- Page 1 NOVUS SPEAKERS OWNER'S MANUAL ©2020 Aperion Audio. All Rights Reserved.
-
Page 2: Safety Instructions
Quick Setup The initial set-up of your Novus loudspeaker is relatively easy. Please take your time reading the guideli- nes and more detailed instructions on the following pages of this manual after completing the first four steps below. -
Page 3: Connecting The Speaker
Connecting the Speaker 1. Connect a two-pole (+/-) loudspeaker cable to the binding posts, located at rear of the cabinet. The high quality, gold plated binding posts can accommodate different connection systems: •Banana plugs: The pins can be put directly into the binding post without any tightening necessary. •Cable spades: Loosen the binding posts, insert the spade into the opening, and secure the spade by tightening the posts. - Page 4 Placement Following explanations refer to the figure below. The distance between each loudspeaker (A) and your listening position (B) should be about the same. Try to achieve an isosceles triangle. The distance between the loudspeakers should be the same or slightly less than the distance between each loudspeaker and your listening position (A, B).
-
Page 5: Distance To Back And Side Walls
Distance to back and side walls If a loudspeaker is placed near a wall, ceiling or floor, the lower frequencies will be amplified by the room. Sometimes this is desirable, sometimes it is not (this may lead to indistinct bass reproduction). The bass amplification becomes more obvious if the speaker is placed near a corner. -
Page 6: Rear Speakers
Rear speakers The rear speakers are responsible for the suround effects behind the listening position. When using the bookshelf models as rear speakers, the speakers can be placed into a shelf, mounted at the rear wall or placed on a stand. This allows you a wide variety of placements, even if your listening room and furniture orientation prevent an ideal setup. -
Page 7: Cleaning The Loudspeakers
Cleaning the loudspeakers Switch off all components of your system when cleaning any of these components. Avoid touching the tweeter domes as any change of their shape may have an impact on sound quality. Clean the cabinet and other plain parts with a soft dry or slightly damp cloth only. Remove dust on the woofer diaphragms with a fine furniture brush. -
Page 8: Technical Specifications
Technical Specifications NOVUS 5T Tower Speaker Construction Type 2-Way Floorstanding Speaker Tweeter 1 x 1" Silk-Dome Tweeter Woofer 2 x 5.25" Aramid-Fiber Cone Woofers Frequency Response(+/- 3dB) 36 - 30,000 Hz Nominal impedance 4 Ohms Sensitivity (2.83V / 1 m) - Page 9 Technical Specifications NOVUS 5C Center Channel Speaker Construction Type 3-Way Center Channel Speaker Tweeter 1 x 1" Silk-Dome Tweeter Midrange 1 x 4" Aramid-Fiber Cone Midrange Woofer 2 x 5.25" Aramid-Fiber Cone Woofers Frequency Response (+/- 3dB) 70 - 30,000 Hz...
- Page 10 Product Dimensions (W x H x D) 9.5" x 12" x 5.4" / 240 x 300 x 137mm Product Weight 13 Lbs / 6 Kg Novus 6.5" 2-Way Slim Satellite Wall Speaker Construction Type 2-Way Sealed Tweeter 1 x 1" Silk-Dome Tweeter Woofer 1 x 6.5"...
- Page 11 If you have any questions, comments, or concerns, please don't hesitate to contact any of our Home Theater Gurus at 503.598.8815 or through a live chat via our website at www.aperionaudio.com - we'll be happy to help you out with anything and everything you need.
- Page 12 25599 SW 95th Avenue, Suite D, Wilsonville, OR, 97070 - 503.598.8815...
