- Page 1 ASSEMBLY GUIDE 150-P4B04 & P4W06 UNIVERSAL 2 LEG / 2 MOTOR / 3 SEGMENT (with LOGICDATA control system)
-
Page 2: Assembly Guide
ASSEMBLY GUIDE 1. Packaging 150-P4B04 & P4W06 1.1 Tools Required Power Drill (optional) Allen Wrench Philips Head Screwdriver 1.2 Part Check List Standard Handset Leg (2 Pcs) Middle Slat (2 Pcs) Brace (2 Pcs) Foot Plate (2 Pcs) - Page 3 ASSEMBLY GUIDE 1. Packaging 150-P4B04 & P4W06 1.2 Part Check List Control Box (1 Pc) Motor Cables (2 Pcs) Feet (2 Pcs) Power Cable (1 Pc) M6x16 (8 Pcs) M8x12 (12 Pcs) ST4.8x16 (22 Pcs) ST4.2x16 (4 Pcs) Washers (4 Pcs)
- Page 4 ASSEMBLY GUIDE 2. Assembly 150-P4B04 & P4W06 2.1 Assembly Step by Step Step 1 Step 2 Place the Middle Slat & Braces as illustrated above. Adjust the Middle Slat to the suitable length. M8x12 Step 3 Step 4 Line up the holes on the legs to the holes on the Middle Slats Place the stabilizing foot plates on each leg.
- Page 5 ASSEMBLY GUIDE 2. Assembly 150-P4B04 & P4W06 2.1 Assembly Step by Step ST4.8x16 Step 8 Step 7 Attach the 2-button handset, using ST4.2 x 16 Mount the Control Unit as illustrated above. Please refer to the Torque Guide. Step 9...
-
Page 6: Zero Setting
ASSEMBLY GUIDE 2. Assembly 150-P4B04 & P4W06 2.2 Assembly Step by Step Step 12 Step 11 Attach optional memory handset with ST4.2 x 16. Assemble the optional part Cable Management Tray to the top, using ST4.8 x 16 and washers. -
Page 7: General Operation
ASSEMBLY GUIDE 3. Operating Instructions 150-P4B04 & P4W06 3.2 General Operation: This function enables you to adjust the frame upwards or downwards. Press ▲ or ▼ button and keep pressing the button until the required frame height is reached •... -
Page 8: Using Memory Function
ASSEMBLY GUIDE 3. Operating Instructions 150-P4B04 & P4W06 3.5 Saving a desktop position: This function allows you to save a defined desktop height .One desktop height can be saved per memory position key. To save a position, proceed as follows: •... - Page 9 ASSEMBLY GUIDE 3. Operating Instructions 150-P4B04 & P4W06 3.8 Changing the desktop height displayed: This function enables you to change the height shown on the display, but not the actual position of the desktop. • Press the memory button. The display will read S -.
