SERVICE MANUAL
TECHNICAL INFORMATION
FOR SERVICE PERSONNEL ONLY
RAM-18QH5E
SPECIFICATIONS
TYPE
MODEL
POWER SOURCE
TOTAL INPUT
TOTAL AMPERES
COOLING CAPACITY
HEATING CAPACITY
DIMENSIONS
(mm)
NET WEIGHT
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
ROOM AIR CONDITIONER
NOVEMBER 2005
(W)
(A)
(kW)
(B.T.U.)
W
H
D
(kg)
OUTDOOR UNIT
Refrigeration & Air-Conditioning Division
NO. 0276E
PM
RAM-18QH5E
REFER TO THE FOUNDATION MANUAL
SPECIFICATIONS ------------------------------------------------------------------- 5
INSTALLATION ----------------------------------------------------------------------- 8
CONSTRUCTION AND DIMENSIONAL DIAGRAM --------------------- 12
MAIN PARTS COMPONENT --------------------------------------------------- 13
CAPACITY DIAGRAM ------------------------------------------------------------ 15
WIRING DIAGRAM ---------------------------------------------------------------- 20
CIRCUIT DIAGRAM --------------------------------------------------------------- 21
BLOCK DIAGRAM ----------------------------------------------------------------- 25
BASIC MODE ----------------------------------------------------------------------- 27
REFRIGERATING CYCLE DIAGRAM --------------------------------------- 40
DESCRIPTION OF MAIN CIRCUIT OPERATION ----------------------- 42
TROUBLE SHOOTING ----------------------------------------------------------- 66
PARTS LIST AND DIAGRAM -------------------------------------------------- 82
DC INVERTER DUAL SYSTEM MULTI
OUTDOOR UNIT
RAM-18QH5E
1ø, 220 - 240V, 50Hz
REFER TO THE SPECIFICATIONS PAGE
750
570
280
40
CONTENTS
After installation

Advertisement

Table of Contents
loading

Related Manuals for Hitachi RAM-18QH5E

Summary of Contents for Hitachi RAM-18QH5E

  • Page 1: Table Of Contents

    NO. 0276E RAM-18QH5E REFER TO THE FOUNDATION MANUAL SERVICE MANUAL TECHNICAL INFORMATION CONTENTS FOR SERVICE PERSONNEL ONLY SPECIFICATIONS ------------------------------------------------------------------- 5 INSTALLATION ----------------------------------------------------------------------- 8 CONSTRUCTION AND DIMENSIONAL DIAGRAM --------------------- 12 MAIN PARTS COMPONENT --------------------------------------------------- 13 CAPACITY DIAGRAM ------------------------------------------------------------ 15 WIRING DIAGRAM ---------------------------------------------------------------- 20...
