- Page 1 TRITON routing switcher Analog Stereo Audio Router 16x2 Product model no. TTN-BAS-1602 INSTALLATION MANUAL MANUAL PART NO. 04-052060-004 Rev. 2 MARCH 05, 2003 the most watched worldwide...
- Page 2 FRANCE Nevada City, CA 95959-7900 Copyright 2003 Thomson Broadcast and Media Solutions, Inc. All rights reserved. Grass Valley, Jupiter, and Triton are trademarks of Thomson. Specifications subject to change without notice. For customer service, please call (800) 547-8949. For comments or questions concerning this manual, please contact: Technical Publications Department, P.O.
-
Page 3: Table Of Contents
Contents Electromagnetic Radiation Notice Hardware Warranty and Software License Parts and Service Revision history General Specifications Connection drawing Power connection Connecting the BAS-1602 to your PC Selection of router level Pin-out of RS-232 connector Maximum cable length NCB connection Several routers in one system Connecting control panels Pin-out and cable type 4.3.1... - Page 4 Basic principles 8.2.1 Example: A single unit with no NCB connected 8.2.2 Example: Several units connected by NCB RS232 Commands 8.5.1 Audio crosspoint set 8.5.2 Audio crosspoint set acknowledge 8.5.3 Video crosspoint set 8.5.4 Video crosspoint set acknowledge 8.5.5 Crosspoint status request...
-
Page 5: Electromagnetic Radiation Notice
88 - 216 216 - 1000 The policy of Thomson is one of continual development and improvement. For that reason Thomson uses components and manufacturing techniques that provide the current state-of-the-art suppression of electromagnetic radiation. This equipment, in production before October 1, 1981, has not been tested to the above listed measurements. However, equipment such as this delivered after October 1, 1983 will have the measurements on record at the factory. -
Page 6: Hardware Warranty And Software License
Please contact your local Thomson representative for hardware warranty and software license information. Parts and Service Thomson maintains a full stock of replacement parts available for immediate shipment. NORTH AMERICA PARTS AND SERVICE Please call toll-free 1-800-547-8949. You will be switched automatically to the parts and service representative nearest you. -
Page 7: Revision History
Revision history Current revision of this document is the uppermost in the table below. Revision Replaces Date Change Description 05/03/03 Updated with new Thomson/GVG design. 30/01/01 Corrected error in baud rate setting 10/10/00 Initial Revision... -
Page 9: General
BAS-1602 Rev. 2 1 General The BAS-1602 is a 16x2 analog stereo audio router with balanced in- and outputs. This state of the art router provides high performance circuits in SMD technology for maximum system performance. The BAS-1602 is designed for all demanding routing tasks in digital studio and broadcast environments. The BAS-1602 offers the possibility to expand the router in the input direction up to 128x2. -
Page 10: Power Connection
BAS-1602 can also be delivered with DC ±15V / 30W, which may be fed by a 36 – 72 VDC mains power source. A Frame mounted power supply solution is also available. Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley for this information. -
Page 11: Ncb Connection
Triton devices, with RJ45 connectors, an RJ45 to 5-pin DIN interface is necessary. This converter can be ordered from Thomson Grass Valley. The NCB system allows connection of up to 16 routers with different levels on the same bus. Control panels dedicated to work with a specific router must be configured to the same level as the router. -
Page 12: Pin-Out And Cable Type
BAS-1602 Rev. 2 Pin-out and cable type 4.3.1 RJ45 connectors On some Triton devices, the NCB cable can be connected to RJ-45 connectors. The following pin-out is used: Pin 1 = Not Connected Pin 2 = Not Connected Pin 3 = Not Connected Pin 4 = data Pin 5 = data Pin 6 = Not Connected... -
Page 13: Rj45 To 5-Pin Din Converter
BAS-1602 Rev. 2 4.3.3 RJ45 to 5-pin DIN converter In configurations that include both devices with RJ45 connectors, and devices with 5-pin DIN connectors, an RJ45 to 5-pin DIN converter may be used to complete the control loop. This converter holds both connector types, and may work both ways, thus from RJ45 to 5-pin DIN, as well as from 5-pin DIN to RJ45. - Page 14 BAS-1602 Rev. 2 o Universal Control Panel to control all devices above, with user configurable default level. Pay attention to the figure below, in order to achieve full controllability of all devices in the loop. • Triton - RCS Complete the Control loop, by connecting all Control bus connections to all Triton devices, before •...
-
Page 15: Router Configuration
BAS-1602 Rev. 2 5 Router configuration Router level Switch 1 - 4 on the configuration switch set the router’s level for communication with the Triton Router Control System, and other units in the NCB system. The panels on the NCB dedicated to operate with the router must be configured to the same level as that router. -
Page 16: Router Extension Mode
BAS-1602 Rev. 2 Router extension mode Switch 5, 6 and 7 on the configuration switch set the router’s input offset in systems with 2 or more BAS-1602. You can build systems up to 128x2. The chosen input offset defines on which input range each BAS-1602 works on. -
Page 17: Connecting Audio Signals To The Bas-1602
BAS-1602 Rev. 2 6 Connecting audio signals to the BAS-1602 Input connection Input A Left channel 1-16 Input B Right channel 1-16 Below you will find the pin-out for DB25 audio contacts. Top connector Input 1 + 24 - 12 Gnd 25 Input 2 + 10... -
Page 18: Input Extension
BAS-1602 Rev. 2 7 Input extension BAS-1602 allows input extension up to 128x2. Please connect the routers as shown below. Looping audio between the devices is done with standard BNC cable (75 Ohms). For connecting the device in the mid of a chain you use either a BNC T-connector or a split cable ( Y ). -
Page 19: Control And Connection Of Triton Systems, Interface Protocol
BAS-1602 Rev. 2 8 Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 8.1.1 Binary Code The strings shown on the next pages are in binary coded format. Please be aware of the fact that any terminal program you may use to control a Triton unit from a PC must be able to generate hexadecimal characters. -
Page 20: Example: Several Units Connected By Ncb
BAS-1602 Rev. 2 8.2.2 Example: Several units connected by NCB Messages sent to the RS232 of a single unit will be returned once no matter what address or input/output number the message has, unless it is a matrix which recognizes one of the conditions a) or b) above. If none of the cases a) or b) is fulfilled the message will also be transmitted on the NCB. -
Page 21: Commands
BAS-1602 Rev. 2 Commands 8.5.1 Audio crosspoint set Only for use with Audio routers. Command for setting of crosspoints: 1001nnnn 0kkk kkkk 0vvv vvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128... -
Page 22: Video Crosspoint Set Acknowledge
BAS-1602 Rev. 2 8.5.4 Video crosspoint set acknowledge Only for use with Video routers. Command for acknowledging setting of crosspoints: 1011nnnn 0kkkkkkk 0vvvvvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128...
