Furniture of America CM3278PC-N-2PK-VN Assembly Instructions

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM3278PC-N-2PK-VN

DIFFICULT

Tools Required For Assembly:

Allen Wrench

Phillips Screwdriver

Page 1 of 5

(Included)

(Not Included)

Rev: 1 9 -0 1 - 1 6

Table of Contents

Do you have a question about the CM3278PC-N-2PK-VN and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3278PC-N-2PK-VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 4pcs x 2 #1 x 1pc x 2 Chair Back Bolt Ø1/4" x 3-1/4" #B x 4pcs x 2 #2 x 1pc x 2 Chair Seat...
Page 4 Align seat (#2) to the holes of the chair back (#1), then secure middle hole of the seat (#2) to chair back (#1) by using bolts (#C) with washers (#E,D). #C x 1pc #D x 1pc #E x 1pc DO NOT TIGHTEN ALL BOLTS UNTIL ASSEMBLY OF CHAIR IS COMPLETED.
Page 5 Align front legs (#3R/L) to the seat (#2), then align the stretchers (#4,5) to the gaps on the chair legs. Secure front legs (#3R/L) by using bolts (#B) with washers (#E,D). #B x 4pcs #D x 4pcs #E x 4pcs Secure stretchers (#4,5) by using screws (#G).
