Page 2
The system information, procedures and guidelines found in this presentation are for Reference Only. information & procedures this presentation have been taken from the FAA Approved Airplane Flight Manual and Pilot’s Operating Handbook (POH). The Information & Procedures in this presentation DO NOT SUPERSEDE the Information &...
Page 3
General Mode A and Mode C 4096-code transponder Incorporates timer features into transponder interface...
Controls and Functions IDENT – activates Special Position Identification (SPI) signal for 18 seconds Press One – selects ‘1200’ as active code Press Twice – reverts to previously active code ON – engages reply to Mode A interrogations STBY – halts response to all ATCRBS interrogations...
Page 5
Controls and Functions FUNC – cycles transponder through display functions Pressure Altitude – displays current pressure altitude as received from altitude digitizer Flight Time – begins when unit senses liftoff Count Up Timer Count Down Timer START/STOP CRSR – cycles position in active field...
Page 6
Features Automatic ALT/STBY Selection When groundspeed is greater than 35 knots, unit automatically selects ALT mod When groundspeed is less than 35 knots + 10 seconds, unit automatically selects STBY...
