Operating & Installation
Fully Automatic Washing Machine
Model No.
Contents
Thank you for purchasing this
product.
- Read these instructions carefully for
optimum performance and safety
before use.
- Keep this manual for future reference.
Instructions
(Domestic use)
NA-F70A7
NA-F65A7
NA-F62A7
W9901-9ZG10
A1116-1018
Printed in India
01-2018
2
3
4
5
6
7
8
9
10
12
14
15
16
Advertisement
Table of Contents
Related Manuals for Panasonic NA-F70A7
Summary of Contents for Panasonic NA-F70A7
-
Page 1: Table Of Contents
Operating & Installation Instructions Fully Automatic Washing Machine (Domestic use) NA-F70A7 Model No. NA-F65A7 NA-F62A7 Contents Safety Precautions Part Names Operation Panel Variety of Programs Detergent Washing Washing Options • Favorite • Delicate • Bed Sheets • Air Dry • Wash / Rinse / Spin... -
Page 2: Safety Precautions
Safety Precautions Read and follow these safety precautions. WARNING May cause serious injury or death. Avoid installation in humid place. Never disassemble, repair or modify the appliance yourself. (To prevent fire or electric shock) ● In case of malfunction or failure, immediately stop Do not allow children to use on their use, unplug the power cord, and ask your nearest own. -
Page 3: Part Names
Part Names Operation CAUTION Detergent/softener Panel (P. 4) drawer (P. 6) May cause injury or property damage. Power cord and plug Do not wash, rinse, or spin (P. 13) waterproof sheets or clothes. Lint fi lter (To prevent injury, damage to the main unit, walls, fl oor (P. -
Page 4: Operation Panel
Operation Panel Reserve Water level/ Water level/ remaining time water amounts Set the time to finish washing (in hours). Water amounts Water Level F70A7 F65A7 F62A7 Indicates the selected program (No.) e.g.) 8 hours later 52 L 48 L 46 L 48 L 44 L ●... -
Page 5: Variety Of Programs
Variety of Programs Maximum capacity Program Purpose NA-F70A7 NA-F65A7 NA-F62A7 Everyday clothes Normal * (P. 7) 7.0 kg 6.5 kg 6.2 kg • Daily washing Everyday clothes Favorite * (P. 8) • Washing with your saved preferred 7.0 kg 6.5 kg 6.2 kg... -
Page 6: Detergent
Detergent Detergent Put in detergent, bleach and softener according to the water Do not put detergent directly into the tub. level displayed. Detergent may remain undissolved. ● Follow the instructions on each package. ■ Detergent and softener drawer • Close the drawer securely after putting in. •... -
Page 7: Washing
Washing Preparation: ● Check if the washing machine is properly installed. (P. 12) ● Turn on the water faucet. Timer reservation After loading laundry Turn the power on. Select a program. Set how many hours later to finish (P. 5) operation. -
Page 8: Washing Options
Washing Options Favorite Delicate Use this program to save your preferred settings. Use this program to gently wash delicate clothes and stylish garments. Load laundry evenly. After loading laundry ● Load lighter items first and press Turn the power on. them from above. -
Page 9: Air Dry
Convenient Functions Air Dry Cancelling end buzzer Water is removed from clothes by the air blown Pressing down, from the tub rotation. ■ Clothes that can be dried press. • Material: Synthetic fibre • Weight: 2 kg or less Then hold on for After loading clothes and closing the lid 2 short 3 seconds. -
Page 10: Maintenance
● Do not wash laundry without the fi lter. (To prevent damage to clothes) ● Turn the tub by hand if it is diffi cult to remove the fi lter. ● If the fi lter is broken, purchase a new one at nearest Panasonic Service Centre. - Page 11 Water supply fi lter If water does not fl ow smoothly Once a week <Air Dry> ● Follow the procedure below to prevent After operation ends splashing of water. Run the Air Dry program without After turning off the water faucet loading laundry.
-
Page 12: Installation
Installation 1. Check the location. ■ Avoid the following locations for installation. • Uneven or unstable locations (on blocks, timbers, a table with wheels, etc.) • Locations with a possibility of freezing Water tap adaptor 2. Attach the bottom cover. Water supply hose Preparation: Set a cardboard, etc. - Page 13 ■ If the installation, test run and inspection of the washing machine are not carried out following this installation method, Panasonic will not be liable for any accident or damage caused. 4. Connect the water tap adaptor and water supply hose.
-
Page 14: Error Display
Error Display ● The buzzer sounds and “U”/“H” and a number are alternately displayed. ● Cancel Child Lock (P. 9) if it is set. Error display Points to be checked Water cannot drain. Check the drain water hose for the following abnormalities: ●... -
Page 15: Troubleshooting
MEMO - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... - Page 19 Troubleshooting Symptoms Points to be checked Time indication increases or ● Time indication is approximate. Remaining time is corrected does not change during operation and displayed. Operation time is longer than ● The operation time may be longer if laundry is concentrated the time indication.
-
Page 20: Specifications
The content of hazardous substance with the a nearby authorized Collection Centre, registered exemption of the applications listed in SCHEDULE II Dismantler or Recycler, or Panasonic Service Centre of the E-Waste Rules-2016: when disposing of this product. 1. Lead (Pb) – not over 0.1 % by weight;...
