USB-1608GX User's Guide

Single-ended mode pinout

Pin Signal name
1 CH0
2 CH8
3 AGND
4 CH1
5 CH9
6 AGND
7 CH2
8 CH10
9 AGND
10 CH3
11 CH11
12 AGND
13 NC
14 AGND
15 NC
16 AGND
empty
17 GND
18 DIO0
19 DIO1
20 DIO2
21 DIO3
22 DIO4
23 DIO5
24 DIO6
25 DIO7
26 GND
27 NC
Table 18. 16-channel single-ended mode pinout
Pin description
AI channel 0
AI channel 8
Analog ground
AI channel 1
AI channel 9
Analog ground
AI channel 2
AI channel 10
Analog ground
AI channel 3
AI channel 11
Analog ground
No connection
Analog ground
No connection
Analog ground
Digital ground
DIO channel 0
DIO channel 1
DIO channel 2
DIO channel 3
DIO channel 4
DIO channel 5
DIO channel 6
DIO channel 7
Digital ground
No connection
22
Pin Signal name
28 CH15
29 CH7
30 AGND
31 CH14
32 CH6
33 AGND
34 CH13
35 CH5
36 AGND
37 CH12
38 CH4
39 AGND
40 AGND
41 AGND
42 +5V
43 AGND
empty
44 GND
45 AICKI
46 AICKO
47 NC
48 NC
49 TRIG
50 GND
51 CTR1
52 CTR0
53 TMR
54 GND
Specifications
Pin description
AI channel 15
AI channel 7
Analog ground
AI channel 14
AI channel 6
Analog ground
AI channel 13
AI channel 5
Analog ground
AI channel 12
AI channel 4
Analog ground
Analog ground
Analog ground
+5V power output
Analog ground
Digital ground
AI clock input
AI clock output
No connection
No connection
Trigger input
Digital ground
Counter 1 input
Counter 0 input
Timer output
Digital ground
