Optoma EH503 Datasheet

MULTIMEDIA PROJECTOR
EH503
BRIGHT 1080P HD LARGE VENUE PROFESSIONAL INSTALLATION
LENS THROW OPTIONS
Optoma Part Number
Throw Ratio (Distance/Width)
Projection Distance
Image Size (Diagonal)
Projection Lens
Weight w/ Projector
Short Throw
BX-DL080
0.77:1
1.6'– 9.8' (0.5–3m)
28.0"– 171" (0.71– 4.34m)
F=2.5, f=11.5 mm, Manual Focus
19.1 lb (8.6 kg)
High resolution 1080p display
ensures easy to read text and
graphics
Ideal solution for large screen 16:9
video displays
3D at full 1080p resolution with
optional RF 3D emitter and glasses
Vertical and horizontal lens shift for
maximum installation flexibility
Interchangeable lens options
The perfect solution for professional installation and
integration in large board rooms, conference rooms,
lecture halls, auditoriums, and houses of worship.
With Its powerful 5000 lumens output, remarkable
2000:1 contrast ratio and native 16:9 aspect ratio,
the Optoma EH503 delivers bright large-screen pre-
sentations, movies, text and graphics with amazing
image clarity and superb color reproduction.
Designed for ease of installation and integration,
the Optoma EH503 provides vertical and horizon-
tal lens shift, choice of 3 high-quality, high perfor-
mance optional lenses, comprehensive connectivity
including HDMI 1.4a, DisplayPort , DVI-D for digital
sources, 3-axis color matching, brightness match-
ing, wired remote, Crestron RoomView for remote
monitoring and control, DICOM simulation mode
and much more. Built to Optoma's highest qual-
ity standards, the Optoma EH503 will deliver peak
performance for years to come.
Standard Throw
BX-DL200
1.54–1.93:1
4.9'– 23.0' (1.5–7m)
34.2"– 200" (0.87– 5.08m)
F=2.46-2.56, f=22.8-28.5 mm,
1.25x Manual Zoom and Focus
18.9 lb (8.6 kg)
Long Throw
BX-DL300
1.93– 2.89:1
6.6'– 65.6' (2– 20m)
30.6"– 457" (0.78 –11.6m)
F=2.5-3.1, f=28.5-42.75 mm,
1.5x Manual Zoom and Focus
18.9 lb (8.6 kg)
