- Page 1 USER MANUAL Element Alb Filter ® ...naturally better water S/N 0000001 ® f i l t e r Made in Germany Blaufaktor GmbH & Co. KG www.alb-filter.com Riedweg 12 info@alb-filter.com D-78607 Talheim...
-
Page 2: Table Of Contents
Thank you very much for purchasing our CONTENT ® Alb Filter Element water filter Preamble .................. 4 Scope of delivery ..............5 ® For a proper installation and efficient operation of Parts – Alb Filter Element ..........6 the filter, please observe the following installation Installation shower / bathtub .......... -
Page 3: Preamble
Alb Element filter cartridge (already installed) At a time when even the smallest part seems to come from the Far East, we at Alb Filter stand for quality Further accessories as well as replacement cartridges, from the centre of the Swabian Alb. A production site in... -
Page 4: Parts - Alb Filter Element
® PARTS – ALB FILTER ELEMENT Top connection (inlet): 1/2 inch female thread with head seal S/N 0000001 Spanner size 24 mm for open-end wrench (top) Sealing ring (top) Thread for upper housing cover Active Filter corpus with internal thread at top and bottom ®... -
Page 5: Installation Shower / Bathtub
1. Before starting installation, please close the water Note: supply line on the relevant fitting. Alb Filter cartridges for shower applications are 2. Unscrew the shower hose from your tap. (A) generally suitable for hot and cold water. For water 3. - Page 6 Made in Germany ® f i l t e r Made in Germany 9. Check the filter housing and all connected components for leaks. (E) 10. The Alb filter is now ready for use.
-
Page 7: Installation Under Sink
INSTALLATION UNDER SINK Warning: For installations under sinks and other indoor areas in the household, a water stop system must be installed upstream. This protection serves to stop the flow of water in the event of water leaks at the housing. If you have any questions, please contact your plumber. - Page 8 Production-related activated carbon dust can loosen during rinsing and slightly turbidify the water during the activation process of the cartridge. 10. Check the filter housing and all connected compo- nents for leaks. (G) 11. The Alb filter is now ready for use.
-
Page 9: Replacing The Filter Cartridge
REPLACING THE FILTER CARTRIDGE If the housing cover is stuck, please use a 24 mm open-ended spanner. Use a sheet to avoid scratches. Way of proceeding: 1. Before starting the installation, please close the water supply line on the relevant valve. 2. - Page 10 6. Check the filter housing and all connected compo- c. With slight turning movements nents for leaks. press them into the bottom of 7. The Alb filter is now ready for use. the housing. Please observe the direction of water flow, marked with the arrow and „IN“!
-
Page 11: Maintenance
MAINTENANCE TECHNICAL SPECIFICATIONS The Alb filter is basically low-maintenance. However, the • Version: Filter housing for installation on water maximum service life of the filter cartridges must be connections observed. • Material: Special alloy, food-safe • Cartridge and Performance: Clean and lime-free fittings are the prerequisite for hy- Depending on the selected version gienically perfect drinking water. -
Page 12: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS • Scope of delivery includes the cartridge selected when or- • To ensure complete safety regarding the quality of your filtered water, a water analysis in a responsible laboratory is dering. It is already pre-installed in the filter housing. •... -
Page 13: Special Safety Instructions For Interiors
Always install the filter at the pressure level of the pump. Installation in the suction stage can perman- ently damage the filter. Replacement cartridges available at www.alb-filter.com Shop-Category: spare cartridges Don‘t miss a filter change with the Alb Filter reminder service: https://alb-filter.com/reminder... - Page 14 All rights reserved. No part of this manual may be reproduced in any Video Tutorials Online form or reproduced or processed using electronic, mechanical or chemi- cal processes without the written consent of the publisher. It is possible that this manual still has printing defects or printing errors. However, the information in this manual is checked regularly and correc- tions are made in the next issue.
