Edimax EW-7618Ug Specifications

802.11g Wireless LAN Adapter
802.11g Wireless LAN Adapter
Wireless XR
Wireless XR
Range Extension, Robust Connection
Taiwan / Headquarters
Edimax Technology Co., LTD.
TEL:886-2-7739-6888
FAX:886-2-7739-6887
sales@edimax.com.tw
Europe
Edimax Technology Europe B.V.
TEL:31-499-377344
FAX:31-499-372647
sales@edimax.nl
U.K.
Edimax Technology (UK) Ltd.
TEL:44-870-7740226
FAX:44-870-7740227
info@edimax.co.uk
Poland
Edimax Technology Europe
B.V. SP. Z O.O.
Tel: +48(22)-6060-255
Fax: +48(22)-6060-254
sales@edimax.nl
U.S.A.
Edimax Computer Company
TEL:1-408-496-1105
FAX:1-408-980-1530
sales@edimax.com
Latin America
TEL:1-786-845-8099
FAX:1-786-331-8490
sales_latinamerica@edimax.com
China
TEL:8610-6213-9288
FAX:8610-6213-9231
™
™
USB 2.0 Adapter
USB 2.0 Adapter
Features :
• Comply with both IEEE 802.11b and IEEE 802.11g products.
• Farther coverage, less dead spaces and higher throughput with
MIMO XR™ technology
• Supports WMM (IEEE 802.11e QoS standard), enhance multi-
media support
• Supports 64/128-bit WEP, WPA (TKIP with IEEE 802.1x), WPA2
(AES with IEEE 802.1x) functions for high level of security.
• Supports CCX 2.0 (Cisco Compatible Extensions) for the radio
monitoring and fast roaming.
• Supports operating system: Windows 98SE/Me/2000/XP
• Supports USB 2.0/1.1 interface
Specification :
Model NO.
Standard
Bus Type
Frequency Band
Modulation
Data Rate
Security
Antenna
Drivers
LEDs
Transmit Power
Receive Sensitivity
Dimension
Temperature
Humidity
Certification
EW-7618Ug
EW-7618Ug
IEEE 802.11g/b
USB Mini-B Connector
2.4000~2.4835GHz (Industrial Scientific Medical Band)
OFDM with BPSK, QPSK, 16QAM, 64QAM (11g)
BPSK, QPSK, CCK (11b)
54/48/36/24/18/12/11/9/6/5.5/2/1Mbps auto fallback
64/128-bit WEP Data Encryption, WPA (TKIP with IEEE 802.1x)
and WPA2 (AES with IEEE 802.1x)
One External Antenna and One Internal Antenna
Windows 98SE/Me/2000/XP
Power, TX, RX
18dBm ~ 20dBm
54Mbps OFDM, 10% PER, -79dBm
11Mbps CCK, 8% PER, -90dBm
15(H) x 65(W) x 100(D) mm
32~131°F (0 ~55°C)
Max. 95% (NonCondensing)
FCC , CE
