zBoost METRO Workspace
ZB540iP User Manual
zBoost products have a 30-day money back guarantee when purchased directly from
zBoost. If product is purchased from a reseller or third party, the purchaser is subject to
the policies of the third party.
1 year manufacturer warranty. Warranty registration at www.zBoost.com
v.0214

Advertisement

Table of Contents
loading

Related Manuals for zBoost METRO Workspace ZB540iP

Summary of Contents for zBoost METRO Workspace ZB540iP

  • Page 1 ZB540iP User Manual zBoost products have a 30-day money back guarantee when purchased directly from zBoost. If product is purchased from a reseller or third party, the purchaser is subject to the policies of the third party. 1 year manufacturer warranty. Warranty registration at www.zBoost.com...

  • Page 2: Fcc Requirements

    FCC ID: SO4ZB570-PCS-CEL FCC contact information: www.fcc.gov/signal-boosters/registration Warning: Changes or modifi cations to this device not expressly approved by zBoost could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital Warning device, pursuant to Part 15 of the FCC Rules.

  • Page 3: Safety And Product Warranty Information

    L’opération est sujette aux deux conditions Before you begin, make sure all of the following parts came with your zBoost METRO Workspace: suivantes: (1) ce dispositif peut ne pas causer l’interférence nocive, et (2) ce dispositif doit accepter n’importe quelle interférence reçue, y compris l’interférence qui peut causer l’opération peu désirée.

  • Page 4: Table Of Contents

    FIRST: Place Signal Antenna on the interior of a window located in the area of best signal . 4 YX023-PCS Outdoor External Antenna, Directional Panel, PCS (13 dBi) SECOND: Place the zBoost Base Unit where you want to create a Cell Zone™ ....5 YX026-CEL Outdoor External Antenna, Directional 3 foot Yagi with 12 Elements, CEL (11 dBi) THIRD: Run the provided coaxial cable between the Base Unit and Signal Antenna .....

  • Page 5: Overview

    There are several obstacles that can contribute to the poor reception you receive in your home: Before placing a zBoost in your home, make sure that you can place calls on the outside of your home, in the attic, at roof level or wherever you plan to place the Signal Antenna. zBoost can only Location of the Cell Phone Tower in Relation to Your Home bring signal into your home when signal reaches the Signal Antenna.

  • Page 6: (10 / 12 Dbi) Setting Up Your Zboost Signal Booster

    ® ® SECOND: Place the zBoost Base Unit where you want to create a Cell Zone™ Setting Up Your zBoost Signal Booster Connect the Indoor Antenna and coax to the Base Unit and place it where you need signal. For the widest possible signal area, it is recommended that you position the Base Unit near the middle of a room or mount it on an interior wall.
  • Page 7 METRO Workspace ZB540iP Manual ® ® Confi rm That Your zBoost is Working Properly zBoost Base Unit Light Indicators With everything connected and the Base Unit plugged in, you should walk throughout the room and see that you are able to reliably place calls.

  • Page 8: Technical Specifi Cations

    Output power Uplink: 22 dBm; Downlink: 4 dBm The zBoost unit will not help your WiFi service. This unit is designed to work with wireless PCS and Cellular phones and devices. The WIFI in your home operates on a different frequency.
  • Page 9 You must have proof of purchase to receive warranty service. A sales receipt or other Warranty service will be provided by zBoost. If you believe you need service for your unit, documentation showing the product purchased and the purchase date is considered proof of contact zBoost at 1-800-871-1612 or support@zBoost.com.
