Amana AGG222VD Dimension Manual

PRODUCT MODEL NUMBERS
AGG222VD
Gas supply: Provide a gas supply line of
" (1.9 cm) rigid pipe to the range location. A smaller
size pipe on longer runs may result in insufficient gas
supply. Pipe joint compounds that resist the action of
LP gas must be used. Do not use TEFLON
With LP gas, piping or tubing size can be
minimum. Usually, LP gas suppliers determine the
size and materials used in the system.
If local codes permit, a new CSA design-certified,
4-5 ft (122-152.4 cm) long, " (1.3 cm) or
" (1.9 cm) I.D., flexible metal appliance connector
may be used for connecting range to the gas supply
line.
A " (1.3 cm) male pipe thread is needed for
connection to the female pipe threads of the inlet to
the appliance gas pressure regulator.
Electrical: A 120-volt, 60-Hz, AC-only, 15-amp,
fused electrical circuit is required. A time-delay fuse
or circuit breaker is also recommended. It is
recommended that a separate circuit serving only this
range be provided.
Do not use an extension cord.
†®TEFLON is a registered trademark of E.I. Du Pont De Nemours and
Company.
CABINET OPENING DIMENSIONS
13" (33.0 cm) max.
upper cabinet depth
20" (50.8 cm) min.
cabinet opening width
opening width
18" (45.7 cm)
3" (7.6 cm) min.
min. clearance
countertop space to
upper side
side wall or other
cabinet to
combustible material
countertop
This shaded area
recommended for
electrical outlet.
(6.4 cm)
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
20" (50.8 cm) Freestanding Gas Range
PRODUCT DIMENSIONS
®† tape.
" (1.3 cm)
This shaded area
recommended for
installation
of gas pipe.
10" (25.4 cm)
24"
(61.0 cm)
4"
(14 cm)
(10 cm)
4"
2"
(10 cm)
(5.1 cm)
(65.9 cm)
For minimum
clearance to
top of cooktop,
see NOTE.
NOTE: 24" (61 cm) minimum when bottom of wood or metal cabinet is
covered by not less than
covered with not less than No. 28 MSG sheet steel, 0.015" (0.4 mm)
stainless steel, 0.024" (0.6 mm) aluminum or 0.020" (0.5 mm) copper.
30" (76.2 cm) minimum clearance between the top of the cooking
platform and the bottom of an uncovered wood or metal cabinet.
IMPORTANT: If installing a range hood or microwave hood
combination above the range, follow the range hood or microwave hood
combination installation instructions for dimensional clearances above
the cooktop surface.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
(106.6 cm)
(50 cm)
" (0.64 cm) flame retardant millboard
Ref. W10173755D
9/24/10
