Table of Contents
Advertisement
Quick Links
Usage Notice ...................................................................................................................... 3
Safety Information ........................................................................................................................3
Class B emissions limits ...................................................................................................................................3
Important Safety Instruction ...........................................................................................................................3
Risk Group 2 ......................................................................................................................................................4
Precautions .....................................................................................................................................5
Eye Safety Warnings .....................................................................................................................7
Introduction ....................................................................................................................... 8
Product Features ...........................................................................................................................8
Package Overview ........................................................................................................................9
Product Overview .......................................................................................................................10
Main Unit .........................................................................................................................................................10
Control Panel ...................................................................................................................................................11
Rear View.........................................................................................................................................................12
Remote Control ...............................................................................................................................................13
Installation ........................................................................................................................ 14
Connecting the Projector ............................................................................................................14
Connect to Computer / Notebook ...............................................................................................................14
Connect to Video Sources ..............................................................................................................................15
Installing or Removing the Optional Lens ..............................................................................16
Removing the Existing Lens From the Projector .......................................................................................16
Installing the New Lens .................................................................................................................................17
Powering On/Off the Projector ................................................................................................18
Powering On the Projector ............................................................................................................................18
Powering Off the Projector ............................................................................................................................20
Warning Indicator ..........................................................................................................................................20
Adjusting the Projected Image ..................................................................................................21
Adjusting the Projector's Height ..................................................................................................................21
Adjusting Projected Image Position Using Lens Shift ...........................................................21
Adjusting the vertical image position .........................................................................................................22
Adjusting the horizontal image position ....................................................................................................23
Lens Shift Range Diagram .............................................................................................................................24
Adjusting the Zoom / Focus .........................................................................................................................25
Adjusting Projection Image Size (XGA) ......................................................................................................26
Adjusting Projection Image Size (WUXGA) ...............................................................................................28
Adjusting Projection Image Size (1080P) ....................................................................................................30
User Controls ................................................................................................................... 32
Control Panel ...............................................................................................................................32
Remote Control ...........................................................................................................................33
On-screen Display Menus ..........................................................................................................35
How to operate ...............................................................................................................................................35
Menu Tree ........................................................................................................................................................36
Image ............................................................................................................................................38
Display ..........................................................................................................................................44
Setup .............................................................................................................................................47
Options .........................................................................................................................................60
LAN_RJ45 .....................................................................................................................................69
Table of Contents
1
English
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Optoma EH505e-B
Summary of Contents for Optoma EH505e-B
-
Page 1: Table Of Contents
Table of Contents Usage Notice ........................3 Safety Information ........................3 Class B emissions limits ...........................3 Important Safety Instruction ...........................3 Risk Group 2 ..............................4 Precautions .............................5 Eye Safety Warnings ........................7 Introduction ........................8 Product Features ...........................8 Package Overview ........................9 Product Overview ........................10 Main Unit .................................10 Control Panel ..............................11 Rear View.................................12... - Page 2 Computer Compatibility - VESA standards ....................89 RS232 Commands ........................92 RS232 Protocol Function List .....................93 Telnet Commands ........................97 AMX Device Discovery commands ..................97 PJLink™ supported commands ....................98 Trademarks ..........................100 Ceiling Installation ........................101 Optoma Global Offices ......................102 Regulation & Safety notices .....................104 Operation conditions ........................105 English...
-
Page 3: Usage Notice
Usage Notice Safety Information The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of import operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 4: Risk Group 2
Do not attempt to service this projector yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma to be referred to an authorized service center near you. 8. Do not let objects or liquids enter the projector as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. -
Page 5: Precautions
Usage Notice Precautions Please follow all warnings, precautions and maintenance as recommended in this user’s guide. ▀■ Warning - Do not look into the projector’s lens when the lamp is on. The bright light may damage your eyes. ▀■ Warning - To reduce the risk of fire or electric shock, do not expose this projector to rain or moisture. - Page 6 Usage Notice Turn off the product before cleaning. Use a soft cloth moistened with a mild detergent to clean the display housing. Disconnect the power plug from the AC outlet if the product is not being used for a long period of time. Do not: Block the ventilation slots and openings on the unit.
-
Page 7: Eye Safety Warnings
Usage Notice Eye Safety Warnings ▀■ Avoid staring directly into the projector’s beam of light at all times. ▀■ Minimize standing facing into the beam. Keep your back to the beam as much as possible. ▀■ Using a stick or laser pointer is recommended to avoid the need for the presenter to enter the beam. -
Page 8: Introduction
Introduction Product Features This product is a single chip 0.7” XGA, 0.67 WUXGA and 1080P series DLP projector. Outstanding features include: ® Texas Instruments Single chip DLP Technology ® Computer Compatibility: Apple Macintosh, iMac, and VESA Standards: UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA Video Compatibility: ■... -
Page 9: Package Overview
Introduction Package Overview This projector comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. IR Remote Control Projector with lens cap (with 2 x AAA Batteries) Option Lens (Standard lens/ Long throw lens/... -
Page 10: Product Overview
Introduction Product Overview Main Unit 12 13 18 17 10. Focus Front IR Receiver 11. Lens CAP Top Cover Lens Release Button 12. Power Button Vertical and Horizontal Lens 13. LED Indicators Shift Adjustment Controls 14. Input/Output Connections Control Panel 15. -
Page 11: Control Panel
Introduction Control Panel 1. Source / ◄ 2. Keystone + / ▲ 3. Re-Sync / ► 4. Menu 5. Enter 6. Keystone - / ▼ English... -
Page 12: Rear View
Introduction Rear View AUDIO2-IN: Share with DVI & BNC audio input. 1. HDMI Connector WIRED REMOTE (3.5mm jack) AUDIO IN L/R RCA (YPbPr) 2. 3D SYNC IN Connectors AUDIO IN L/R RCA (Video/ 3. VGA 2/ YPbPr Connector S-Video) Connectors 4. -
Page 13: Remote Control
Introduction Remote Control 1. Power On 2. Test Pattern 3. Function 1 (Assignable) 4. Display mode / Mouse Due to the Left Key difference in 5. Four Directional Select applications Keys for each country, some 6. Enter regions may 7. Information Panel have different 8. -
Page 14: Installation
Installation Connecting the Projector Connect to Computer / Notebook 3D Adapter Due to the difference in applications for each country, some regions may have different 1. Power Cord accessories. 2. VGA Cable 3. Audio-in Cable * AUDIO2-IN: Share with DVI 4. -
Page 15: Connect To Video Sources
Installation Connect to Video Sources DVD Player, Set-top Box, HDTV receiver Due to the difference in applications for each country, some regions may have different accessories. AUDIO2-IN: Share with DVI & BNC audio input. DVD Player, Set-top Box, Video Output HDTV receiver 1. -
Page 16: Installing Or Removing The Optional Lens
Installation Installing or Removing the Optional Lens Caution • Do not shake or place excessive pressure on the projector or the lens components as the projector and lens components contain precision parts. • Before removing or installing the lens, be sure to turn off the projector, wait until the cooling fans stop, and turn off the main power switch. -
Page 17: Installing The New Lens
Installation 5. Pull out the existing lens slowly. Installing the New Lens Remove both end caps from the lens. 1. Align the flange and correctly position at the 11 o’clock position as shown in the picture. Flange 2. Rotate the lens clockwise until you feel it click into place. -
Page 18: Powering On/Off The Projector
Installation Powering On/Off the Projector Powering On the Projector 1. Remove the lens cover. 2. Connect the power cord to the projector. 3. Turn On the connected devices. 4. Ensure the Power LED turns red and then press the power button to turn On the projector. - Page 19 Installation See Security Setting on page 50 if security lock is enabled. 5. If more than one input device is connected, press the “Source” button sequentially to switch between devices. For direct source selection, see page 33. English...
-
Page 20: Powering Off The Projector
Installation Powering Off the Projector 1. Press POWER to turn off the projector lamp, a message displays on the projector’s screen. 2. Press POWER again to confirm, otherwise the message disappears after 15 seconds. 3. The cooling fans continue to operate for about 180 seconds for cooling cycle and the Power Led will turn blue. -
Page 21: Adjusting The Projected Image
Installation Adjusting the Projected Image Adjusting the Projector’s Height The projector is equipped with elevator foot for adjusting the image height. To raise the image: Use screw in foot u to rise the image to the desired height angle and fine-tune the display angle. -
Page 22: Adjusting The Vertical Image Position
Installation The Lens Shift function can be used to adjust the position of the projected image either horizontally or vertically within the range detailed below. Adjusting the vertical image position The vertical image height can be adjusted between 50% and -10% for XGA, 55% and -15% for WUXGA, 60% and -20% for 1080P of offset position. -
Page 23: Adjusting The Horizontal Image Position
Installation Screen H x 30% 100% H x 20% H x 60% H x 5% Distance 1080P Adjusting the horizontal image position With the lens in the center position the Screen Width horizontal image position can be adjusted to the left or right by up to a maximum of 5% of the image width. -
Page 24: Lens Shift Range Diagram
Installation Lens Shift Range Diagram H50% When W and H at 0% offset position The max. H up shift=Hx55% The max. H down shift=Hx15% The max. W shift=Wx5% When max. W shift is Wx5% Max. H shift=Hx50% When max. H shift is Hx55% Max. -
Page 25: Adjusting The Zoom / Focus
Installation Adjusting the Zoom / Focus You may turn the zoom ring to zoom in or out. To focus the image, rotate the focus ring until the image is clear. The projector will focus at distances. See pages 26-30. Use the keystone buttons to correct image distortion. They can be found on the remote control and on the projector’s control panel. -
Page 26: Adjusting Projection Image Size (Xga)
Installation Adjusting Projection Image Size (XGA) 65.6' (20.00m) 65.6' (20.00m) 32.8' (10.00m) 53.8' (16.40m) 32.0' (9.76m) 16.4' (5.00m) 42.0' (12.80m) 29.5' (9.00m) 30.2' (9.20m) 20.2' (6.16m) 13.1' (4.00m) 26.2' (8.00m) 14.4' (4.40m) 18.4' (5.60m) 16.4' (5.00m) 16.4' (5.00m) Width 9.8' (3.00m) 9.8' (3.00m) 8.9' (2.72m) 8.2' (2.50m) - Page 27 Installation Long lens: offset=50% 49.2” 137.8” 226.4” 315.0” 403.5” 492.1” Max. Screen (125.0cm) (350.0cm) (575.0cm) (800.0cm) (1025.0cm) (1250.0cm) (Diagonal) 32.8” 91.9” 150.9” 210.0” 269.0” 328.1” Min. (83.3cm) (233.3cm) (383.3cm) (533.3cm) (683.3cm) (833.3cm) 110.2”x82.7” 39.4”x29.5” 181.1”x135.8” 252.0”x189.0” 322.8”x242.1” 393.7”x295.3” (WxH). 100.0x75.0cm 460.0x345.0cm 640.0x480.0cm 820.0x615.0cm...
-
Page 28: Adjusting Projection Image Size (Wuxga)
Installation Adjusting Projection Image Size (WUXGA) 65.6' (20.00m) 65.6' (20.00m) 32.8' (10.00m) 53.8' (16.40m) 32.6' (9.95m) 16.4' (5.00m) 42.0' (12.80m) 29.5' (9.00m) 30.2' (9.20m) 20.2' (6.16m) 13.1' (4.00m) 26.2' (8.00m) 14.4' (4.40m) 18.4' (5.60m) 16.4' (5.00m) 16.4' (5.00m) Width 9.8' (3.00m) 9.8' (3.00m) 8.9' (2.72m) 8.2' (2.50m) - Page 29 Installation STD lens: offset=55% 45.2” 82.0” 132.6” 185.7” 241.2” 300.0” Max. Screen (114.9cm) (208.3cm) (336.9cm) (471.7cm) (612.6cm) (761.9cm) (Diagonal) 36.1” 65.4” 105.8” 148.2” 192.4” 239.4” Min. (91.7cm) (166.2cm) (268.8cm) (376.4m) (488.8cm) (608.0cm) 38.3”x24.0” 69.5”x43.5” 112.5”x70.3” 157.5”x98.4” 204.5”x127.8” 254.4”x159.0” Screen size 97.4x60.9cm 176.6x110.4cm 285.7x178.6cm...
-
Page 30: Adjusting Projection Image Size (1080P)
Installation Adjusting Projection Image Size (1080P) 65.6' (20.00m) 65.6' (20.00m) 32.8' (10.00m) 53.8' (16.40m) 33.6' (10.23m) 16.4' (5.00m) 42.0' (12.80m) 29.5' (9.00m) 30.2' (9.20m) 21.7' (6.61m) 13.1' (4.00m) 26.2' (8.00m) 14.4' (4.40m) 18.4' (5.60m) 16.4' (5.00m) 16.4' (5.00m) Width 9.8' (3.00m) 9.8' (3.00m) 8.9' (2.72m) 8.2' (2.50m) - Page 31 Installation STD lens: offset=60% 44.0” 79.8” 129.1” 193.9” 234.7” 300.1” Max. Screen (111.8cm) (202.6cm) (327.8cm) (492.5cm) (596.0cm) (762.2cm) (Diagonal) 35.1” 63.7” 103.0” 154.7” 187.2” 239.4” Min. (89.2cm) (161.7cm) (261.6cm) (393.0cm) (475.6cm) (608.2cm) 38.3”x21.6” 69.5”x39.1” 112.5”x63.3” 169.0”x95.1” 204.5”x115.0” 261.5”x147.1” (WxH). 97.4x54.8cm 176.6x99.4cm 285.7x160.7cm 429.2x241.4cm...
-
Page 32: User Controls
User Controls Control Panel Using the Control Panel ▲/Keystone+ •Adjust the image Keystone positively. (Up arrow) •Navigates and changes settings in the OSD. ◄/Source •Press Source to select an input signal. (Left arrow) •Navigates and changes settings in the OSD. Enter Confirm your item selection. -
Page 33: Remote Control
User Controls Remote Control Using the Remote Control Refer to the “Powering On the Projector” on page 18. Power On/Off Refer to the “Powering Off the Projector” on page 20. Test Pattern Refer to the “Test Pattern” on page 61. When connecting your PC to the projector through USB, press Mouse Mouse Switch... - Page 34 User Controls Using the Remote Control Source Press Source to search for source. Automatically synchronize the projector Re-Sync to the input source. Press Menu to launch the on-screen Menu display (OSD) menu. To exit OSD, press Menu again. Volume +/- Press Volume +/- to adjust volume.
-
Page 35: On-Screen Display Menus
User Controls On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. How to operate 1. To open the OSD menu, press Menu on the Remote Control or Projector Keypad. -
Page 36: Menu Tree
Mute On/Off 0~10 Volume Audio Input Default /Audio 1/Audio 2/Audio 3/Audio 4 Exit SETUP | Advanced Logo Optoma/Neutral/User Logo Capture Closed Captioning Off/CC1/CC2 Exit SETUP | Network LAN Settings Network Status/DHCP/IP Address/Subnet Mask/Gateway/DNS/Apply/MAC Address/Exit Control Settings Crestron/Extron/PJ Link/AMX Device Discovery/Telnet/Exit... - Page 37 User Controls HDMI/DVI-D/BNC/VGA 1/VGA 2/Component/S-Video/Video/Display Port/Exit Input Source OPTIONS Source Lock On/Off High Altitude On/Off Information Hide On/Off Keypad Lock On/Off Display Mode Lock On/Off Test Pattern None/Grid(White)/Grid(Green)/Grid(Meganta)/White Background Color Blue/Black/Red/Green/White Remote Setting On/Off 12V Trigger Advanced Lamp Setting Information Reset Current/All OPTIONS | Remote Setting...
-
Page 38: Image
User Controls Image Display Mode There are many factory presets optimized for various types of images. Presentation: Good color and brightness from PC input. Bright: Maximum brightness from PC input. Movie: For home theater. sRGB: Standardised accurate color. Blackboard: This mode should be selected to achieve optimum color settings when projecting onto a blackboard (green). - Page 39 User Controls Image Sharpness Adjusts the sharpness of the image. Press ◄ to decrease the sharpness. Press ► to increase the sharpness. Color Adjusts a video image from black and white to full color saturation. Press ◄ to decrease the amount of color in the image. Press ►...
- Page 40 User Controls Image | Advanced Noise Reduction The motion Adaptive Noise Reduction reduces the amount of visible noise in interlaced signals. The range is from “0” to “10”. (0=Off) BrilliantColor This adjustable item utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing true, more vibrant colors in picture.
- Page 41 User Controls Image | Advanced | RGB Gain/ Bias This setting is used to adjust the balance of red, green and blue in grays/white. Gain Set RGB Gain to adjust the Brightness of the follow in brighter shades: Red—balance the gain value for red. Green—balance the gain value for green.
- Page 42 User Controls Image | Advanced | Color Matching Colors (Except White) Press ▲▼ to select a color and press Enter to adjust the hue, saturation, and gain settings. Green, Blue, Cyan,Yellow, Magenta can be separate adjust by each color HSG. Press ▲▼...
- Page 43 User Controls Image | Advanced | Color Matching White Press ▲▼ to select White and press Enter. White can be adjust Red, Green, Blue color by each. Press ▲▼ to select Red, Green, or Blue and press ◄► to adjust the settings.
-
Page 44: Display
User Controls Display Format Use this function to choose your desired aspect ratio. 4:3: This format is for 4x3 input sources not enhanced for Wide screen TV. 16:9 (XGA/1080P) | 16:10 (WUXGA): This format is for 16x9 input sources, like HDTV and DVD enhanced for Wide screen TV. LBX: This format is for non-16x9, letterbox source and for users who use an external 16x9 lens to display 2.35:1 aspect ratio using full resolution. - Page 45 User Controls Display Digital Zoom Press ◄ to reduce the size of the image. Press ► to magnify an image on the projected screen. Edge Mask Edge Mask function removes the noise in a video image. Edge Mask the image to remove video encoding noise on the edge of video source. Image Shift Shifts the projected image position horizontally or vertically.
- Page 46 User Controls User Controls Display | 3D 3D Mode DLP Link: Select DLP Link to use optimized settings for DLP Link 3D Glasses. VESA 3D: Select VESA 3D to use optimized settings for IR-based 3D images. Off: Select “Off” to turn off 3D mode. 3D2D Press ◄...
-
Page 47: Setup
User Controls User Controls Setup Language Enter the Language menu. Select the multilingual OSD menu. See page 49 for more information. Projection Select projection method: Front Desktop The factory default setting. Rear Desktop When you select this function, the projector reverses the image so you can project from behind a translucent screen. - Page 48 User Controls Setup Security Enter the Security menu. Access the projector’s security features. See page 50 for more information. Signal (RGB) Enter the Signal (RGB) menu. Set projector signal properties. The function is available when input source is support VGA 1/VGA 2/BNC. See page 53 for more information.
- Page 49 User Controls Setup | Language Language Choose the multilingual OSD menu. Press ENTER ( ) into the sub menu and then use the Left (◄) or Right (►) key to select your preferred language. English...
- Page 50 User Controls Setup | Security Security Setting Enable or disable the security password. Enabled—the current password is required to power on the projector The default and access the Security menu. password: 1, 2, Disabled—no password is required for any function. 3, 4, 5.
- Page 51 User Controls Setup | Security Security Timer Enter the Security Timer sub menu. No password is required to Enter the Months, Days, and hours that the projector can be used without access Setup entering the password. Exiting to the Setup menu activates the Security | Security Timer.
- Page 52 User Controls Setup | Security Change Password Use this submenu to change the security password for the projector. 1. Select Change Password from the Security submenu. The Confirm If the incorrect Change Password dialog box displays. password is 2. Select Yes. entered three times, the device auto...
- Page 53 User Controls Setup | Signal (RGB) Automatic Set Automatic to On or Off to lock or unlock the Phase and Frequency features. Off—disable auto lock. On—enable auto lock. Frequency Change the display data frequency to match the frequency of your computer’s graphics card.
- Page 54 User Controls Setup | Signal (Video) White Level Allow user to adjust Black Level when input source is Video or S-Video signals. Press ◄► to adjust the White Level. Black Level Allow user to adjust Black Level when input source is Video or S-Video signals.
- Page 55 User Controls Setup | Audio Settings Mute Toggle the audio on or off. Off—Audio out is turned on. On—Audio out is turned off. Volume Press ◄► to decrease(increase) for Audio-out. Audio Input Press ◄► to select audio source input. English...
- Page 56 User Controls Setup | Advanced Logo Select the screen to display during startup. Optoma—the supplied default startup screen. Neutral— is Background Color. User—customized screen capture using the Logo Capture function. Logo Capture Capture a displayed screen to use as the startup screen.
- Page 57 User Controls Setup | Network LAN Settings Enter the LAN Settings menu. See page 58 for more information. Control Settings Enter the Control Settings menu. See page 59 for more information. English...
- Page 58 User Controls Setup | LAN Settings If the connection is successful, the OSD display will show the following dialogue box. Network State—to display network information. Network DHCP: sub-menu On: Assign an IP address to the projector from the DHCP server can only be automatically.
- Page 59 User Controls Setup | Control Settings Crestron Press ◄► to check to enable/disable Crestron. Extron Press ◄► to check to enable/disable Extron. PJ Link Press ◄► to check to enable/disable PJ Link. AMX Device Discovery Press ◄► to check to enable/disable AMX Device Discovery. Telent Press ◄►...
-
Page 60: Options
User Controls Options Input Source Enter the Input Source submenu. Select the sources to scan for at startup. See page 63 for more information. Source Lock Lock the current source as the only available source, even if the cable is unplugged. - Page 61 User Controls Options Keypad Lock Lock the buttons on the projector top panel. On—a warning message displays to confirm keypad lock. Off—projector keypad functions as normal. Display Mode Lock Press ◄► to select display mode function whether lock or not. When Display Mode Lock set to On, the Display Mode function can’t be adjusted by user.
- Page 62 User Controls Options Advanced Enter the Advanced menu. See pages 65 for more details. Lamp Setting Enter the Lamp Setting menu. See pages 67-68 for more details. Information Show the projector information. Reset Reset all Options to default factory settings. When Power mode (Standby) is set to Eco,...
- Page 63 User Controls Options | Input Source Input Source Use this option to enable / disable input sources. Press ▲ or ▼ to select a source, then press ◄ or ► to enable / disable it. Press (Enter) to finalize If all sources the selection.
- Page 64 User Controls Options | Remote Settings Function 1 Set F1 key as a hotkey for Brightness, Contrast, Color, Color Temp. or Gamma function. Function 2 Set F2 key as a hotkey for Source Lock, Projection, Lamp Settings, Mute, Digital Zoom or Volume function. IR Function Enable or Disable projector’s IR function.
- Page 65 User Controls Options | Advanced Direct Power On Enable or disable Direct Power On. On—the projector powers on automatically when AC power is supplied. Off— the projector must be powered on as normal. Signal Power On Enable or disable Signal Power On. On—the projector powers on automatically when an active signal is detected.
- Page 66 User Controls Options | Advanced Sleep Timer (min) Set the Sleep Timer interval. The projector powers off after the specified time period of inactivity (regardless of signal). The following warning is displayed 60 seconds before power off. Power Mode (Standby) Eco.: Choose “Eco.”...
- Page 67 User Controls Options | Lamp Setting Lamp Hour Displays the number of hours the lamp has been active. This item is for display only. Lamp Reset After replacing the lamp, reset the lamp counter to accurately reflect the new lamp’s life span. 1.
- Page 68 User Controls Options | Lamp Setting Brightness Mode Select the lamp brightness mode. Bright—the default setting. Eco—lower brightness setting to conserve lamp life. Power—Select to display the Power mode function. Power Press ◄► to select the lamp mode for 365W brightness or 292W brightness to save lamp life.
-
Page 69: Lan_Rj45
User Controls LAN_RJ45 For simplicity and ease of operation, the Optoma projector provides diverse networking and remote management features. The LAN/RJ45 function of the projector through a network, such as remotely manage: Power On/Off, Brightness and Contrast settings. Also, Projector projector status information, such as: Video-Source, Sound-Mute, etc. - Page 70 User Controls LAN_RJ45 Connect an RJ45 cable to RJ45 ports on the projector and the PC (Laptop). On the PC (Laptop), select Start -> Control Panel-> Network Connections. 3. Right Click on your Local Area Connection, and select Property. English...
- Page 71 User Controls 4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP). 5. Click Properties. 6. Fill in the IP address and Subnet mask, then press OK. English...
- Page 72 User Controls 7. Press the Menu button on the projector. 8. Select OSD-> SETUP-> Network Settings-> Lan Settings. 9. After getting into Network Status, input the following: DHCP: Off IP Address: 10.10.10.10 Subnet Mask: 255.255.255.0 Gateway: 0.0.0.0 DNS: 0.0.0.0 10. Press (Enter) / ►...
- Page 73 User Controls Category Item Input-Length IP Address Crestron Control IP ID Port Projector Name Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A) Admin Password New Password Confirm...
- Page 74 User Controls Preparing Email Alerts 1. Make sure that user can access the homepage of LAN RJ45 function by web browser (for ex-ample, Microsoft Internet Explorer v6.01/v8.0). 2. From the Homepage of LAN/RJ45, click Alert Settings. 3. By default, these input boxes in Alert Settings are blank. 4.
- Page 75 User Controls The From field is the sender’s email address (for example, the projector administrator). This is a required field. Select the alert conditions by checking the desired boxes. Fill in all fields as specified. User can click Send Test Mail to test what setting is correct.
- Page 76 User Controls Quick Start-Guide for “RS232 by TELNET” Check and get the IP-Address on OSD of the projector. Make sure that laptop/PC can access the web-page of the projector. Make sure that “Windows Firewall” setting to be disabled in case of “TELNET”...
- Page 77 User Controls How to have TELNET enabled in Windows VISTA / 7 By default installation for Windows VISTA, “TELNET” function is not included. But end-user can have it by way of “Turn Windows features On or Off” to be enabled. 1.
- Page 78 User Controls 3 Select “Turn Windows features on or off” to open. 4. Have “Telnet Client” option checked, then press “OK” button. Specsheet for “RS232 by TELNET” : 1. Telnet: TCP. 2. Telnet port: 23 (for more detail, kindly please get contact with the service agent or team).
-
Page 79: Appendices
Appendices Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image Problems No image appears on-screen Ensure all the cables and power connections are correctly and securely connected as described in the Installation section. - Page 80 Appendices If you are using a Notebook: 1. First, follow the steps above to adjust resolution of the computer. 2. Press the toggle output settings. Example: [Fn]+[F4] Acer [Fn]+[F5] IBM/Lenovo [Fn]+[F7] [Fn]+[F4] Asus [Fn]+[F8] HP/Compaq Dell [Fn]+[F8] [Fn]+[F3] Gateway [Fn]+[F4] Toshiba [Fn]+[F5] Mac Apple:...
-
Page 81: Intermission Problems
Appendices The image is stretched when displaying 16:9 DVD title When you play anamorphic DVD or 16:9 DVD, the projector will show the best image in 16:9 format in OSD. If you play 4:3 format DVD title, please change the format as 4:3 in projector OSD. If the image is still stretched, you will also need to adjust the aspect ratio by referring to the following: Please setup the display format as 16:9 (wide) aspect ratio type... -
Page 82: Hdmi Q & A
Appendices HDMI Q & A What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High-Speed cables. Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal. -
Page 83: Projector Status Indication
Appendices Projector Status Indication Power LED Power LED Temp LED Lamp LED Message (Green) (Red) (Red) (Red) Operating Warm up or Flashing Cooling down (0.5 sec) Standby T1 temperature Flashing over temperature Thermal break Lamp error Flashing Fan error Flashing Flashing Lamp door open DMD error... -
Page 84: Remote Control Problems
Appendices Message Reminders Replacing the lamp: Out of range: (see the following for more information) Remote Control Problems If the remote control does not work Check the operating angle for the remote control is approximately ±15°. Make sure there are no obstructions between the remote control and the projector. -
Page 85: Replacing The Lamp
Appendices Replacing the Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: The lamp contains a certain amount of mercury and should be disposed of according to local ordinance regulations. - Page 86 Appendices 1. Switch off the power to the projector by pressing the Power button. 2. Allow the projector to cool down at least 30 minutes. 3. Disconnect the power cord. 4. Unlock the lamp cover. 5. Pull up and remove the cover. 6.
-
Page 87: Cleaning The Projector
Appendices Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: Be sure to turn off and unplug the projector at least an hour before cleaning. Failure to do so could result in a severe burn. Use only a dampened cloth when cleaning. -
Page 88: Compatibility Modes
Appendices Compatibility Modes Video Compatibility NTSC NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4.43MHz SECAM B/D/G/K/K1/L, 4.25/4.4 SECAM SDTV 480i/p, 576i/p 720p(50/60Hz), 1080i(50/60Hz), HDTV 1080P(50/60Hz) Video timing detail describe Refresh Signal Resolution Notes Rate(Hz) TV(NTSC) 720 X 480 For Composite For wide Video/S-Video TV(PAL, SECAM) 720 X 576... -
Page 89: Computer Compatibility - Vesa Standards
Appendices Computer Compatibility - VESA standards Computer Signal (Analog RGB Compatible Signal Resolution Refresh Rate(Hz) Notes for Mac 640 x 480 60/67/72/85 Mac 60/72/85 56/60 /72/ (*2) SVGA 800 x 600 Mac 60/72/85 85/120 (*2) 50/60 /70/ (*2) 1024 x 768 75/85/120 60/70/75/85 (*2) - Page 90 Appendices Input Signal for HDMI/DVI-D Signal Resolution Refresh Rate(Hz) Notes for Mac 640 x 480 Mac 60/72/85 /72/85/ (*2) SVGA 800 x 600 Mac 60/72/85 (*2) 50/60 /70/ (*2) 1024 x 768 75/85/120 60/70/75/85 (*2) SDTV(480i) 720 x 480 SDTV(480p) 720 x 480 SDTV(576i) 720 x 576...
- Page 91 Appendices True 3D Video Compatibility table Input Input timing Resolutions 1280 x 720p @50Hz Top - and - Bottom 1280 x 720p @60Hz Top - and - Bottom 1280 x 720p @50Hz Frame packing 1280 x 720p @60Hz Frame packing HDMI 1.4a 3D Input 1920 x 1080i @50Hz...
-
Page 92: Rs232 Commands
Appendices RS232 Commands RS232 Connector Pin No Specification English... -
Page 93: Rs232 Protocol Function List
Appendices RS232 Protocol Function List RS232 Commands < > l l a < > : y t Stop Bits: 1 UART16550 FIFO: Disable Projector Return (Fail): F XX=01-99, projector's ID, XX=00 is for all projectors ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ SEND to projector ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Function Description 232 ASCII Code... - Page 94 Appendices ~XX35 8 7E 30 30 33 35 20 38 0D ~XX35 9 7E 30 30 33 35 20 39 0D ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ ~XX36 3 7E 30 30 33 36 20 30 0D Color Temp. Warm ~XX36 0 7E 30 30 33 36 20 31 0D Standard ~XX36 1 7E 30 30 33 36 20 32 0D...
- Page 95 7E 30 30 38 39 20 35 0D Audio4 ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ ~XX82 1 7E 30 30 38 32 20 31 0D Logo Optoma ~XX82 2 7E 30 30 38 32 20 32 0D User ~XX82 3 7E 30 30 38 32 20 33 0D...
- Page 96 Appendices Appendices (5 minutes for each step). ~XX107 n 7E 30 30 31 30 37 20 a 0D Sleep Timer (min) n = 0 (a=30) ~ 995 (a=39 39 35) (30 minutes for each step). ~XX114 1 7E 30 30 31 31 34 20 31 0D Power Mode(Standby) Active (<=0.5W) l b i...
-
Page 97: Telnet Commands
Carriage Command ID Space Variable Code Return Defined by Fix code Fix code Optoma 2 or 3 Per item One Digit Digit. See the Definition Digit~ Digit Follow content For wide screen resolution (WXGA), the compatibility support is dependent on Notebook/PC models. -
Page 98: Pjlink™ Supported Commands
Appendices Command Description Remark (Parameter) Config-URL Device’s IP address http://xxx.xxx.xxx. xxx/index.html LAN IP address is shown up if LAN IP address is valid. Wireless LAN IP address is shown up if Wireless LAN IP address is valid. Revision The revision must follow a 1.0.0 major.minor.micro scheme. - Page 99 Inquiry about the The projector name set on specifications projector name the NETWORK menu or the Version 1.0. ProjectorView Setup window is returned INF1? Inquiry about the “Optoma” is returned. manufacturer name INF2? Inquiry about the “EH7700” is returned. model name English...
-
Page 100: Trademarks
Appendices Command Description Remark (Parameter) INF0? Inquiry about other No other information is available. information No parameter is returned. CLSS? Inquiry about the “1” is returned. class information Trademarks DLP is trademarks of Texas Instruments. IBM is a trademark or registered trademark of International Business Machines Corporation. -
Page 101: Ceiling Installation
Appendices Ceiling Installation To prevent damage to your projector please use the recommended mounting package for installation. To ensure compliance, only use a UL Listed ceiling mount and Damage to the screws that meet the following specifications: projector as a Screw Type: M4 result of incorrect... -
Page 102: Optoma Global Offices
Appendices Optoma Global Offices For service or support please contact your local office. 3178 Laurelview Ct. Fremont, CA 94538, USA Tel : 888-289-6786 Fax : 510-897-8601 www.optomausa.com Service : services@optoma.com Canada 2420 Meadowpine Blvd., Suite #105 Mississauga, ON, L5N 6S2, Canada... - Page 103 Appendices Scandinavia Optoma Scandinavia AS Lerpeveien 25 3040 Drammen Norway PO.BOX 9515 3038 Drammen Norway Tel : +4732988990 Fax : +4732988999 Service : info@optoma.no Latin America 3178 Laurelview Ct. Fremont, CA 94538, USA Tel : 888-289-6786 Fax : 510-897-8601 www.optomausa.com.br Service : www.optomausa.com.mx...
-
Page 104: Regulation & Safety Notices
Appendices Regulation & Safety notices This appendix lists the general notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 105: Operation Conditions
Appendices Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian users This Class B digital apparatus complies with Canadian ICES-003.
