Settings

Settings contains the parameters that control C-Pen. Enter
Settings from the Main screen by selecting the Settings
icon. You can also enter text settings from the Text menu,
p. 43 and the Edit menu, p. 26. A list of the available set-
tings appears.
The following settings are available:
• Text Language
• Read Mode
• Text Quality
• Beam Settings
• C Write Feedback
• Calibration
• System Settings
Text Language, Read Mode and Text Quality are referred
to as text settings. You should set up these settings to
achieve optimal OCR.
To modify a setting:
1. Turn Nav to highlight the setting you want to change.
Press Nav and a check box or menu appears.
2. Turn Nav to highlight the option you want and press
Nav to select the chosen value.
3. Select
OK
changed setting.
4. Exit Settings by selecting Exit at the top of the
Settings menu, or alternatively press ESC.
54
to close the dialog box and save the
