Summary of Contents for Edimax EW-7612PIn
- Page 2 Multi-Language QIG in Driver CD ================================================ Český: Českého průvodce rychlou instalací naleznete na přiloženém CD s ovladači Deutsch: Finden Sie bitte das deutsche QIG beiliegend in der Treiber CD Español: Incluido en el CD el QIG en Español Français: Veuillez trouver l’français QIG ci-joint dans le CD Italiano: Incluso nel CD il QIG in Italiano Magyar: A magyar telepítési útmutató...
- Page 3 Copyright by Edimax Technology Co, LTD. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company.
-
Page 4: Product Information
Before you starting to use this wireless network card, please check if there's anything missing in the package, and contact your dealer of purchase to claim for missing items: EW-7612PIn □ Wireless PCI-e Adapter x1 □ 3dBi Antenna x 2 □... -
Page 5: Network Card Installation
2. Network Card Installation Please follow the following instructions to install your new wireless network card: 2.1 Hardware Installation 1. SWITCH THE COMPUTER OFF, remove the cover and insert the wireless network card into an empty PCI Express slot of your computer. - Page 6 2.2 Software Installation This wizard can be run in Windows XP/Vista/7. You can install the Wireless Adapter by EZMAX Setup Wizard in the CD-ROM including in the package. The wizard is an easy and quick configuration tool for internet connection with series process. When you start EZMAX Setup Wizard, you will get the following welcome screen.
- Page 7 2.2.1 Please execute ‘ Utility \ Setup.exe ’ program to install your wireless adapter.
- Page 8 2.2.2 When you see this message, please click ‘Finish’ to complete the driver installation process.
-
Page 9: Connect To Wireless Access Point
3. Connect to Wireless Access Point Using Configuration Utility to Connect to Wireless Access Point 3.1 After installation is complete, wireless configuration utility will be shown as an icon at the lower-right corner of your windows desktop. Please click the icon by right mouse key, and select ‘Open Config Utility’... - Page 10 3.2 If the wireless access point uses encryption, you have to input WEP passphrase or WPA preshared key. Please ask the owner of the wireless access point you want to connect, and input the correct passphrase / preshared key here, then click ‘OK’. If the value you inputted here is wrong, you will not be able to connect to wireless access point.
- Page 11 3.3 If the wireless access point is successfully connected, you’ll see a ‘Connected’ message displayed at the lower-left corner of wireless configuration utility window. Click ‘Close’ to exit. For advanced settings and other features of this wireless network card, please refer to user manual enclosed in supplied CD-ROM.
-
Page 12: Federal Communication Commission Interference Statement
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 13: R&Tte Compliance Statement
Romania, Slovakia, Slovenia, the Netherlands, Portugal, Spain, Sweden, and the United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland. EU Countries not intended for use None Please check the declaration of conformity on www.edimax.com...
