- Page 1 EW‐7489WAX EW‐7689WTX Quick Installation Guide ...
-
Page 2: Product Specification
Product Specification • IEEE 802.11b/g/n/ax 2.4GHz 1024QAM with 574Mbpps • IEEE 802.11a/n/ac/ax 5GHz 1024QAM with 2400Mbps Wireless Technology • SupportMU‐MIMO/OFDMA at 2.4GHz and 5GHz • 1x GE LAN(PoE 802.3at PD) • 1 x Console port • 1x 12V DC Jack External Interface • 1 x reset button • 1x WPS • 1x console port RJ45 • 1 x Console Port PIN connector (for core‐board UART use) Internal Interface • LED 1xtri‐color LED • Core board: 75x84mm/6L PCB Dimension ... -
Page 3: Led Definition
Damaged appliances must be returned. It is forbidden to open the hardware appliance or to change its components. Failure to comply with this rule results in the loss of warranty cover from EDIMAX. Connect the device to a power socket with a fully functional earth conductor. Defective earth conductor connections do not comply with the requirements for safety and electromagnetic compatibility. - Page 4 The appliance produces heat. Ensure that there is sufficient air circulation to remove the heat. Avoid a permanent high level of air humidity and formation of condensation. Protect the appliance from humidity and chemicals. Safe use of the appliance is no longer possible if: the chassis is damaged water penetrated the appliance objects entered the appliance via air opening smoke comes out of the appliance the power cable is damaged it does not work properly Immediately turn off the appliance in the event of one of the above problems, remove the power cable...
-
Page 5: Federal Communication Commission Interference Statement
the label is different from the power outlet voltage, do not connect the PoE-Injector to that power outlet. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Industry Canada Statement
Industry Canada statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. -
Page 7: Red Compliance Statement
RED Compliance Statement Compliance with 2014/53/EU Radio Equipment Directive (RED) In accordance with Article 10.8(a) and 10.8(b) of the RED, the following table provides information on the frequency bands used and the maximum RF transmit power of the product for sale in the EU: Max. -
Page 8: Declaration Of Conformity
Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European Radio Equipment directives. Equipment: Access Point Model No.: EW-7489WAX, EW-7689WTX The following European standards for essential requirements have been followed:... - Page 9 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the United Kingdom Radio Equipment directives. Equipment: Access Point Model No.: EW-7489WAX, EW-7689WTX The following European standards for essential requirements have been followed: Radio Equipment Regulations 2017 (S.I.
