- Page 1 ASSEMBLY INSTRUCTIONS MATRIX HEAVY-DUTY HIGH BACK CHAIR JBMATRHDFA Weight capacity: 250kgs This design and instruction booklet is subject to copyright. www.officeworks.com.au 1CTN For spare parts or hardware call (03) 9310 3011 or email hardware@kyvas.com.au...
- Page 2 Assembly Video • To view an assembly video, go to https://www.officeworks.com.au • Search the product by item code or name: • Click on the icon to watch the video. (03) 9310 3011 NOTE • Please check you have all hardware before assembly. •...
- Page 3 H-L / H-R (5/16” x 1-1/4” ) (5/16” x 1” ) (5/16” x 1-1/2” )
- Page 4 Note:Turn the Star Base (B) upside down. Push the Castors (A) firmly into hole at the end of each leg. Turn the Star Base (B) upright and insert Gas Lift (C) into the center hole of Star Base (B). Place cover (D) over the Gas Lift (C). 6 Pcs 5/16”...
- Page 5 2 Pcs 2 Pcs 5/16” x 1” Bolt 5/16” x 1-1/4” Bolt used to complete used to complete this step. this step. Note: Using 2 bolts (I) & 2 bolts (J) to fix the Seat Plate (E) onto the Seat (G) with Allen Key (L). Ensure the Seat Plate (E) is fixed to the Seat with correct orientation.
- Page 6 Note: Place assembled Seat on the Gas Lift (C). Push down firmly until connection is secure. Your Matrix Heavy-Duty High Back Chair is now complete and ready for use. IMPORTANT NOTE: Periodically check and re-tighten screws...
- Page 7 Care Instructions • Wipe with a damp cloth and mild soap. Wipe dry immediately with an absorbent dry cloth. • Treat spills immediately with an absorbent cloth by blotting the spill. • Do not use detergents, solvents or abrasive cleaners. •...
- Page 8 MATRIX HEAVY-DUTY HIGH BACK CHAIR Functionality Arm Height Adjust - Pull lever up whilst moving the arm up or down. Release lever at desired height. * Chair Height Adjustment - To increase chair height pull lever upward while body weight slightly off...
