SPECIFICATION APPROVAL SHEET
Open frame 10.1" (1280x800) Digital TFT LCD, Aspect Ratio: 16:10
Input Signal VGA / HDMI 1.3a, Maximum Support Resolution
1920x1080, Headphone Driver, 46mW@32O, 5 Key Buttons Controls,
9 Language OSD Menu, LED Backlight, Single Operation Voltage +12V,
No accessory is included.
MODEL: FCOPW1010
i-Tech Company LLC
TOLL FREE: (888) 483-2418 • EMAIL: info@itechlcd.com • WEB: www.iTechLCD.com
Advertisement
Table of Contents
Related Manuals for I-Tech FCOPW1010
Summary of Contents for I-Tech FCOPW1010
- Page 1 Input Signal VGA / HDMI 1.3a, Maximum Support Resolution 1920x1080, Headphone Driver, 46mW@32O, 5 Key Buttons Controls, 9 Language OSD Menu, LED Backlight, Single Operation Voltage +12V, No accessory is included. MODEL: FCOPW1010 i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@itechlcd.com • WEB: www.iTechLCD.com...
-
Page 2: General Description
FCOPW1010 2018 08 30 V1.0 Projected Capacitive Touch Resistive Touch Panel 1. General Description Features ■ 10.1” (1280x800) Digital TFT LCD ■ Aspect Ratio: 16:10 ■ Input Signal VGA / HDMI 1.3a ■ Maximum Support Resolution 1920x1080 ■ Headphone Driver, 46mW@32Ω... -
Page 3: Table Of Contents
FCOPW1010 2018 08 30 V1.0 2. Contents Page Contents 1. General Description…………………………………………………………………………………….……………. 1.1 Features 1.2 Applications 2. Contents……………………………………………………………………………...…………………………….…. 3. Specifications………..………………………………………….………………..…………………………………… 4. Black Diagram………………………………………………………………….………………………………….…. 5. Order Information…..………………...……………………………………………………………………………… 5.1 Unit 6. Accessories (Option)………………………………………………………………………………………………….. 7. Operation manual / Connection……………………………………………………………………………………… 7.1 Driver Board Manual 8. - Page 4 11.2.4 Projected Capacitive Touch Panel Operation System Support 12. Key Function by OSD……………………………………………………………………………………………….. 17-20 12.1 Menu Operation 17-20 13. Dimension Information…………………………………………………………………………………………….. 21-23 13.1 Unit (FCOPW1010) 14. Installation Recommendations………………………………………………….………………………………… 15. Appendix………………………………………………………………………….………………………………… 14.1 TFT-LCD Mechanical Specifications 14.2 TFT-LCD Optical Characteristics 16. Revision History.………………………………………………………………….………………………………… 16.1 Record of Revision...
-
Page 5: Specifications
FCOPW1010 2018 08 30 V1.0 3. Specifications Input Signal Panel Size 10.1” D-Sub15 Resolution (Pixels) HDMI 1280x800 1.3a 300 cd/㎡ Luminance without RTP Audio 234cd/㎡ 46mW@32Ω Luminance (RTP) Headphone Driver 255 cd/㎡ Phone Jackψ3.5 Luminance (PCAP) (Line In & out) -
Page 6: Order Information
FCOPW1010 2018 08 30 V1.0 5. Order Information Unit Item FCOPW1010 Unit Remark ◎ HDMI ◎ Touch Panel Type Touch Screen Interface Headphone Driver ◎ (Line In & out) 5 Keys ◎ UART Remote Control ◎ Dimensions 244.5 x 150.9 x 22.83 Weight 485.5... -
Page 7: Accessories (Option)
FCOPW1010 2018 08 30 V1.0 6. Accessories (Option) Before you begin installing the KIT, please make sure that the following materials have been shipped: A. AC to DC Adapter (L:1500mm,100-240V 50-60Hz to +12V @ 3.3A,ψ2.1) B. Power Cord (L:1800mm, Plug Type B for USA) C. -
Page 8: Operation Manual / Connection
FCOPW1010 2018 08 30 V1.0 7. Operation manual / Connection Driver Board Manual... -
Page 9: Pin Description
FCOPW1010 2018 08 30 V1.0 8. Pin Description ψ ψ J101A : Pin Assignment of Power Input (DC-Jack Inside Diameter:2.1 Outside Diameter:5.5 Side Entry Type) Pin No. Symbol Description Remark DC-In +12Vdc Input Voltage Power Ground J702 : Pin Assignment of UART (Pitch 1.25mm 4Pin, Top Entry Type) ※... -
Page 10: J401：Pin Assignment Of Hdmi-A Type Input (Hdmi 1.3A -19Pin Female)
FCOPW1010 2018 08 30 V1.0 ： J401 Pin Assignment of HDMI-A Type Input (HDMI 1.3a -19Pin Female) Pin No. Symbol Description Remark DATA2+ Positive HDMI Input for B Link Data Channel 2 DET_HDMI HDMI Detect DATA2- Negative HDMI Input for B Link Data Channel 2... -
Page 11: J701A：pin Assignment Of Touch Usb (Usb A Type - Female 2.0Mm, Side Entry Type )(Option)
FCOPW1010 2018 08 30 V1.0 ： J701A Pin Assignment of Touch USB (USB A Type - Female 2.0mm, Side Entry Type )(Option) Pin No. Symbol Description Remark VBUS USB VCC DATA (-) DATA (+) DGND Digital Ground ： J706B Pin Assignment of Touch RS232 (Pitch 1.25mm 5Pin , Side Entry Type)(Option) ※... -
Page 12: Absolute Maximum Ratings
FCOPW1010 2018 08 30 V1.0 9. Absolute Maximum Ratings Absolute Maximum Ratings Parameter Symbol Unit Remark Input Voltage +13.5 Analog RGB Input Signal Analog RGB in Vp-p Digital Input Signal HDMI Input Signal Operating Temp. without TP ℃ Storage Temp. without TP ℃... -
Page 13: Vga Mode Characteristics
FCOPW1010 2018 08 30 V1.0 10.2 VGA Mode Characteristics Dots per inch Unit Polarity Unit Polarity Note 640 × 480 31.47 Positive 59.9 Positive 800 × 600 37.88 Positive 60.3 Positive 1024 × 768 48.36 Positive Positive 1280 × 800 49.2... -
Page 14: Resistive Touch Panel Integration Design Guide
FCOPW1010 2018 08 30 V1.0 -11.1.5 Resistive Touch Panel Integration Design Guide Avoid the design that Front-case overlap and press on the active area of the touch-panel. Give enough gap (over 0.5mm at compressed) between the front case and touch-panel to protect wrong operating. -
Page 15: Mechanical Design Notice For Resistive Touch Panel
FCOPW1010 2018 08 30 V1.0 -11.1.6 Mechanical Design Notice For Resistive Touch Panel Correct Installation Incorrect Installation P.14... -
Page 16: Resistance Touch Panel Operation System Support
FCOPW1010 2018 08 30 V1.0 -11.1.7 Resistance Touch Panel Operation System Support Driver Vender：EETI (eGalax_eMPIA Technology Inc.) Version Interface Windows 7, 8, 8.1, 10 Windows Embedded 7, 8 Windows Windows Embedded POSReady 2009 USB/RS232 Windows , XP, 2000 Windows XP Embedded... -
Page 17: Projected Capacitive Touch Panel Characteristics
FCOPW1010 2018 08 30 V1.0 11.2 Projected Capacitive Touch Panel Characteristics -11.2.1 Electrical Performance Parameter Symbol Unit Note Operating Voltage -11.2.2 Optical Performance Parameter Specifications Light Transmittance Min 85% -11.2.3 Mechanical Performance Parameter Specifications Input Method Finger Touch Function 10 Points... -
Page 18: Key Function By Osd
FCOPW1010 2018 08 30 V1.0 12. Key Function by OSD 12.1 Menu Operation DOWN EXIT SOURCE / POWER MENU LED Indicator OSD ICON Instructions： POWER：Power On/Off (※Press for 3 secs to turn off) MENU / ENTER：(After turning on MENU, only ENTER is available) UP：Move Upward / Increase Value / Option Switch... - Page 19 FCOPW1010 2018 08 30 V1.0 Overview of the Menu： Image Indicator Meaning Default Adjustable range Remark Brightness 0~63 Adjust-Bar Contrast 0~63 Adjust-Bar Sharpness Adjust-Bar Adjust-Bar Dimmer 0~15 Normal Color Temp. Normal / Warm / Cool H-Position -25~+25 VGA only V-Position...
- Page 20 FCOPW1010 2018 08 30 V1.0 Setting Indicator Meaning Default Adjustable range Remark Source VGA / HDMI Volume 0~63 Mute On / Off On：Mute，Off：Sound English / 中文 / 日本語 / 한국의 Language English / Française / Deutsch / Italiano / Española / Português...
- Page 21 FCOPW1010 2018 08 30 V1.0 Hot Key When OSD Menu is Off： Information of Input Source and Functionality： Input Source Resolution Detect Source Remaining Secs VGA Mode Remaining Secs [Source]：Input Signal Switch Overview of Input Signals： Indicator Interface HDMI P.20...
-
Page 22: Dimension Information
FCOPW1010 2018 08 30 V1.0 13. Dimension Information 13.1 Unit (FCOPW1010) P.21... -
Page 23: Installation Recommendations
FCOPW1010 2018 08 30 V1.0 14. Installation Recommendations P.22... -
Page 24: Appendix
FCOPW1010 2018 08 30 V1.0 15. Appendix 15.1 TFT-LCD Mechanical Specifications Parameter Specifications Unit Screen Size 10.1 (diagonal) Inch Display Format 1280 x (R.G.B) x 800 Active Area 216.96 (H)× 135.6(V) Pixel Pitch 0.1695(H) x 0.1695(V) Pixel Arrangement RGB stripe 15.2... -
Page 25: Revision History
FCOPW1010 2018 08 30 V1.0 16. Revision History 16.1 Record of Revision Date Description Page Note ．First draft August 30, 2018 P.24...
