the PGM output. For more details on configuring the X-10/PGM output functions, see the corresponding sections of the control panel’s Installer Guide (“OUTPUTS”... -
Page 9: Using The Touch Screen Keyprox
3. USING THE TOUCH SCREEN KEYPROX 3.1 Arming and Disarming the System Step Operation User Actions Keyboard & Panel Response Any combination of The selected key Select a PARTITION blinks. (if Partition is enabled) Arm AWAY The selected key and the "Present Prox Tag"... -
Page 10: Initiating Alarms
LATCHKEY is available only if the LATCHKEY feature is enabled in the WP8010/30 control panel (see WP8010/30 Installer Guide).You can perform the LATCHKEY and INSTANT functions, one after the other. The order is not important. LATCHKEY and INSTANT functions can be operated only during exit delay. ... - Page 11 Arming Indications The table below lists the Arming indication keys and their definition. Icon/Key Indications Arming Indication ARM AWAY ARM HOME DISARM EXIT DELAY Each icon appears one after the other ENTRY DELAY The "Present Prox Tag" icon and DISARM key blink simultaneously If Partition is enabled, the arming indication of the first partition is displayed concurrently with the corresponding first partition key LED...
- Page 12 Number Indication What it Means Selected PGM or X-10 unit number. Volume level PGM/X-10 control mode. System is armed in LATCHKEY mode. Exit beeps are shut off. This mode disables when the exit delay is over. System is armed in the INSTANT mode. A message is waiting in the system.
- Page 13 Zone Status Indications To view the zone numbers of enrolled detectors that are in NOT READY ( ) or BYPASSED state ( ), repeatedly press the key. Upon each press of the key, the next zone number appears on the Zone # display (marked "4" in the "Icon and Key Indications"...
-
Page 14: Bypassing Zones
3.4 Bypassing Zones A zone can by bypassed by pressing the key until the zone number is shown on the zone # display (marked "4" in the "Icon and Key Indications" Figure) followed by the key. Notes: 1. Zone bypassing on the WK160 unit can be operated only if Bypass was enabled via the control panel (see WP8010/30 Installer Guide, section 3.5.2 "Configuring Arming/Disarming and Exit/Entry Procedures"). -
Page 15: Other Functions
3.6 Other Functions Output Function Actions Response AUX Function Enrollment: Long key press (more than 5 sec.) until green LED lights and then release key. Back to Factory: Long key press (more than 7 sec.) to reset the WK160 device to factory default settings. - Page 16 product. UK: This product is suitable for use in systems installed to conform to PD6662:2010 at Grade 2 and environmental class 2. DD243 and BS8243 USA: CFR 47 part 15 Canada: RSS 210 RFID Tags: ISO-18000-2 (125 kHz) The Power G peripheral devices have two- way communication functionality, providing additional benefits as described in the technical brochure.
- Page 17 LIMITED WARRANTY Digital Security Controls (DSC) warrants that for a Digital Security Controls (DSC) warrants that for a period of 12 months from the the product shall be period of 12 months from the date of purchase, the free of defects in materials and workmanship under product shall be free of defects in materials and normal use and that in fulfillment of any breach of workmanship under normal use and that in fulfillment...
- Page 18 ©2016 Tyco International Ltd. and its Respective Companies. All Rights Reserved. Toronto, Canada www.dsc.com Printed in Israel D-306042 Rev 01 (02/16) D-306042 WK160 User’s Guide...
