Wiring instructions
·① : when the device (computer) has RS485 interface, the communication can be directly
connected to RS485_A and RS485_B communication lines without transferring to 485
module through USB
·② : in this way, other serial port debugging software (such as MODBUS poll) can be
used for debugging
Software can be downloaded on the official website. Software and driver are integrated in the
process of software installation, and both are installed together. It is recommended to check the
create shortcut during installation.
2.1.2 Debugging software instructions
'
Before use, it is necessary to connect the corresponding wiring according to the instructions
Tel/Fax: 0755-82734836
Figure 2.2 (a) installation interface 1
Figure 2.2 (b) driver installation interface
