SUPER-SAVER XL
♦ Hot Surface Ignition
♦ Wash Down Design
MODEL
BTUH
SS-225-XL
225,000
FOR YOUR SAFETY
If you smell gas:
1. Open windows
2. Don't touch electrical switches
3. Extinguish any open flames
4. Immediately call your gas supplier
CONSIGNES DE SECURITE
Si vous sentez une odeur de gaz:
1. Ouvrez les fenetres
2. Ne touchez pas aux interrupteurs electriques
3. Etegnex toute flamme hue
4. Contactez immediatement votre compangie
de gaz
HIRED-HAND, INC. • 1733 County Road 68 • Bremen, AL 35033 USA• Phone 256-287-1000 • Fax 256-287-2000
Owner's Manual
Agricultural Building Heater - Maywick
kW
65.9
Retain Instructions For Future Reference
Manual Part No. 4801-5801 Rev 4-2010
HEATER
TM
FOR YOUR SAFETY
Do not store or use gasoline or any
flammable vapors and liquids in the
vicinity of this or any other appliance
CONSIGNES DE SECURITE
II es interdit d'utiliser des liquides
inflammables ou degageant des
vapeurs inflammables, a proximite
de tout appareil fonctionnant au gaz
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIRED-HAND Maywick SUPER-SAVER XL
Summary of Contents for HIRED-HAND Maywick SUPER-SAVER XL
- Page 1 4. Contactez immediatement votre compangie de tout appareil fonctionnant au gaz de gaz Retain Instructions For Future Reference HIRED-HAND, INC. • 1733 County Road 68 • Bremen, AL 35033 USA• Phone 256-287-1000 • Fax 256-287-2000 Manual Part No. 4801-5801 Rev 4-2010...
- Page 2 GENERAL HAZARD WARNING Failure to comply with precautions and instructions provided with this heater can result in death, serious bodily injury and property loss or damage from hazards of fire, explosion, burn, asphyxiation, carbon monoxide poisoning, and/or electrical shock. If you need assistance or heater information such as an instruction manual, labels, etc.
-
Page 3: Table Of Contents
Installation ............7 all of the listed parts are enclosed. User Instructions ..........8 not, call your Hired-Hand Outside Mount (Optional) ....... 9 Distributor immediately. Component And Wiring Diagram ....11 Ladder Type Schematic Diagram ....12 Servicing Instructions ........13 Pipe Sizing Guidelines ......... -
Page 4: Warnings And Cautions
2. Warnings and Cautions WARNING When Heater Is Connected To Remote Thermostat Heater May Start At Any Time! ELECTRICAL GROUNDING INSTRUCTIONS This appliance is equipped with a three prong (grounding) plug for your protection against electrical shock and should be plugged directly into a properly grounded three-prong receptacle. -
Page 5: Maintenance
This appliance rating is based on the use of ANSI LC-2 test gases including LP (2500 BTU/ft 93.15 MJ/m ) and natural gas (1075 BTU/ft , 40 MJ/m ). Hired-Hand, Inc. makes no guarantees regarding the proper operation of this appliance when these conditions are not met. Part No. 4801-5801 Rev. 4-2010 Page... -
Page 6: Warranty
Limited Warranty 4. Warranty The GSI Group, LLC. (“GSI”) warrants products which it manufactures to be free of defects in materials and workmanship under normal usage and conditions for a period of 12 months after sale to the original end-user or if a foreign sale, 14 months from arrival at port of discharge, whichever is earlier. -
Page 7: Installation
5. Installation 5.1 Hanging The Heater Chain Suspension Cable Suspension Mount heater with chain hooks and chains so that back of heater is at least 12 inches (305 mm) from If frequent height adjustment is required, use ceiling and wall. Heater must be a minimum of 20 cables and pulleys. -
Page 8: User Instructions
6. User Instructions Before turning on gas, check main supply valve to be sure it is open (Fig. 3). Be sure to check all connections for leaks with a Gas Leak Testing solution, (soap and water work well). Check to see if gas valve knob is in the ON position. -
Page 9: Outside Mount (Optional)
7. Outside Mount (Optional) Hired-Hand heaters are available in Outside Mount (OSM) models. These heaters are designed to be mounted to the outside wall of a building. This saves valuable space inside the building and ensures fresh air intake for the heater. - Page 10 Detail E Existing Bend Direction 13. Bend the sides of two door covers 90° by hand in the direction of the existing top and bottom bends. See Detail E. 14. Insert tabs of door cover in slots on heater door Door Cover and slide down.
-
Page 11: Component And Wiring Diagram
8. Component and Wiring Diagram COMPONENT AND WIRING DIAGRAM 230 Volts A.C. 50 Hz Single Phase Part No. 4801-5801 Rev. 4-2010 Page Super Saver XL Heater Maywick... -
Page 12: Ladder Type Schematic Diagram
9. Ladder Type Schematic Diagram LADDER TYPE SCHEMATIC DIAGRAM LEG 1 LINE VOLTAGE LEG 2 GROUND THERMOSTAT LINE VOLTAGE ON / OFF LOW LINE 10 AMP FUSE TRANSFORMER 24 VAC-40VA, 50/60 Hz UNITED TECHNOLOGIES Hot Surface Ignition Control TRANSFORMER 24 VAC-40VA, 50/60 Hz IGNITOR HSIG SAIL SWITCH... -
Page 13: Servicing Instructions
10. Servicing Instructions 10.1 United Technologies Hot Surface Ignition System IMPORTANT! Inspect and check operation of this appliance monthly. Follow the instructions below. If a problem is detected, contact a qualified technician to make any necessary repairs. In an effort to minimize the time required to trouble shoot this system: Turn off the gas supply at the main gas valve. - Page 14 10.2 1018 Series Hot Surface Ignition Status Indicator Error Conditions The status indicator LED will not be lit with power applied to the board and the control operating properly. However, if the control is not operating properly, the status indicator LED will flash in one of the following error codes.
- Page 15 10.4 Chart 1 First Visual Check Part No. 4801-5801 Rev. 4-2010 Page Super Saver XL Heater Maywick...
- Page 16 10.5 Chart 2 Second Visual Check Part No. 4801-5801 Rev. 4-2010 Page Super Saver XL Heater Maywick...
- Page 17 10.6 Chart 3 Third Visual Check Part No. 4801-5801 Rev. 4-2010 Page Super Saver XL Heater Maywick...
-
Page 18: Pipe Sizing Guidelines
11. Pipe Sizing Guidelines Determine the Equivalent Length Of Pipe (ELOP) 11.1 Calculating HVR & ELOP required for sufficient gas service. Using a system schematic, label each piping ELOP = (length from meter to most remote heater) section of the system starting at the meter or + (Minor loss equivalents of the system) regulator. - Page 19 Table 1 Minor Loss Equivalents Fitting 2" (5.08 cm) IPS Or Smaller 2” (5.08 cm) IPS To 4” (10.16 cm) IPS Feet per fitting Meters per fitting Feet per fitting Meters per fitting 45° Elbow 90° Elbow Gate Valve Angle Valve Swing Valve Pipe Sizes Determined For Diagram Pipe Section...
-
Page 20: Parts & Assemblies
12. Parts & Assemblies When ordering service parts, please specify the country, model number, date of manufacture, voltage, frequency, gas type, inside or outside mount, and whether the heater is constructed of galvanized or stainless steel. 6401-2899 6401-2889 3005-0107 1007-1614 6401-2879 3005-2130 3005-0102... - Page 21 6401-0225 0404-10773 6401-0226 6401-5030 1004-1406 0408-4492 6401-1308 3002-5001 (24 V) Refer to Model No. for Orifice type. 3003-5010 1041-3066 1009-1500 1004-1422 1021-1495 3004-6000 1041-1491 1021-1497 1021-1496 Part No. 4801-5801 Rev. 4-2010 Page Super Saver XL Heater Maywick...
- Page 22 6401-2879 6401-1318 0408-1131 3504-4007 3001-1740 0404-4486 3017-3076 3591-0100 3008-2258 1902-1138 3006-1580 3001-2862 1042-2693 3010-2139 240 Volt Heater Plate Part No. 4801-5801 Rev. 4-2010 Page Super Saver XL Heater Maywick...
- Page 23 NOTES Part No. 4801-5801 Rev. 4-2010 Page Super Saver XL Heater Maywick...
- Page 24 Copyright © 2008 by Group Printed in the USA...
